| Prod Model: |
NPS100-12 |
| Color: |
Orange |
| Service: |
OEM Is Ok |
| Type: |
Lead-Acid Batteries |
| Usage: |
Solar /Wind Power Storage Battery |
| Nominal Voltage: |
12V |
| Discharge Rate: |
Low Discharge Rate |
| Shape: |
Square Battery |
| Rechargeable: |
Chargeable |
Product Description
12V 100Ah Solar Deep Cycle Gel Lead Acid Battery For Telecommunication, Solar, Powerplant Koyama® Solar Gel Batteries for solar and remote power systems
Koyama® NPS Series Solar Battery is specifically designed with revolutionary long life heavy duty plate gel technology for solar power storage. Solar batteries are traditionally hard working batteries and are usually cycled on a daily basis as part of primary power source of electricity where no grid power is available.
DescriptionSolar batteries are an intricate component for off-grid electrical systems such as solar, wind, and mini hydroelectric systems. All these systems produce DC electrical which must be stored so that it may be used at a later time. In order to do this at the present time, we offer deep cycle gel batteries for this applications.
Deep cycle batteries are used because they have the ability to be recycled many times. This means that they can go from being charged to being discharged to 50% numerous times without damaging the batteries unlike that of other batteries such as cranking batteries which are used to start vehicles.
The innovative
Gel Technology does not only combines the advantages of lower internal resistance of deep cycle battery, but also do have much much better thermal stability and longer cyclic life.
Features-High-quality gel prepared with fumed silica ensures the electrolyte Liquid is uniformly distributed without stratification
-The electrolyte presents a gel state, without flowing or leakage, or recuction, Ensuring homogeneous reaction with the plate; Safe and maintenance Free operation
-Large amounts of liquid; High heat capacity; Good heat sinking capability; Wide operation temperature
-Using lead calcium tin alloy, very low self discharge rate. Long service life
Applications:-Telecommunication system, microwave station, mobile base station, data center, Radio / broadcasting station
-Power plant; Power transmission and transformation system
-Solar energy/ wind power system
-Emergency lighting and signal system
-EPS/ UPS system, etc
-Backup power for open type stationary lead acid batteries
-Marine/ Boats /Navigational Aids (sailing boats, motorized yachts, motor boats, etc)
-Leisure vehicles (caravans, mobile homes, etc)
-Engine Starting
Certificates: ISO9001&14001, CE, UL
Standard: JIS, DIN, IEC & BS6290-4
Specification| Model No | Rated Voltage(V) | Capacity (Ah) | Dimension | Weight | Terminal Type |
| Length | Width | Height | Total Height | kg |
| mm | mm | mm | mm |
| NPS24-12 | 12 | 24 | 165 | 126 | 174 | 179 | 7.8 | L6/T3 |
| NPS26-12 | 12 | 26 | 166 | 175 | 126 | 126 | 8.5 | L2/T2 |
| NPS33-12 | 12 | 33 | 196 | 130 | 155 | 179 | 10.1 | L7/T3/L4 |
| NPS38-12 | 12 | 38 | 197 | 166 | 174 | 179 | 12.4 | L6/T3/L7 |
| NPS42-12 | 12 | 42 | 198 | 166 | 174 | 174 | 13 | L7/T3/L3 |
| NPS50-12 | 12 | 50 | 258 | 134 | 200 | 200 | 15.6 | L8 |
| NPS55-12 | 12 | 55 | 229 | 138 | 208 | 226 | 17.5 | L4/T3 |
| NPS65-12 | 12 | 65 | 350 | 167 | 178 | 178 | 20.3 | L9/T3/L4 |
| NPS70-12 | 12 | 70 | 350 | 167 | 178 | 178 | 21.4 | L9/T3 |
| NPS75-12 | 12 | 75 | 260 | 169 | 211 | 231 | 21.8 | L11/T3 |
| NPS80-12 | 12 | 80 | 260 | 169 | 211 | 215 | 23.5 | T3/L11/L4 |
| NPS85-12 | 12 | 85 | 331 | 174 | 214 | 219 | 25 | L12/T4 |
| NPS90-12 | 12 | 90 | 307 | 169 | 211 | 227 | 27 | L13/T3 |
| NPS100-12 | 12 | 100 | 331 | 174 | 214 | 219 | 30 | L12/T4 |
| NPS120-12 | 12 | 120 | 407 | 174 | 210 | 233 | 34.8 | L14/T5 |
| NPS150-12 | 12 | 150 | 484 | 171 | 241 | 241 | 43.8 | L16/T4 |
| NPS160-12 | 12 | 160 | 532 | 206 | 216 | 221 | 48.5 | L17/T4 |
| NPS180-12 | 12 | 180 | 522 | 240 | 219 | 244 | 55.8 | L17/T5 |
| NPS200-12 | 12 | 200 | 522 | 240 | 219 | 244 | 58.8 | L17/T5 |
| NPS220-12 | 12 | 220 | 522 | 240 | 219 | 244 | 61.4 | L17/T5 |
| NPS250-12 | 12 | 250 | 520 | 268 | 220 | 245 | 71 | L17/T5 |
CBB Battery Technology Co Ltd is a large modern comprehensive power enterprise, specializing in production, R&D and sales of the full line of lead acid battery, with a factory area of 65mu and production area more than 30000m2. Our production capacity has reached more than 3 million KVAH per year.
We mainly produce VRLA battery, automotive battery, Motorcycle battery, Motive power battery, Tricycle battery, Electric vehicle battery and various plates thereof. All batteries are widely used in UPS, Power station, solar power system, telecommunication, vehicles, boats, motorcycle and other applications. All battery can meet a variety of standby, storage, deep cycle, starting, sports, new energy system and other power requirements.
In the past few years, by adopting a lot of advanced production lines and testing devices, we have developed to gain the competitive advantage in the field, which owns first class infrastructure, strict production management, unique know-how and special formula.
We attach importance to scientific and technological personnel, integrating production and research. With the efforts of professional experienced engineers, a well-trained management team and a lot number of skilled production workers, we have established the complete quality management system, which guarantees all battery quality is reliable and long-term stable. Our battery has been sold not only throughout China, but also many foreign countries, its quality have been well recognized by users both at home and abroad.
As one of the leading industrial battery manufacturers, we are keeping quality and environment protection first and foremost in our minds. With a proven track record of this dedication to protect both the earth, our employees for years has propelled us to be the industry leader in environmental protection while still maintaining the highest quality products on the market. With the recertification of Chinese Environment Ministry to Chinese battery industry in 2011, we have been becoming the best company on the environmental protection in South of China. We have been certified by IS09001, IS014001, CE, UL, RoHS, and OHSMS18001.
With the spirit of Unity, Development, Trust and Quality First, Our Team would offer you the best quality battery and services. It is our eternal pursuit to continuously meet all customer''s expectation and demands, with unremitting efforts to offer high-quality battery and excellent after-sales for all users at home and abroad.
Your any cooperation is highly appreciated
