132kv Model Gw7-132kv Outdoor High Voltage Disconnector/ Isolator Switch

Name: 132kv Model Gw7-132kv Outdoor High Voltage Disconnector/ Isolator Switch
Brand: all-electronics-online.com
SKU: 614532835
Availability: InStock
Rating: 4.6 (38 reviews)

Price:	Negotiable/Piece
Trade Terms:	FOB,CFR,CIF
Min Order:	10/Piece
Pay Type:	L/C,T/T,D/P

Contact Supplier

Showroom Product Company Profile

Prod Model:	GW7-132kv
Markets:	North America,South America,Eastern Europe,Southeast Asia,Africa,Oceania,Mid East,Eastern Asia,Western Europe
Outdoor Installation:	Three Phase
Type:	High-voltage
Structure:	Three-column Disconnector
Installation:	Outdoor High-voltage
Operation:	Manual
Grounding:	Single Ground
Series:	Single-Stage
Run:	Turn the Horizontal
Switching Mode:	Single Throw-in
Certification:	ISO
Common Model:	Gn10
Brand:	Haivol

Product Description

Outdoor Isolator Switch 132kv Model Gw7-132kv
GW7 series Isolator switch(disconnectors) are outdoor 3-phase high voltage equipment. They are used to change over power circuit and electrically isolate the repaired equipment under no-load condition. GW7 are type of 3 poles centre rotating and double horizontal breaks.

Technical specification:
Outdoor, double break, with earthing switch complete 3 phase with steel structure:
Rated voltage: 132KV
Highest system voltage: 145KV
Insulation level: ( 275 -650 ) KV
Frequency: 50Hz
Creepage distance: 31.5mm/KV
Rated current: 1600A
Rated short time current: 40KA for 1 Sec
Terminal: Line isolator / Bus bar isolator
Operating mechanical: Manual & electrical (110V D. C motor).
Complete with all electrical & mechanical interlocking

Haivo Electrical Co., Ltd, is a provider of power equipment and services for the global electric utility industry. It mainly manufacture power transmission & distribution equipments, covering many product series as Fuse cutout, Surge arrester, Composite & Porcelain insulator, Disconnector switch & Load Break Switch, Hardware fitting for overhead line, Cable accessories and Cable kits (cold & heat shrinkable cable accessories).

HAIVO ELECTRICAL, As one of the international electrical companies in China, We not only manufacture the power equipment, but also provide sustainable power solutions underpinned by technology innovation. To date, HAIVO conducts business in nearly 50 countries and territories in South America, Europe, Latin America, Asia, Africa, and the Middle East. HAIVO′ S high standards have received due recognition from the local power customers.

HAIVO′ S worldwide operation and sales coverage is backed by exceptional experience and expertise to provide customers with the most reliable and highest quality products and services available.

For the quality control system, HAIVO was successively awarded ISO 9001: 2008 by DAS CERTIFICATION Ltd & UKAS QUALITY MANAGEMENT, and TYPE TEST REPORT by China NATIONAL HIGH VOLTAGE APPARATUS QUALITY SUPERVISION TESTING CENTER(XIHARI) & QUALITY INSPECITION AND TEST CENTER FOR EQUIPMENT OF ELECTRIC POWER.

We promise we will offer first-class quality, reasonable price, first-class service and following the business philosophy of development and innovation to serve global power customers!
