15W 70mm AC Induction Motor with Square Head

Name: 15W 70mm AC Induction Motor with Square Head
Brand: all-electronics-online.com
SKU: 743453385
Availability: InStock
Rating: 4.3 (51 reviews)

Price:	US $ 41.3-49.7/Piece
Trade Terms:	FOB,CIF,DAP
Min Order:	10/Piece
Pay Type:	T/T,Paypal

Contact Supplier

Showroom Product Company Profile

Prod Model:	3IK15GN-A
Markets:	North America,South America,Eastern Europe,Southeast Asia,Africa,Oceania,Mid East,Eastern Asia,Western Europe
All Technical Data:	Can Be Customized
Size:	70m with Square Head
Number Of Stator:	Single-Phase
Function:	Driving
Brand:	GS

Product Description

15W 70mm AC Induction Motor

Introduction
Generally, Micro Induction Motor refers to the motor rotated by the induction. Induction Motor relies on capacitor and electromagnetism when starting and rotating. Though its starting torque is not very high, it has a simple structure, high efficiency and can rotate continue.

Specifications
1. Dimensions of device: 70mm
2. Rated Power: 15W
3. Voltage: 110/120/220/230V
4. CCC, CE, UL, CU
5. Can be customized

Greensky's Advantage
On the site you can find a range of renewable products including ac/dc motor, induction motor, reversible motor, brake motor, speed control motor, ac angel motor, gear motor, planetary gearbox, worm gearbox and their relevant components.

If you have any other questions, please feel free to contact us.

Model		Output power W	Voltage V	Frequency Hz	Current A	Starting Torque mN.m	Rated Torque mN.m	Rated Speed r/min	Capacitor μF
Pinion Shaft	Round Shaft
3IK15GN-A	3IK15A-A	15	1ph100	50	0.35	90	125	1200	6.0
				60	0.33	85	105	1450
3IK15GN-E	3IK15A-E	15	1ph110	60	0.30	65	105	1450	5.0
			1ph120		0.32
3IK15GN-C	3IK15A-C	15	1ph220	50	0.18	90	125	1200	1.2
			1ph230		0.20
3IK15GN-H	3IK15A-H	15	1ph220	60	0.16	65	105	1450
			1ph230		0.15	70
3IK15GN-S	3IK15A-S	15	3ph220	50	0.14	220	125	1200	_
				60	0.12	180	105	1450

About Greensky Mechanical

History: Greensky Mechanical was founded in 2012 with purchasing of a 15 year old cooperative factory in Zhejiang Province. Greensky Power brought new management concept to the new joint company and increase the quality of the motors as Greensky Power only provides best quality and best service to the society.

Introduce: Greensky Mechanical Co., Ltd is a subsidiary company of Greensky Power which is producing AC and DC gear motor, gearbox and motor, and it has capability to design and develop customized product with high quality.

Philosophy: We save cost by increasing the efficiency of production and delivery. "Once and forever" is our goal to serve customers in the world. Once we do business with customer, we will do business forever.

GS motor makes the cool mechanism human by progress in thchnology and products innovation. GS bases on talents. Products are the morality of man. Wisdom and passion of us are the core power. GS

Motor has made her own stronger through the long-term experience and exerise. GS believes that we raise ourself continuously in future. GS will go on innovating forever.
