15gq22-B Panel Mount Roller Plunger Type Micro Switch

Name: 15gq22-B Panel Mount Roller Plunger Type Micro Switch
Brand: all-electronics-online.com
SKU: 727663802
Availability: InStock
Rating: 4.7 (57 reviews)

Price:	US $ 1.6-2.25/Piece
Min Order:	10/Piece
Pay Type:	L/C,T/T,Western Union,Paypal,Money Gram

Contact Supplier

Showroom Product Company Profile

Prod Model:	NM-1308
Pressing Type:	Lever Roller
Protection:	Waterproof
Size:	Small-Sized
Environment:	﹤250℃
Breaking Capacity:	Micro-Current
Breaking Form:	Single Type
Application:	Electronic Equipment
Brand:	Chnanma

Product Description

Adopt thermostable phenolic plastic crust;
Small contact gap,snap action,high sensitivity and small operating travel;
Variety of levers;
Widely used in appliance, electronic equipment,automatic machine,communication equipment,car electric,apparatus and instrument,electro tool etc.

Product picture

Max	350-450g(3.43-4.41N)
RF Min	114g(1.12N)
PT Max	0.5mm
OT Min	4mm
MD Max	0.1mm
OP	31.2±1.2mm

Specification

Item		Data
Operating speed		0.1mm-50cm/s
Operating frequency	Mechanical	20times/min
Operating frequency	Electrical	20times/min
Insulation resistance		100MΩ(Above)DC500V
Contact resistance		25MΩ(intial value)
Withstand voltage	Non-connection wire	1000VAC(keep on working 1min)
Withstand voltage	Every terminal	2000VAC(keep on working 1min)
Vibration	Misoperation	10-55Hz Amplitude 1.5mm
Impact	Durable	1000m/s²
Impact	Misoperation	300m/s²
Life	Electrical	200,000above
Life	Mechanical	2,000,000above
Pertection degree		IP40
Operating temperature		-25'C~80'C
Operating humidity		≤85%

Rating

Ue(V)	LE(A)	Ith(A)
AC-25	15	20
DC-125	15	20
DC-250	0.3	0.45
DC-125	0.6	0.75
