12V35ah Solar Gel Deep-Cycle Sealed Battery

Prod Model:	6FM35S
Certificate:	Ce/UL/ISO9001/ISO14001/Ohsas18001
Terminal:	F9 Also Can Be Designed
Color:	Grey or Black
Weight:	10.5kg
Type:	Lead-Acid Batteries
Usage:	Lighting
Nominal Voltage:	12V
Discharge Rate:	Low Discharge Rate
Rechargeable:	Chargeable
Shape:	Rectangle Battery

Product Description

LONGWAY 12volt 35ah maintenance-free rechargeable sealed lead acid gel battery supplier

LONGWAY® Standard battery is design for a general purpose by KaiYing Power.
6FM35G is a general purpose battery up to 8 years in floate service or more than 260 cycles at 100% discharge in cycle service. As with all LONGWAY® Batteries, all are rechargeable highly efficient, leak proof and maintenance free.

Specification
Product type: GEL battery 12V35AH/10hr
Capacity: 35Ah@10Hr-rate to 1.80V per cell@25° C
Weight: Approx. 10.5 kg(23.15lbs)
Maximum Discharge Current: 350A(5sec)
Internal Resistance: Approx. 8.5mΩ Full charged @25° C
Operating Temperature Range:
Discharge: -15° C~50° C
Charge: -15° C~40° C
Storage: -15° C~40° C
Nominal Operating Temperature Range: 25° C± 3° C
Float Charging Voltage: 13.7~13.9VDC/unit Average @25° C
Maximum Charging Current: 8.75A
Equalization and Cycle Service: 14.4V~15.0VDC/unit Average @ 25° C
Self Discharge
LONGWAY Valve Regulated Lead Acid (VRLA) batteries can be stored
For more than 6 months at 25° C. Self-discharge ratio less than 3%
Per month at 25° C. Please charge batteries before using.
Terminal: F9
Container Material: ABS(UL94-HB)
*Flammability resistance of (UL94-V0) can be available upon request

General Features
Ø Stable quality&high reliability
Ø Sealed construction
Ø Environmentally friendly
Ø Maintenance-free operation
Ø Low pressure venting system
Ø Heavy duty grid
Ø Low self discharge
Ø UL component recognition(MH46789)

Applications:
Alarm systems, Cable television, communications equipment, control equipment,
Computers, electronic cash registers, electric test equipment,
Electric powered bicycle and wheel chair,
Emergency lighting systems, fire&security, geophysical equipment,
Marine equipment, medical equipment,
Micro processor based office machines, portable cine&video lights,
Power tools, solar powered systems,
Telecommunications systems, television&video recorders, toys,
Uninterruptible power supplies, vending machines;

Packing and Shipping
Packing Qty: 1 PC/CTN
N. W: 10.5kg
G. W: 11.0KG
Packing carton size: 214*149*226 mm
Lead-time: 1500 PCS for one container
10-25 days after order for the first container, 3-7days for the second container.
Loading Port/Discharge Port: From Xiamen, China to any port in Your country by ship.
Packing: By Carton Box With Wooden Pallet.

We are committed to expert porfessionalism and dependable services.
Any questions, pls feel free to contact us and welcome you!

