| Prod Model: |
A100-12 |
| Markets: |
North America,South America,Eastern Europe,Southeast Asia,Africa,Oceania,Mid East,Eastern Asia,Western Europe |
| For Use: |
Standard Battery |
| Case: |
PC+ABS Plastic |
| Customized: |
Yes |
| Color: |
Yes |
| Recovery Function: |
Yes |
| MCU Controller: |
Yes |
| Short Circuit Protection: |
Yes |
| Reverse Potection: |
Yes |
| LED: |
Yes |
| Delivery Date: |
3-4 Weeks |
| Type: |
Lead-Acid Batery |
| Charger Type: |
Lead-Acid Batery Charger |
| Charger Application: |
Electric Wheelchair/Scooter/Sightseeing Car/E-Bike |
| Nominal Voltage: |
13.8V |
| Compatible Battery Type: |
12 Volt 10~60ah Lead-Acid Battery |
| Size: |
170 X 70 X 41mm |
| Socket Type: |
UL, VDE, PSE, UK, SAA... |
Product Description
A100-12 12V Car Motorcycle Battery Charger for Lead Acid Battery
-
| Specification |
|---|
| Input: 100~240V |
| Output: 13.8V 5.0A |
| Charge Process: MCU Control, With Recovery Function |
| Charger Indicator: With One Bi-color LED Indicator |
| Output Protections: Short-circuit, Reverse Polarity |
| Safety Approval: CE cUL |
| Size: 170 x 71 x 41mm |
| Suit for Battery: 12 Volt 10~60Ah Lead-Acid Battery Charger |
Feature:programmed 3 auto stages (CC-Bulk-Float) charging process.
It is designed for all kinds of 12V Lead-Acid battery, such as SLA, AGM and Gel battery.
With Bi-color LED battery indicator, easily know the charging process.
Protection mode for battery polarity reversed or the output connectors shorted.
UL, CE approval (EN60335-2-29 and UL1310)
Application: Power Tool, Electrical Toy, Mobile Lamp, Security system,car battery,motorcycle battery, automotive battery, golf cart charger,boat battery and so on.
Specification for A100-12| AC Input | 100-240V, 1.6A, 50-60Hz 1.6A |
| Charge voltage Limited | A100-12 | A100-24 | A100-36 | A100-48 |
| 14.7V±1% | 29.4V±1% | 44.1V±1% | 58.2V±1% |
| Bulk charge current | 5.0A±5% | 2.8A±5% | 1.8A±5% | 1.7A±5% |
| Float charge voltage | 13.7V±1% | 27.4V±1% | 41.1V±1% | 54.2V±1% |
| Operate Temperature | -20ºC~40ºC |
| Cooling | Natural convection. Do not cover the charger. |
| Charge principle | Auto 3 stages: Bulk C.C. + Bulk C.V. + Floating C.V. |
| Battery type | All types of 12V 7~80Ah lead-acid batteries. (SLA, Gel, AGM.) |
| LED display | Bi-color LED indicator, "Red" for charging "Green" for full charged or idle. |
| Size | 170 x 71 x 41mm |
| Output cable & plug | 1.5 meter 2xAWG18#, SPT1 wire, DC plug type defined by user |
| Input AC plug | IEC60320-C14 or C-8 |
| Enclosure | ABS+PC Plastic housing |
| Weight | 400g |
An example shows the duration of 80% state charged for an empty battery.
Battery capacity | G100-24L |
| 3.2Ah | 1.5 hours |
| 7.0Ah | 3 hours |
| 12Ah | 5 hours |
| 25Ah | 10 hours |
If you have specific parameters and requirements for our Battery Charger, customization is available
For more details, please link Company homepage http://www.green-charger.com/en/.
Green-charger's engineers have dedicated to digital control power products for 13 years, specialize in the design and manufacture many types of NiMH, NiCd, Li-ion and Lead-acid battery charger and battery meter, and also is a professional in the face of high-end clients of the battery charger and battery meter. These products have high performance microprocessor technology to power your battery safely and quickly The main products are battery chargers that can be used in the Electrical-Vehicle, wheelchair, scooters, motorcycles, RC toy, RC flight, mobile light/lamp, LED lamp and many kinds of portable electrical device. The type of chargers have NiMH NiCd charger, lithium battery charger, lead-acid battery charger, LiFePO4 battery charger and so on. All sorts of 5W to 500W power charger all have production, is one of the most professional manufacturers of battery chargers in China.
After many years experiences, Green-charger made a super technology and rich experience of senior R&D engineers. We can develop battery chargers for NiMH, NiCd, Lead-Acid and Li-ion batter pack. The Battery chargers and Battery Management is our produces family also.
Our quality policy is: Providing high reliability of the products, to provide high satisfaction service. We are equipped with the advanced production and kind of test instruments, has the rich RoHS process production management, to ensure that every batch of products satisfy customers. Our products have CCC UL cUL CE VDE CB PSE FC EMC and so on.
We can according to the specific requirements of customers, customized all kinds of non-standard products to meet the needs
