150W 12V Waterproof LED Driver Bg-150-12 with Ce RoHS Approved IP68

Name: 150W 12V Waterproof LED Driver Bg-150-12 with Ce RoHS Approved IP68
Brand: all-electronics-online.com
SKU: 821063355
Availability: InStock
Rating: 4.6 (71 reviews)

Price:	US $ 13-20/Piece
Min Order:	1/Piece
Pay Type:	L/C,T/T,D/P,Western Union,Paypal

Contact Supplier

Showroom Product Company Profile

Prod Model:	BG150W-12V
Output Type:	Single
Output Power:	101 - 200W
Input Voltage:	110-220V
Connection Mode:	Series Switching Power Supply
Starting Mode:	Self-excited Switching Power Supply
Voltage Regulating Mode:	Width Modulation Type
Power Supplying System:	Terminal Power Distribution Equipment
Certification:	RoHS
Warranty:	Lifetime Warranty
Brand:	Waw

Product Description

Product Description
150W 12V waterproof LED driver BG-150-12 with CE ROHS approved IP68

Features

1.High Efficiency and good price

2.Built-in EMI filter

3.100% full load burn-in test

4.Low output ripple and noise
5.Protection:Over load/Over voltage/Short circuit

6.LIFETIME WARRANTY

Specifications

Model	BG-150-12	BG-150-24
DC output voltage	12V	24V
Output voltage error	±10%	±10%
Rated output current	12.5A	6.2A
Output current rage	0-12.5A	0-6.2A
Wave and noise	120mVp-p	150mVp-p
Inlet stability	±0.5%	±0.5%
Load stability	±1%	±0.5%
DC output power	150W	150W
Efficiency	81%	83%
AC input voltage range	90~132VAC/176~264VAC 47~63Hz

AC impulse current	Cold-start current 30/230V
Leakage current	<0.75mA/240VAC
Over load protection	105%~150% rated output power
	Protection:Hiccup mode,recover automatically
Over voltage protection	13~16V	28~32V
	Protection:Shut down output voltage
Short circuit protection	Protection:Hiccup mode
Temperature coefficient	±0.03%(050)
Setup rise hold up time	200ms,100ms,30ms
Vibration	10~500Hz,2G 10min./1cycle,Period for 60min,Each axes
Withstand voltage	I/P-O/P:2.5KVAC I/P-FG:2KVAC O/P-FG:0.5KVAC
Isolation resistance	I/P-O/P:100M Ohms / 500VDC / 25 / 65% RH
Working temperature and humidity	-10+50,20%90%RH
Store temperature and humidity	-20+85,10%95RH
Overall dimension	2226842mm
Weight	1.3KG
Safety standards	Desgin refer to UL1012,EN60950-1,EN61347-1,EN-61347-2 approved
EMC	EN55015,EN55022,EN55024,EN61000-2,EN61000-3,EN61547 approved
