| Prod Model: |
FGET-150AH1 |
| Item Name: |
Deep Cycle Battery |
| Maintenance Type: |
Free |
| Size: |
483*170*241*241mm |
| Weight: |
43kg/PCS |
| Material: |
Fire Proof Case |
| Warranty: |
5 Year |
| Plate: |
Flat Plate |
| Terminal Type: |
Copper/Lead |
| Certificate: |
Ce, UL.ISO.PV |
| Cell: |
6 |
| Type: |
Lead-Acid Batteries |
| Usage: |
Storing Energy |
| Nominal Voltage: |
12V |
| Discharge Rate: |
High Discharge Rate |
| Shape: |
Square Battery |
| Rechargeable: |
Chargeable |
Product Description
Future Green
150ah Deep Cycle AGM Lead Acid Storage Gel Battery Gel battery description:Gel solar battery accumulator shows some distinctive advantages over flooded battery or AGM battery, such as super thermal stability, high deep discharge capability, good recovery from deep discharge, even if the battery is left discharged for three days, it will recover to 100% of capacity.
With the above-mentioned advantages, the gel battery has long service life, specially suitable for motive power applications, such as golf trailer, folklift, etc. The deep discharge cycles increased 50% as compared with the AGM battery.
| Nominal Voltage | 12V |
| Capacity (10 hr 25 ) | 120Ah |
| Design Life | 5 Years |
Dimensions | Length | 409 mm (16.1 inch) |
| Width | 176 mm (6.93 inch) |
| Height | 225 mm (8.86 inch) |
| Total Height | 225 mm (8.86 inch) |
| Approx.Weight | 35 Kg |
Capacity 25 (77 ) | 10 hr rate | 120Ah |
| 3 hr rate | 96Ah |
| 1 hr rate | 78Ah |
| Internal Resistance (Full charged Battery at 25 (77 ) | 4 m |
Capacity affected
by Temperature (20hr) | 40 | 102% |
| 25 | 100% |
| 0 | 85% |
| -15 | 65% |
Self-Discharge at | 3 month | Remaining capacity: 91% |
| 6 month | Remaining capacity: 82% |
| 12 month | Remaining capacity: 65% |
| Normal operating temperature | 25 3 (77 5 ) |
| Operating temperature range | -15 ~50 (5~122 ) |
| Float charging ) | 13.6 to13.8V |
| Cyclic charging ) | 14.5 to 14.9V |
| Maximum chaging current | 32A |
| Terminal material | Pb |
| Maximum Dischage current | 800A(5sec) |
Applications: - Solar and wind systems
- Cable TV
- Telecommunications
- Wheelchair
- Marine Equipment
| - Military Equipment
- Emergency lighting
- Power Plants
- Medical Devices
- Golf Cart
|
Use and Maintenance:1) Please use constant-voltage charge.
2) In floating charge, the voltage is 2.23 to 2.27 per unit cell.
3) In cycle use, the voltage is 2.35 to 2.45 per unit cell, the max. Current is no more than 25%° C
4) Please do tighten the bolts to avoid sparkle and poor contact when the battery is in use.
5) Please do not use it near the heat source and open flame.
6) Please keep it at low temperature. Please change it while there is liquid leaking or damage.
| Gel battery series |
| Model | Voltage | Capacity
C20 | Dimension & Weight | Approx .weight | Terminal
Type |
| Length | Width | Height | Totl height |
| (V) | (h) | mm | mm | mm | mm | Kg |
| GE6V180Ah | 6 | 180 | 260 | 182 | 245 | 288 | 23.00 | F6 |
| GE6V210Ah | 6 | 200 | 260 | 182 | 247 | 289 | 30.00 | F6 |
| GE6V225Ah | 6 | 225 | 321 | 176 | 226 | 246 | 31.00 | F6 |
| GE8V210Ah | 8 | 210 | 260 | 182 | 295 | 336 | 36.00 | F6 |
| GE12V33Ah | 12 | 33 | 195 | 130 | 159 | 180 | 9.50 | F5 |
| GE12V40Ah | 12 | 40 | 197 | 165 | 175 | 182 | 13.00 | F5 |
| GE12V60Ah | 12 | 60 | 260 | 168 | 211 | 233 | 20.00 | F6 |
| GE12V70Ah | 12 | 70 | 260 | 168 | 211 | 233 | 21.50 | F6 |
| GE12V100Ah | 12 | 100 | 331 | 171 | 214 | 224 | 30.00 | F6 |
| GE12V120Ah | 12 | 120 | 407 | 174 | 225 | 238 | 33.50 | F6 |
| GE12V150Ah | 12 | 150 | 483 | 170 | 241 | 241 | 44.00 | F6 |
| GE12V200Ah | 12 | 200 | 522 | 240 | 219 | 244 | 57.00 | F6 |
| GE12V250Ah | 12 | 250 | 520 | 268 | 220 | 249 | 67.00 | F6 |
| GE12V55Ah-F | 12 | 55 | 277 | 106 | 222 | 222 | 16.50 | F6 |
| GE12V80Ah-F | 12 | 80 | 564 | 115 | 189 | 189 | 25.50 | F7 |
| GE12V100Ah-F | 12 | 100 | 395 | 110 | 285 | 285 | 30.00 | F9 |
| GE12V150Ah-F | 12 | 150 | 551 | 110 | 287 | 287 | 48.00 | F9 |
| GE12V180Ah-F | 12 | 180 | 546 | 125 | 317 | 323 | 53.00 | F9 |
| GE2V200Ah | 2 | 200 | 173 | 111 | 330 | 364 | 13.50 | F6 |
| GE2V300Ah | 2 | 300 | 171 | 151 | 330 | 364 | 20.00 | F6 |
| GE2V500Ah | 2 | 500 | 241 | 171 | 330 | 365 | 31.00 | F6 |
| GE2V600Ah | 2 | 600 | 302 | 175 | 330 | 367 | 37.00 | F6 |
| GE2V800Ah | 2 | 800 | 410 | 175 | 330 | 365 | 50.00 | F6 |
| GE2V1000Ah | 2 | 1000 | 475 | 175 | 330 | 367 | 60.00 | F6 |
| GE2V1500Ah | 2 | 1500 | 400 | 350 | 345 | 382 | 95.00 | F6 |
| GE2V2000Ah | 2 | 2000 | 490 | 350 | 350 | 382 | 120.00 | F6 |
Factory Show:
Packing Details:
Our Qualification:
Our Services:
Samples and OEM, Warranty and After-Sale Service:
- Sample can be provided for quality testing
- OEM Welcomed
- Warranty:2 Year
- After-Sale Service: 24 Hour-Hot Line for Consultacncy and Technical Support
