| Prod Model: |
NP12 series |
| Markets: |
North America,South America,Eastern Europe,Southeast Asia,Africa,Oceania,Mid East,Eastern Asia,Western Europe |
| Capacity 1: |
12V 4ah--250ah |
| Capacity 2: |
2V 300ah to 3000ah |
| Maintenance Type: |
Free |
| Deep Cycle: |
Yes |
| Service Life: |
up to 12 Years |
| Warranty: |
1-3 Years |
| Temp Range: |
-10 Degree to 65 Degree |
| Model You Can Choose: |
AGM Type,Deep Cycle AGM Type,Gel Type |
| Certificate: |
CE, ISO |
| Type: |
Lead-Acid Batteries |
| Usage: |
Solar Power |
| Nominal Voltage: |
12V |
| Discharge Rate: |
Medium Discharge Rate |
| Shape: |
Square Battery |
| Rechargeable: |
Chargeable |
Product Description
12V 75AH AGM maintenance free motorcycle battery
Main Features
1. Long service life: 6 to 12 years design:
AGM type:6-8 years
Deep cycle AGM type:8-10 year
Gel type:10-12 year
2. Low self-discharge: at the ambient temperature 25C, self-discharge rate is less than 1.8% after 28 days storage
3. Sufficient capacity: guarantee 100% capacity; voltage and capacity of the battery is accordant
4. Maintenance-free operation
5. Good electric conductivity: adopting red copper with silver plated patent terminal , it allows the battery discharge with high current
6. Good charge acceptance performance: so the charge acceptance of the battery is more efficient, the charge time for battery is shorter, the capacity is easier and quicker to be recovered
7. Safe and reliable venting system,can eliminate the danger of explosion under large pressure
8. Good sealing capability: no pollution and corrosion, which ensure the battery operate safely and efficiently in horizontal and vertical position. The sealed construction can combine the generated gas to water, and no need to add water or check their specific gravity during the life of the battery
9. No memory effect after repetitious usage or discharges
10. Wide operating temperature range:
AGM type:1-30ºC
Deep cycle AGM:1-40CºC
Gel type: -10-65ºC
Applications
Solar Powered Systems
Uninterruptible Power Supplies
Emergency Lighting Systems
Electric powered Bicycle and Wheelchairs
Vending Machines
Alarm Systems
Marine/Geophysical / Medical / Communications/ Electronic Test/ equipment
Cable Television
Micro Processor Based Office Machines
Control Equipment Portable Cine & Video Lights
Electronic Cash Registers
Telecommunications Systems
Television & Video Recorders
Toys,Fire, Security Systems
| Voltage | Capacity
(AH) | Dimension(mm)(±5%) | Net weight
(kg)(±5%) |
| Length | Width | Height | Total Height |
| 12V | 5AH | 90 | 70 | 101 | 107 | 1.56 |
| 7AH | 151 | 65 | 94.5 | 100 | 2.05 |
| 9AH | 151 | 65 | 94.5 | 100 | 2.35 |
| 12AH | 151 | 98 | 95 | 101 | 3.4 |
| 18AH | 181.5 | 77 | 167.5 | 167.5 | 5.3 |
| 20AH | 181.5 | 77 | 167.5 | 167.5 | 5.7 |
| 24AH | 166.5 | 175 | 125 | 125 | 7.8 |
| 30AH | 195 | 130 | 164 | 180 | 9.5 |
| 38AH | 197 | 165 | 170 | 170 | 12 |
| 45AH | 197 | 165 | 170 | 170 | 13.8 |
| 50AH | 257 | 132 | 200 | 200 | 16.2 |
| 65AH | 348 | 167 | 178 | 178 | 21 |
| 75AH | 259 | 168 | 208 | 214 | 22.5 |
| 80AH | 259 | 168 | 208 | 214 | 24 |
| 100AH | 330 | 173 | 212 | 220 | 29.5 |
| 120AH | 410 | 177 | 225 | 225 | 35 |
| 150AH | 484 | 171 | 241 | 241 | 44.5 |
| 160AH | 530 | 209 | 214 | 234 | 48 |
| 180AH | 530 | 209 | 214 | 234 | 50 |
| 200AH | 522 | 240 | 218 | 224 | 59 |
| 250AH | 522 | 268 | 220 | 226 | 69 |
| 2V | 300AH | 170 | 150 | 328 | 350 | 18.5 |
| 500AH | 240 | 175 | 330 | 350 | 30 |
| 800AH | 410 | 175 | 330 | 351 | 50 |
| 1000AH | 475 | 175 | 328 | 350 | 61.5 |
| 1500AH | 403 | 354 | 339 | 349 | 92 |
| 2000AH | 490 | 350 | 339 | 349 | 92 |
| 3000AH | 709 | 350 | 337 | 349 | 181 |
Shipping
1. FedEx/DHL/UPS/TNT for samples, Door-to-Door;
2. By Air or by Sea for batch goods, for FCL; Airport/ Port receiving;
3. Customers specifying freight forwarders or negotiable shipping methods!
4. Delivery Time: 3-7 days for samples; 5-25 days for batch goods.
Payment Terms
1. Payment: T/T, Western Union, MoneyGram, Cash
2. MOQ: 10pcs
3. Warranty : 1-3 years
4. Package Informations: Export standard carton package or based on your requirement
Why Choose us?
1.We are Alibaba Assessed 7 years Gold Supplier.
2.We are a factory manufacturing battery, inverter chargerand UPS,best production capability and quality control
3.OEM and ODM service, fully meet your demand
4.100% QC inspection Before Shippment.
5. Competitve price.
FAQ
Q1. We are a new and small company dealing with power inverter, UPS and solar energy related products. What kind of support you can provide?
A. We can provide you the most competitive price and lower MOQ requirement to help you develop when you are new. Besides, 2 years warranty and life-long technical support.
Q2.What's the warranty details?
A. For the 1-3 year years warranty, it is applied to mass order. Every product will be inspected strictly before delivery.
So we can ensure the failure rate is very low.
1) Within warranty period
If the machine breaks down due to non-human or non misuse reasons, we will be responsible for free repair. The freight of the round-trip of the goods is on our account. Or we provide technical assistance and supply spareparts for free to customers; if bulk goods have problems,we will send technicians to customers' side to solve the problem.
If the malfunction is caused by misuse or other human factors, we will charge for the spare parts and repair fee, freight is on customers' account.
2) After the warranty period
The materials and maintenance expenses will be charged, and freight is on customers' account; lifetime technical support is free.
Q3. Can you put my logo on the unit or change the appearance?
A. Absolutely. We are a professional manufacturer and provide OEM/ODM service. Our R&D department can also help to add new functions according to your market requirement.
Q4. Do you have inverter also?
A.Yes. Besidesbattery, we can also provide you inverter/charger, MPPT solar charge controller and online/offline UPS.
