| Prod Model: |
12V150Ah FR |
| Color: |
Grey or Black |
| Terminal: |
B/F11/F12 |
| Size: |
L565*W110*H288(T295)mm |
| Weight: |
44.0kg/97.0lbs |
| Lead-Time: |
20-40days |
| Packing Qty: |
1 PCS/CTN |
| Applications: |
UPS, Telecom System, Bank Security System |
| Type: |
Lead-Acid Batteries |
| Usage: |
Boat |
| Nominal Voltage: |
12V |
| Discharge Rate: |
Low Discharge Rate |
| Shape: |
Square Battery |
| Rechargeable: |
Chargeable |
Product Description
LONGWAY 12V150ah Front Access Valve Regulated Sealed Lead-Acid Battery
*The Longway FR series battery is mainly uesed in the area of communication,
which is novel in design, reasonable in structure and occupying the leading
position in the same industry of the world.
*As with previous INTELEC(International Telecommunications Energy)conferences,
many people were concerned about the life and durability of VRLA(Valve regulated
lead acid) batteries,
*It can be employed in numerous applications in the fields of communications, In order
to ensure that the power supply is guaranteed at all times, essential facilities are backed
up with high performances battery systems. Sudden breaks in the power supply are then
no longer a problem. If the power suddenly fails, battery systems take over the emergency
supply of power.
Specifications:
| Cells per Unit | 6 |
| Normal Voltage | 12V |
| Capacity | 150Ah@10Hr-rate to 1.80V per cell@25ºC |
| Weight | Approx(44.0±3%kg) (97.0lbs) |
| Maximum Discharge Current | 1500A(5sec) |
| Internal Resistance | Approx. 4.0mΩ full charged @25ºC |
| Operating Temperature Range | Discharge: -20ºC~60ºC
Charge:0ºC~50ºC
Storage: -20ºC~60ºC |
Nominal Operating
Temperature Range | 25ºC±3ºC |
| Float Charging Voltage | 13.7~13.9VDC/unit Average @25ºC |
| Maximum Charging Current | 37.5A |
| Equalization and Cycle Service | 14.4V~15.0VDC/unit Average @ 25ºC |
| Self Discharge | LONGWAY Valve Regulated Lead Acid (VRLA) batteries can be stored
for more than 6 months at 25ºC. Self-discharge ratio less than 3%
per month at 25ºC. Please charge batteries before using. |
| Terminal | Terminal F12 |
| Container Material | ABS(UL94-HB)
*Flammability resistance of (UL94-V0) can be available upon request |
*General Features
Environmental friendly;
Thick pasted plates with quality lead-tin-calcium alloy grids for long service life;
Centralized venting system for gas ventilation;
Plastics or rope handles for handling and installation convenience;
Front access terminals for easy and quick connection;
Low internal resistance;
Lower self discharge.
*Applications: UPS, Telecom System, Bank Security System, Railway, Solar Light system
Our factory photo
Our certificate
If any interest, welcome to contact us freely.
| Standby LONGWAY FR series batteries |
| Battery Model | Nominal
Voltage
(V) | Nominal
Capacity
(AH) | Length | Width | Height | Total Height | Weight(5%) | Terminal |
| In | mm | In | mm | In | mm | In | mm | Pound | Kg | Type | Position |
| 6FM55FR | 12 | 55 | 11.5 | 291 | 4.17 | 106 | 8.78 | 223 | 9.06 | 230 | 39.7 | 18.0 | F9 | E |
| 6FM75FR | 12 | 75 | 22.1 | 562 | 4.53 | 115 | 7.36 | 187 | 7.64 | 194 | 51.8 | 23.5 | F10 | E |
| 6FM85FR | 12 | 85 | 22.1 | 562 | 4.53 | 115 | 7.36 | 187 | 7.64 | 194 | 56.2 | 25.5 | F10 | E |
| 6FM105FR | 12 | 105 | 20.0 | 508 | 4.33 | 110 | 8.86 | 225 | 9.13 | 232 | 71.7 | 32.5 | F10 | E |
| 6FM110FR | 12 | 110 | 16.1 | 410 | 4.33 | 110 | 11.3 | 288 | 11.6 | 295 | 72.8 | 33.0 | F10 | E |
| 6FM125FR | 12 | 125 | 21.7 | 551 | 4.29 | 109 | 9.41 | 239 | 9.41 | 239 | 79.4 | 36.0 | F11 | E |
| 6FM150FR | 12 | 150 | 22.2 | 565 | 4.33 | 110 | 11.3 | 288 | 11.6 | 295 | 97.0 | 44.0 | F11 | E |
| 6FM180FR | 12 | 180 | 22.0 | 560 | 4.92 | 125 | 12.4 | 316 | 12.4 | 316 | 114.6 | 52.0 | F11 | E |
Kaiying Power Supply & Electrical Equip Co., Ltd., established in 2001, is a professional valve regulated sealed lead acid battery manufacturer in China. We have a lot of experience in producing high quality products. There is a group of engineers to develop batteries as our clients required.
As the environmental readjusted, Zhangshan Long Way Battery Manufacturing Co., Ltd couldn't produce SLA batteries anymore. The technology and IQC management of Zhangshan Long Way Battery Manufacturing Co., Ltd which had merged with KAIYING GROUP, the Logo LONGWAY is also transferred to the KAIYING GROUP.
Kaiying Power Supply & Electrical Equip Co., Ltd., with a 10, 000 M² Factory space, the company has over 1000 employees and advanced development equipment and comprehensive test facilities. Attaching great importance to quality, our management comply with ISO9001-2000 standard. Our batteries have UL and CE approvals.
During the past several years, the company has gained a very high reputation in the industry with excellent development, production, sales capability and premium quality. So, we got very good market share both in the domestic and foreign markets in the past. OEM orders acceptable.
