| Prod Model: |
JL-20A180 |
| Markets: |
North America,South America,Eastern Europe,Southeast Asia,Africa,Oceania,Mid East,Eastern Asia,Western Europe |
| Brush: |
Metal /Carbon Brush |
| Diameter: |
20mm |
| Gear: |
Metal Gears |
| Torque: |
High Torque |
| Power: |
DC |
| Micro: |
Micro Gear Motor |
| Speed: |
Constant Speed |
| Shaft: |
Stainless Steel |
| Material: |
RoHS Material |
| Noise: |
Low Noise |
| Application: |
Household Appliances |
| Operating Speed: |
Constant Speed |
| Excitation Mode: |
Compound |
| Structure And Working Principle: |
Brush |
| Type: |
Gear Motor |
| Certification: |
ISO RoHS |
| Brand: |
Kingly |
Product Description
DC Geared Motor
Typical Applications
Electric-drive toy
Electric-drive toothbrush
ProjectorOutput Power: Approx 0.1W-20W
Voltage: From 1.5v to 24v
Speed: From 2rpm to 3000rpm
Ratio: From 1: 5 to 1: 2340
Torque: From 0.1kg. Cm to 120kg. Cm
Dia: 6mm to 48mm
-Motor's specification and shaft length can be tailor-made according to customer's requirements.
Weclome your inquiry!
Gear Motor JL-20A130/20A180
Typical Applications
Electric-drive toy
Electric-drive toothbrush
ProjectorOutput Power: Approx 0.1W-20W
Voltage: From 1.5v to 24v
Speed: From 2rpm to 3000rpm
Torque: From 0.1kg. Cm to 8kg. Cm
Dia: 6mm to 48mm
1.DC Gear Motor JL-20A180
2.brushed motor with gear reducer
3.motor manufacturer dc motor
4.motor motors gearbox with motor gear reducer
5.With CE, ROHS ISO9001:2000 certificates.
6.Diameter of gear box: 38mm rectangle gear box motor
7.Motor diameter:33mm (carbon brush/metal brush)
8.low noise long-life
9.Ruduction Ratio: customizable
10.Gearbox diameter :20mm
11.The shaft:4.0mm D-shaped
12.Typical Applications of DC Gear Motor
Tie-yarn machine
Massager
Cut-card machine, etc.
-Motor's specification and shaft length can be tailor-made according to customer's requirements.
Weclome your inquiry!
| Model | Voltage | No Load | At Maximum Efficiency | Stall |
| V | Speed | Current | Speed | Current | Torque | Output | Torque | Current |
| r/min | A | r/min | A | mN.m | kg.cm | W | mN.m | kg.cm | A |
| JL-20A130-31 | 12 | 290 | 0.04 | 220 | 0.12 | 21.5 | 0.22 | 0.49 | 89.2 | 0.91 | 0.41 |
| JL-20A180-195 | 2.4 | 41 | 0.16 | 35 | 0.82 | 147 | 2.05 | 0.37 | 140.2 | 14.3 | 4.5 |
| | | | | | | | | | | | |
| Match Motor | Length of motorL2 | | | | | | | | | |
| JFF-130 | 25.1mm | | | | | | | | | |
| JFF-180 | 32.1mm | | | | | | | | | |
| Length of GearL | Reduction Ratio | | | | | | | | |
| 16mm | 10 | 12.5 | 25 | 31 | | | | | | | |
| 17.5mm | 50 | 62 | 78 | | | | | | | | |
| 19mm | 107 | 125 | 156 | 195 | | | | | | | |
| 20.5mm | 250 | 313 | 391 | 488 | | | | | | | |
Core solutions to the world industrial 4.0 and related intelligent application sector!
Kingly Gear is a high-tech enterprise engaged in designing, manufacturing and selling micro gearbox, micro DC motor, AC motor, brushless motor and motor control system. It is the modern high-tech enterprise producing DC/AC motor and micro speed reduction system in large scale.
The main Applications:
L Intelligent industry: Industrial automization, Automatic lubricator, Industrial machine arm
L Intelligent agriculture: Greenhouse tent, Automatic sprinkler
L Intelligent logistics: Conveyor system
L Intelligent water and power grid: Water-electricity-gas value intelligent control
L Intelligent safeguard system: Electronic locks, Automatic door, automatic windows
L Intelligent home furnishing: Sweeper robot, Intelligent closestool, Switch,
L Intelligent environment protection:
L Intelligent transportation: Auto industry
L Intelligent medical treatment: Massager
L Intelligent entertainment: Automatic card collating machine, Stage lighting
Kingly has the production base in Huizhou of Guangdong and Huang Gang of Hubei respectively. Besides, it also sets directly subordinated branch companies in Germany in Europe and Shanghai/Ningbo/Hangzhou/Wenzhou/Chengdu in China.
Kingly has a group of qualified employees professionally engaging in R&D, production and sales. Except common micro motors and gear boxes, it also developed over 200 various special non-standard micro motors and gear boxes. It emphasizes intellectual properties, boasting dozens of patent for utility models and the copyright of motor control software.
By virtue of strong customized technology development ability and production and sales ability, its products are sold nationwide and also exported to Europe, the United States, Australia, Japan and Middle East.
Kingly will keep optimizing markets, continuously upgrade various hardware equipment and manufacturing process standards to satisfy customers, overtake industrial competitors and become the best optimal plan provider for micro intelligent transmission in China.
Company Vision: To be No. 1 brand in the customized precise transmission control system in China!
Enterprise positioning: Service and product provider for customized customized precise transmission control system!
Enterprise Mission: Provide core solutions to the world industrial 4.0 and related intelligent application sector!
Enterprise Tenet: Build the business through refined technology to meet customers' requirements; Win the competition through high quality and produce reliable products; Treat others with sincerity and provide qualified service.
Our tenet: Make enterprise with excelsior attitude, win customers with high quality, treat anybody with all sincerity!
