12V 24V 48vlithium Battery for Solar System

Name: 12V 24V 48vlithium Battery for Solar System
Brand: all-electronics-online.com
SKU: 675717055
Availability: InStock
Rating: 4.7 (72 reviews)

Price:	US $ 465-665/Piece
Trade Terms:	FOB,CIF,EXW
Min Order:	10/Piece
Pay Type:	L/C,T/T,Western Union

Contact Supplier

Showroom Product Company Profile

Prod Model:	OPT-XXX-XXX
Markets:	North America,South America,Eastern Europe,Southeast Asia,Africa,Oceania,Mid East,Eastern Asia,Western Europe
Product Name:	Lithium Battery (12V, 24V, 48V, etc) for Solar Sys
Cell:	32650
Standard Capacity:	20ah/50ah/100ah/200ah/400ah
Rated Voltage:	12V/24V/48V
Certificate:	CE,UL,SGS/RoHS,Rbrc,ISO9001:2000,ISO1400,Ts16949:2
Components:	Lithium Iron Phosphate
Composed Type:	in Parallels and Series
Warranty:	2 Years
Package:	Plastic Case or Custmized
Color:	Blue/Black .
Type:	Lithium-Ion Batteries
Usage:	Solar Energy System
Nominal Voltage:	12V
Discharge Rate:	Low Discharge Rate
Shape:	Square Battery
Rechargeable:	Chargeable
Electrolyte:	LiFePO4

Product Description

Lithium Battery (12V, 24V, 48V, etc) for solar system

Specifications

12V 5/10/20/25/30/40/50/60/80/100/120/150/200/300/400Ah
Item No.	OPT12005	OPT12010	OPT12020	OPT12030	OPT12040	OPT12050	OPT12060
Standard Capacity	5Ah	10Ah	20Ah	30Ah	40Ah	50Ah	60Ah
Rated Voltage	12.8V
Discharge Cut-off Voltage	10.0V
Cell Model	IFR32650/32750
Casing Material	Steel Case for Single Cells
Self Discharge Rate	≤3% after one month
Life Cycles	80% capacity remaining after 2000 times at 1C rate 100%DoD
Max Charger Voltage	DC14.6V
Standard Charge Current	0.2C
Protection Function	Short-circuit &Over-current &Overcharge &Over-discharge &Undervoltage Protection
Product Size(mm)	1515193	1358585	18276167	118175175	190165175	190165175	350168179
Approx N.W	0.9Kg	1.3Kg	2.8Kg	4.0Kg	5.5Kg	7.0Kg	8.0Kg
	OPT12080	OPT12100	OPT12150	OPT12200	OPT12200	OPT12300	OPT12400
Standard Capacity	80Ah	100Ah	150Ah	200Ah	200Ah	300Ah	400Ah
Product Size(mm)	260170215	330170220	502262242	502262242	360220262	520262242	560360200
Approx N.W	11Kg	16Kg	24Kg	35Kg	38Kg	45Kg	65Kg

24V 5/10/15/20/30/40/50/60/70/100/120/150/200Ah
	OPT24005	OPT24010	OPT24010	OPT24015	OPT124020	OPT24030	OPT24040
Standard Capacity	5Ah	10Ah	10Ah	15Ah	20Ah	30Ah	40Ah
Rated Voltage	25.6V
Discharge Cut-off Voltage	20V
Cell Model	IFR32650/32750
Casing Material	Steel Case for Single Cells
Self Discharge Rate	≤3% after one month
Life Cycles	80% capacity remaining after 2000 times at 1C rate 100%DoD
Max Charger Voltage	DC29.2V
Standard Charge Current	0.2C
Protection Function	Short-circuit &Over-current &Overcharge &Over-discharge &Undervoltage
Product Size(mm)	1477171	36111281	18176167	197125155	190165175	350168179	28028078
Approx N.W	1.45Kg	3.8Kg	3.5Kg	4.5Kg	6.0Kg	8.68Kg	10.5Kg
	OPT24050	OPT24060	OPT24070	OPT24100	OPT24150	OPT24200
Standard Capacity	50Ah	60Ah	70Ah	100Ah	150Ah	200Ah
Product Size(mm) (changeable)	323171215	275210195	500170203	360220262	520265220	560360200
Approx N.W	15Kg	20Kg	22Kg	35Kg	51Kg	68Kg

