| Prod Model: |
PDF600-280S12 |
| Markets: |
North America,South America,Eastern Europe,Southeast Asia,Africa,Oceania,Mid East,Eastern Asia,Western Europe |
| Output Voltage: |
12VDC |
| Output Current: |
50A |
| Size: |
61.00*50.80*12.70mm |
| Output Type: |
Single |
| Warranty: |
2 Years |
| Connection Mode: |
Series Switching Power Supply |
| Starting Mode: |
Separate-excited Switching Power Supply |
| Voltage Regulating Mode: |
Width Modulation Type |
| Power Supplying System: |
Terminal Power Distribution Equipment |
| Certification: |
ISO |
| Output Power: |
600W |
| Input Voltage: |
280VDC |
| Brand: |
Pengtu |
Product Description
12V 50A power supply with full brick standard
Product Description
Features
l Industry standard full brick
l High power density
l 1500V input-output isolation
l Aluminum baseplate technology
l Aluminum baseplate technology
l Remote sensing of compensation
Input Characteristic
l Inputvoltage range............ 200 ~ 400 VDC Rated value: 220VDC
Reverse Protection
Fuse Outside
Output Characteristic
l Voltage set-point accuracy ......... ±1%
l Line regulation(main) ............... ±0.3%
l Load regulation(main) .............. ±0.5%
l Temperature coefficient .............. ±0.02%/ºC
l Output current limiting .............. 120%(Typ)
l Dynamic response ............ 200μs
General Characteristic
l Switching frequency ............ 300 KHz
l Isolation resistance ............ 200 MΩ
l MTBF .................. >50000H
l Isolation voltage
Input-output: >1500 VDC
Input-case: >1050 VDC
Output-case: >500 VDC
l Environmental Characteristic
Operation temperature ......... Industry: -25-+60ºC; MilitaryI: -40~ +70ºC
Storage temperature ............ Industry: -45~ +105ºC; Military: -55~ +105ºC
Models
| Model | Output Lines | Input Voltage (V) | Input Voltage Range (V) | Output Voltage (V) | Output Current (A) | Ripple pk-pk (mv) | Efficieency (Typ) |
| PDF600-280S12 | Single | 280 | 200-400 | 12 | 50 | 120 | 92% |
| PDF600-280S24 | Single | 280 | 200-400 | 24 | 25 | 240 | 90% |
| PDF600-280S28 | Single | 280 | 200-400 | 28 | 21.5 | 280 | 91% |
| PDF600-280S48 | Single | 280 | 200-400 | 48 | 12.5 | 480 | 91% |
Remark: Custom-made specifications are acceptable.
