Name: 15kv, 30kv Power Cable, 1c500sqmm
Brand: all-electronics-online.com
SKU: 711402602
Availability: InStock
Rating: 4.4 (25 reviews)

Price:	Negotiable/Meter
Min Order:	500/Meter
Pay Type:	L/C,T/T

Contact Supplier

Showroom Product Company Profile

Prod Model:	YJV
Voltage:	Low and Medium Voltage Cable
Insulation Material:	XLPE
Certification:	CE
Brand:	Yifang

Product Description

Product Description
Rated voltage: 6/10KV; 8.7/15KV;12/20KV;18/20KV;21/35KV,26/35KV

No. of cores: single or 3 cores

Cross section:

25mm2;35mm2;50mm2,70mm2,95mm2,120mm2,150mm2,185mm2,240mm2,300mm2,400mm2,500mm2,630mm2,800mm2.

Characters of XLPE Cable:

a.Max Long-time operating temperature of XLPE insulated cable is 90°C

b.Installing temperature of cable should not be less than 0°C

c.Max short-circuit temperature is not exceed 250°C,Not more than5 Sec.

d.Unable be laid without the limit of fall with enough mechanical pull,Single core cable can not be laid in iron tube or fixed by circled iron tools around cables

Zhengzhou Yifang Cable Co., Ltd is a large joint-stock\hi-tech enterprise established in 1988. We are specialized in wires & cables, including designment, production and sales.

There are more than 500 staffs in our factory including over 50 technical personnel, 5 senior engineers. With complete advanced cable producing equipments over 150 sets, complete testing equipments, a national level fire-resistant & flame retardant cable laboratory. Our technology has reached advanced levels at home and abroad.

Our main products include: Power Cable for voltage up to 220KV, Overhead insulated cable, ABC Cable, Building Cable and flexible cord, Control Cable, Rubber Cable, Bare Conductor(ACSR, AAC, AAAC, BCC), Welding Cable, Galvanized Steel Wire(Stay wire), flame retardant mining cable, etc

We have own IM/EX right, our products have been exported to Europe, Australian, Middle-east, South-east Asia, Africa, American, South American etc., being subjected to consistent good opinion of customers.