Product Feature
1. Safety: the safest Li-ion battery, CE UL approved, BMS built inside to protect the battery in the round, none fire, none explosive
2. Environment friendly, Clean and Green energy, no toxic material contained
3. Long life cycle, more than 2000 cycle in 0.5C~1C discharge, 8 times of Lead acid battery
4. No memory effect, highly efficient charge, can be recharged anytime, no reduction of capacity
5. Broad operation temperature: -20~70°C
6. Small in size and light in weight: 1/2 size of lead acid battery, 70% size of
Ni-MH Ni-Cd battery, 1/2 weight of lead acid battery
7. Good performance at high temperature and high temperature resistance
8. Low self-discharge rate: less than 3% monthly

Applications
1. Large-scale electric vehicles: electric bus, electric car, E-Tour Car
2. Light electric car: electric bicycle, electric scooter, electric motor, electric golf car, small-scale electric flat car, forklift, cleanness car, electric wheelchairs
3. Electric tool: electric drill, electric saw, lawn mower and so on
4. Remote control cars, boat, aircraft, toys
5. Solar and wind power generation energy storage devices
6. Small medical equipment and portable equipment

IS9001:2008, TS16949 factory
The largest factory of producing 32650-3.2V-5Ah LiFePO4 cell in China

Optimum Battery Co., Ltd/Optimumnano Energy CO.,LTD is one of the largest Lithium battery manufacturers with ISO9001 and TS16949 certificates etc in China, specializing in LiFePO4 batteries with UL, CE, ,C-tick, RoHS, IEC-62133 etc certifications for 7 years. We are the largest factory of producing cylindrical 32650-3.2V-5Ah/5.5Ah LiFePO4 cells in China.

As one of eight China national high and new tech enterprises, there are about 4000 staffs including 300 engineers producing batteries widely used in EV, HEV, telecommunication stations, e-bikes, e-motorcycles, UPS, solar/wind energy storage solution, home application etc..

Company Name: OptimumNano Energy Co., Ltd

Name of Exhibition: The China Sourcing Fair

Address: Hong Kong Asia Exhibition Hall

Booth No: At at 9B05

Dates: Oct 11-14, 2015(4 Days)

In 2002, OptimumNano Energy Co., Ltd started the battery business in Shenzhen.

In 2006, OptimumNano began to focus on the production, Engineering, researching and manufacturing of LiFePO4-Lithium Iron Phosphate Battery, we believe the LiFePO4 shall be the best Lithium-ion Power Solution in the future

In 2008, OptimumNano finished the first Pure Electric Bus with LiFePO4 Battery, demonstrating and running for Shanghai EXPO.

In 2009, OptimumNano was awarded the honor of "National High-tech Enterprise".

In 2011, OptimumNano was the main vehicle power battery supplier of the 26th World Universiade Games.

In 2012, OptimumNano was selected as one the supporting company of "2012 New Energy Automotive Industry Technology Innovation Project", which was launched by the Ministry of Finance, the Ministry of Industry and the Ministry of Science and Technology.

In 2013, OptimumNano moved to new and bigger factory to meet our 500, 000 PCS daily production requirement.

In 2014, Shenzhen mayor Mr. Wang Rong and others come to our company to make researches and guidances and gave high praise for our company achievement in the new energy industry

OptimumNano set up the workstation for Academician Material Application. With around 500 R&D staffs, now we have more than 200 patents at home and abroad.

After over 13 years' development, OptimumNano has offices in local 31 cities, distribute our LiFePO4 batteries to over 40 countries in the world.
