150W DC to AC Pure Sine Wave Car Inverter

Name: 150W DC to AC Pure Sine Wave Car Inverter
Brand: all-electronics-online.com
SKU: 831156595
Availability: InStock
Rating: 4.8 (93 reviews)

Price:	US $ 36-39/Piece
Min Order:	100/Piece
Pay Type:	L/C,T/T

Contact Supplier

Showroom Product Company Profile

Product Description

Product Description
CE,RoHS,ISO 9001 approved off grid sine wave inverters.
Manufacturer of power inverters located in Zhejiang,China.
Provide various inverters from 150w to 6000w.

Product Features

1. Pure sine wave output
2. Strong ability of impact resistance
3. Protection against overload, short-circuit, overvoltage, under-voltage and over-temperature, etc.
4. Soft start cooling fan .
5. 2 Years warranty , 1%-2% spare parts .

There are full protection and audio-visual alarm system in the power inverter. It can provide a full range of protection, mainly over-voltage protection, low-voltage alarm, under-voltage protection, over-heat protection, overload protection, short circuit protection etc.
Protection
.Buzzer alarm
.Soft start
.Reverse polarity
.Grounding protection
.Over-load protection
.Low-voltage protection
.Over-voltage protection
.Short-circuit protection
.Over-temperature protection
.Auto reset after being in protection

Technical Parameters

Model		CZ-150S
Input	DC voltage	12V	24V	48V	110V
	Voltage range	10-16VDC	20-33VDC	40-63VDC	90-130VDC
	No load current draw	0.7A	0.4A	0.2A	0.1A
	Efficiency	>90%
	DC connection	Cables With Clips or Car Adaptor
Output	AC voltage	100/110/120VAC or 220/230/240 VAC
	Continuous power	150W
	Surge power	300W
	Waveform	Pure sine wave
	Frequency	50Hz or 60Hz
	AC regulation	3%
Protection	Low voltage alarm	10.5DC±0.5V	21DC±1V	42VDC±1V	96VDC±3V
	Low voltage shut down	10DC±0.5V	20DC±1V	40VDC±1V	90VDC±3V
	Short circuit	Shut off output automatically
	Over load	Shut off output
	Over voltage shut down	16±0.5V	33±1V	63±1V	130±3V
	Over thermal	Shut off output automatically
Environment	Working temperature	between -10ºC and +50ºC
	Working humidity	20%~90%RH
	Storage temperature	between -30ºC and +70ºC
Package	Machine size(mm)	20010560
	Packing size(mm)	275160113
	Net weight(kg)	0.86
	Gross weight(kg)	1.13
	Packing mode	Carton packaging
Other	Start	Soft start
	Cooling ways	Intelligent cooling fan
