12V 100ah SLA AGM Solar Power Energy Batteries

Prod Model:	FG005
Item Name:	12V 100ah SLA AGM Solar Power Tool Batteries
Maintenance Type:	Free
Size:	328*172*222mm
Weight:	30 Kg/PCS
Material:	Fire Proof Case
Warranty:	3 Years
Dod:	70% Reach 1600times
Working Temperate:	-15 to 45
Certificate:	Ce, UL.ISO.PV
Storage Battery:	VRLA Battery for Industry Marketing
Type:	Lead-Acid Batteries
Usage:	Electric Bicycle
Nominal Voltage:	12V
Discharge Rate:	High Discharge Rate
Shape:	Square Battery
Rechargeable:	Chargeable

Product Description

12V 100ah SLA AGM Solar Power Energy Batteries

General Feature:
1. Long battery life, high capacity, Superior of recovery after discharge.
2. ABS material: increase the strength of battery container.  (Flame-retardant ABS is optional)
3. High purity raw material: ensure low self discharge rate.
4. Silver- coated copper terminals, brass insert terminals and lead terminals improve the electric conductivity.
5. Pb CaSn alloy for plate grids: less gassing, less self-discharging high quality.
6. Maintenance-Free Operation
7. Low Self-Discharge


Characteristics
Nominal Voltage			12V
Nominal Capacity (10 hour rate)			100Ah
Capacity 25°C(77°F)		10 hour rate (10A)	100Ah
		3 hour rate (25A)	75Ah
		1 hour rate (55A)	55Ah
Internal Resistance		Full Charged Battery 25°C(77°F)	≤8mΩ
Float Life		25°C(77°F) Float charge at 13.8V	About  5 Years
Capacity affected by Temperature (10 hour )		40°C (104°F)	102%
		25°C (77°F)	100%
		0°C (32°F)	85%
		-15°C (5°F)	65%
Self-Discharge 25°C(77°F)		Capacity after 3 month storage	90%
		Capacity after 6 month storage	80%
		Capacity after 12 month storage	62%
Charge (Constant Voltage) 25°C(77°F)	Cycle	Initial Charging Current Less than 30A Voltage 14.6-15.0V
	Float	Voltage 13.5-13.8V


Applications:

Solar and wind systems Cable TV Telecommunications Wheelchair Marine Equipment

Military Equipment Emergency lighting Power Plants Medical Devices Golf Cart

Battery Use and Maintenance:
1) Please use constant-voltage charge.
2) In floating charge, the voltage is 2.23 to 2.27 per unit cell.
3) In cycle use, the voltage is 2.35 to 2.45 per unit cell, the max. Current is no more than 25%° C
4) Please do tighten the bolts to avoid sparkle and poor contact when the battery is in use.
5) Please do not use it near the heat source and open flame.
6) Please keep it at low temperature. Please change it while there is liquid leaking or damage.
Lead acid battery series:

Style	Size(mm)	Plate	Weight(kg)
SJ12V1.3Ah	97*43*51*57	24	0.53
SJ12V2.6Ah	70*47*99*105	24	0.8
SJ12V5.5Ah	90*70*101*107	36	1.6
SJ12V7Ah	151*65*94*100	48	2.1
SJ12V12Ah	151*98*95*101	72	3.6
SJ12V17Ah	181*77*167*167	48	4.9
SJ12V24Ah	177*165*126*126	66	7.3
SJ12V24Ah	177*165*126*126	42	8.3
SJ12V24Ah	177*165*126*126	42	8.7
SM12V33Ah	196*131*155*180	42	9.2
SM12V40Ah	196*165*175	42	12
SM12V55Ah	229*138*208*227	48	15
SM12V55Ah	229*138*208*227	54	16.5
SM12V65Ah	350*166*175	66	19
SM12V70Ah	350*166*175	72	21
SM12V80Ah	350*166*175	78	22
SM12V90Ah	307*168*208*227	66	25
SM12V100Ah	328*172*222(222)	66	28
SM12V120Ah	406*174*208*233	90	33
SM12V134Ah	340.5*173*280(285)	66	36
SM12V150Ah	483*170*241*241	102	43
SM12V180Ah	532*207*215*240	126	52
SM12V200Ah	522*240*219*244	126	61
SM12V210Ah	522*240*219*228	150	63
SM12V260Ah	522*240*219*228	162	69

Factory Show:


Packing Details:


Our Qualification:




Our Services:

 Samples and OEM, Warranty and After-Sale Service:

• Sample can be provided for quality testing
•  OEM Welcomed
•  Warranty:2 Year
•  After-Sale Service: 24 Hour-Hot Line for Consultacncy and Technical Support

How To Ask for Support if products failure in warranty?
1.Email us about PI number, serial number,Product S/N number,  show us more details such as: pictures,   your testing report or video, if it is the quality problem of product itself, we will resend a new one in       next order.
2.we will submit your case to our after sales department.
3.Usually within 24 hours, we will email you the best solutions.
