12V12ah Rechargeable AGM Battery Lead Acid UPS Battery

Prod Model:	FG298
Markets:	North America,South America,Eastern Europe,Southeast Asia,Africa,Oceania,Mid East,Eastern Asia,Western Europe
Item Name:	12V12ah Rechargeable Lead Acid UPS Battery
Maintenance Type:	Free
Size:	90*70*101*107mm
Weight:	3.2kg/PCS
Material:	Fire Proof Case
Warranty:	3 Years
Terminal:	F2
Working Temperate:	-15 to 45
Certificate:	Ce, MSDS
Cell:	6
Type:	Lead-Acid Batteries
Usage:	Electric Bicycle
Nominal Voltage:	12V
Discharge Rate:	High Discharge Rate
Shape:	Square Battery
Rechargeable:	Chargeable

Product Description

12V12AH 12V12ah Rechargeable AGM Battery Lead Acid UPS Battery

The products are widely used in telecommunications, electricity, solar energy, rail transportation and its auxiliary systems, UPS systems, emergency lighting systems and new energy and many other areasGuangzhou Future Green Energy Technology Co.,Ltd is a professional lead acid battery ,plate and Activity Silica Gel manufacturer with own R&D and sales team based on more than 7 years experience.
We welcome orders with "FGET" brand; We are also flexible to accept orders on OEM basis. Contact us now! All of the possibilities is in FGET

General Feature:

1. Long battery life, high capacity, Superior of recovery after discharge.
2. ABS material: increase the strength of battery container.  (Flame-retardant ABS is optional)
3. High purity raw material: ensure low self discharge rate.
4. Silver- coated copper terminals, brass insert terminals and lead terminals improve the electric conductivity.
5. Pb CaSn alloy for plate grids: less gassing, less self-discharging high quality.
6. Maintenance-Free Operation
7. Low Self-Discharge

Battery Out Size:
Battery Parameters:


Characteristics
Nominal Voltage			12V
Nominal Capacity (20 hour rate)			12Ah
Capacity 25°C(77°F)		20 hour rate (0.6A)	12Ah
		10 hour rate (1.14A)	11.4Ah
		5 hour rate (1.92A)	9.6 Ah
		1 hour rate (7.8A)	7.8Ah
Internal Resistance		Full Charged Battery 25°C(77°F)	≤22mΩ
Float Life		25°C(77°F) Float charge at 13.8V	About 3 Years
Capacity affected by Temperature (20 hour )		40°C (104°F)	102%
		25°C (77°F)	100%
		0°C (32°F)	85%
		-15°C (5°F)	65%
Self-Discharge 25°C(77°F)		Capacity after 3 month storage	90%
		Capacity after 6 month storage	80%
		Capacity after 12 month storage	62%
Charge (Constant Voltage) 25°C(77°F)	Cycle	Initial Charging Current Less than 3.6A Voltage 14.6-15.0V
	Float	Voltage 13.5-13.8V

Application:


Solar and wind systems Cable TV Telecommunications Wheelchair Marine Equipment

Military Equipment Emergency lighting Power Plants Medical Devices Golf Cart

Battery Use and Maintenance:
1) Please use constant-voltage charge.
2) In floating charge, the voltage is 2.23 to 2.27 per unit cell.
3) In cycle use, the voltage is 2.35 to 2.45 per unit cell, the max. Current is no more than 25%° C
4) Please do tighten the bolts to avoid sparkle and poor contact when the battery is in use.
5) Please do not use it near the heat source and open flame.
6) Please keep it at low temperature. Please change it while there is liquid leaking or damage.


Battery
Model	Voltage (V)	Capacity C20(h)	Size(mm)				Approx.weight (kg)
			Length	Width	Height	Total height
12V7AF	12	7	151	65	94	100	2
12V12AF	12	12	151	98	95	101	3.2
12V17AF	12	17	181	77	167	167	4.8
12V24AF	12	24	177	165	126	126	7.3
12V33AF	12	33	196	131	155	180	10
12V40AF	12	40	196	165	175	175	12
12V50AF	12	50	229	138	208	227	15
12V70AF	12	70	350	166	175	175	21
12V100AF	12	100	328	172	222	222	28
12V150AF	12	150	483	170	241	241	43
12V200AF	12	200	522	240	219	244	58
SJ6V4.5Ah	6	4.5	70	47	101	107	0.71
SJ6V5Ah	6	5	70	47	101	107	0.75
SJ6V7Ah	6	7	151	34	94	100	1
SJ6V12Ah	6	12	151	50	94	100	1.7
SM6V100Ah	6	100	195	170	207	212	14
SM6V150Ah	6	150	298	170	207	227	20
SM6V200Ah	6	200	323	178	229	231	31

Factory Show:


Packing Details:

Normally packing: 1pc/5pcs/8pcs/10pcs per carton
Individual packing requirement is acceptable.


Our Services:

 Samples and OEM, Warranty and After-Sale Service:

 OEM Welcomed
 Warranty: 2 Year
 After-Sale Service: 24 Hour-Hot Line for Consultacncy and Technical Support

How To Ask for Support if products failure in warranty?
1. Email us about PI number, serial number,Product S/N number,  show us more details such as: pictures, your testing report or video, if it is the quality problem of product itself, we will resend a new one in next order.
2. we will submit your case to our after sales department.
3.Usually within 24 hours, we will email you the best solutions.