Standby LONGWAY Standard Series batteries
Battery Model	Nominal Voltage(V)	Nominal Capacity          (AH)	Length		Width		Height		Total Height		Weight(5%)		Terminal
			In	mm	In	mm	In	mm	In	mm	Pound	Kg	Type	Position
6FM1.2	12	1.2	3.86	98	1.71	43.5	2.05	52	2.28	58	1.26	0.57	F1	E
6FM2.2	12	2.2	2.78	70.5	1.87	47.5	3.90	99	4.09	104	1.70	0.77	F1	C
6FM2.4	12	2.4	7.01	178	1.38	35	2.40	61	2.64	67	2.14	0.97	F1	C
6FM2.6	12	2.6	2.78	70.5	1.87	47.5	3.90	99	4.09	104	1.83	0.83	F1	C
6FM3.2	12	3.2	5.28	134	2.64	67	2.34	59.5	2.60	66	2.80	1.27	F1/F2	E
6FM4	12	4	3.54	90	2.76	70	3.98	101	4.21	107	3.15	1.43	F1/F2	C
6FM4.5	12	4.5	3.54	90	2.76	70	3.98	101	4.21	107	3.26	1.48		C
6FM5	12	5	3.54	90	2.76	70	3.98	101	4.21	107	3.57	1.62	F1/F2	C
6FM5A	12	5	5.51	140	1.89	48	4.13	105	4.13	105	3.66	1.66	F2+F1-	C
6FM5B	12	5	5.94	151	2.01	51	3.66	93	3.90	99	3.66	1.66	F1	F
6FM5.5	12	5.5	3.54	90	2.76	70	3.98	101	4.21	107	3.86	1.75	F1/F2	C
6FM5.5A	12	5.5	5.51	140	1.89	48	4.13	105	4.13	105	3.86	1.75	F2+F1-	C
6FM5.5B	12	5.5	5.94	151	2.01	51	3.66	93	3.90	99	3.66	1.66	F1	F
6FM6	12	6	5.94	151	2.56	65	3.70	94	3.94	100	4.30	1.95	F1/F2	F
6FM7	12	7	5.94	151	2.56	65	3.70	94	3.94	100	4.63	2.10	F1/F2	F
6FM7.2	12	7.2	5.94	151	2.56	65	3.70	94	3.94	100	4.74	2.15	F1/F2	F
6FM7.5	12	7.5	5.94	151	2.56	65	3.70	94	3.94	100	4.85	2.20	F1/F2	F
6FM8	12	8	5.94	151	2.56	65	3.70	94	3.94	100	5.07	2.30	F1/F2	F
6FM8E	12	8	5.94	151	2.56	65	3.70	94	3.94	100	5.07	2.30	F1/F2	F
6FM9	12	9	5.94	151	2.56	65	3.70	94	3.94	100	5.73	2.60	F1/F2	F
6FM10A	12	10	5.94	151	2.56	65	4.37	111	4.61	117	6.61	3.00	F2	F
6FM10B	12	10	5.94	151	2.56	65	4.37	111	4.61	117	6.39	2.90	F2	F
6FM10	12	10	5.94	151	3.86	98	3.74	95	3.98	101	6.72	3.05	F2	F
6FM11	12	11	7.13	134	3.15	80	6.34	161	6.50	165	10.10	4.58	F3	C
6FM12	12	12	7.13	151	3.86	98	3.74	95	3.98	101	7.17	3.25	F2	F
6FM14	12	14	7.13	151	3.86	98	3.74	95	3.98	101	8.27	3.75	F2	F
6FM15	12	15	7.13	181	3.03	77	6.57	167	6.57	167	10.14	4.60	F4	D
6FM17	12	17	7.13	181	3.03	77	6.57	167	6.57	167	11.02	5.00	F4	D
6FM18	12	18	7.13	181	3.03	77	6.57	167	6.57	167	11.90	5.40	F4	D
6FM18C	12	18	7.13	181	3.03	77	6.57	167	6.57	167	11.24	5.10	F4	D
6FM20	12	20	7.13	181	3.03	77	6.57	167	6.57	167	12.35	5.60	F4	D
6FM24	12	24	6.89	175	6.54	166	4.96	126	4.96	126	16.76	7.60	F4/F8	D
6FM26	12	26	6.89	175	6.54	166	4.96	126	4.96	126	18.96	8.60	F4/F8	D
6FM28	12	28	6.89	175	6.54	166	4.96	126	4.96	126	19.84	9.00	F4/F8	D
6FM28A	12	28	6.50	165	4.96	126	6.89	175	7.01	178	18.74	8.50	F14/F9	D
6FM30	12	30	7.68	195	5.12	130	6.34	161	6.54	166	20.94	9.50	F9/F15	C
6FM33	12	33	7.68	195	5.12	130	6.34	161	6.54	166	22.49	10.20	F9	C
6FM35	12	35	7.68	195	5.12	130	6.34	161	6.54	166	23.15	10.50	F9	C
6FM38	12	38	7.80	198	6.54	166	6.69	170	6.69	170	28.66	13.00	F9	D
6FM40	12	40	7.80	198	6.54	166	6.69	170	6.69	170	29.76	13.50	F9	D
6FM45	12	45	7.80	198	6.54	166	6.69	170	6.69	170	30.86	14.00	F9	D
6FM50	12	50	9.02	229	5.43	138	8.19	208	8.39	213	37.04	16.80	F9	C
6FM55	12	55	9.02	229	5.43	138	8.19	208	8.39	213	38.58	17.50	F9	C
6FM60	12	60	10.20	259	6.65	169	8.19	208	8.39	213	47.40	21.50	F9	C
6FM65	12	65	13.78	350	6.50	165	7.17	182	7.17	182	46.30	21.00	F6/F9	C
6FM70	12	70	10.20	259	6.65	169	8.19	208	8.39	213	47.40	21.50	F9	C
6FM75	12	75	10.20	259	6.65	169	8.19	208	8.39	213	50.71	23.00	F9	C
6FM80B	12	80	10.20	259	6.65	169	8.19	208	8.39	213	51.81	23.50	F9	C
6FM80	12	80	12.09	307	6.57	167	8.27	210	8.46	215	55.12	25.00	F9	C
6FM90	12	90	12.09	307	6.57	167	8.19	208	8.39	213	58.42	26.50	F9	C
6FM95	12	95	12.09	307	6.57	167	8.19	208	8.39	213	59.52	27.00	F9	C
6FM100H	12	100	12.99	330	6.81	173	8.62	219	8.82	224	66.14	30.00	F11	C
6FM100E	12	100	12.99	330	6.81	173	8.62	219	8.82	224	65.04	29.50	F11	C
6FM120	12	120	15.94	405	6.81	173	9.33	237	9.33	237	77.16	35.00	F11	C
6FM120E	12	120	12.99	330	6.81	173	8.62	219	8.82	224	68.34	31.00	F11	C
6FM134	12	134	13.43	341	6.81	173	11.14	283	11.34	288	91.49	41.50	F10	C
6FM150	12	150	19.02	483	6.69	170	9.49	241	9.49	241	97.00	44	F11	C
6FM160	12	160	13.43	341	6.81	173	11.14	283	11.34	288	99.21	45	F10	C
6FM200	12	200	20.55	522	9.45	240	8.62	219	8.82	224	132.28	60	F11	E
6FM200E	12	200	20.55	522	9.45	240	8.62	219	8.82	224	134.48	61	F11	E
6FM230	12	230	20.51	521	10.59	269	7.99	203	8.19	208	145.51	66	F11	F
6FM250	12	250	20.47	520	10.59	269	8.66	220	9.65	245	154.32	70	F11	E
