| Prod Model: |
GOT08 |
| Markets: |
North America,South America,Eastern Europe,Southeast Asia,Africa,Oceania,Mid East,Eastern Asia,Western Europe |
| Model Number: |
Got08 |
| Color: |
Black |
| Weight: |
69g |
| GSM Frequency: |
850/900/1800/1900MHz |
| Network: |
GSM |
| Number Of SIM Card: |
One Piece |
| GPS Accuracy: |
5-15 Meters |
| Application: |
Car Bus Truck |
| Working Voltage: |
12/24 V DC |
| GPS Antenna: |
Internal |
Product Description
Product Features
*Supports quad bands, i. e. 850/900/1800/1900MHz, worldwide used.
*Plug and play, free installation.
*GPS precise positioning with A-GPS and uploaded by GPRS regularly
*Supports real-time tracking and history track playback.
*Web browser platform, Smart phone app platform and SMS query.
*Built-in battery, Power disconnect alarm & Low battery alarm.
*Supports multiple alarm, Built-in acceleration sensor with vibration, collision and falling alarm.
*Multiple protocol support, OTA upgrade program.
Alarm Type
Vibration Alarm
Collision / falling Alarm
Speed Alarm
Geo-fence Alarm
Unplugging Alarm
Low battery Alarm
Base Specification
GPS positioning accuracy 5-15m (Depend GPS signal)
GSM positioning accuracy 100-1000 m(Depending on density of base stations)
GPS Frequency 1575MHz
GSM Frequency 850/900/1800/1900MHz
Hot/warm/cold start time <3s, <15s, <60s
Battery capacity 550mAh
Dimensions (mm) 70(L)X48.5(W)X16.8(H)
Operating temperature -20º C~70º C
Operating humidity 20%~80%RH
Net Weight 69 g
Typical Application Areas
Logistics enterprises,
Fleet management,
Bus management
Insurance
Power
Oil
Telecommunications
Taxi
Car sales
Car rental
Vehicle maintenance
Technology researchers
Installation
How to find your OBDII Connector?
Start by looking around the underside of your dashboard, below your steering wheel but above your gas and brake pedals. The diagram below will show you the general area to search. The connector may be covered by a small flap, but will usually be visible without requiring any disassembly.
Installing the OBDII-GPS
Once the OBDII connector has been located, all that is required is to plug the OBDII-GPS into the connector. Once you turn the ignition of the vehicle on, the small lights on the unit will blink. During your first installation, you will need to give the OBDII-GPS unit a minimum of 15 minutes fully initialize.
Platform
You can choose Keelin terminal monitoring platform or not. It is designed by EELINK, we can position, playback the cars' track, listen and cut off oil of car on the platform server.
If you have a business in which you need to regularly check out that for which purposes the cars or other vehicles are used then definitely gps tracking solutions will help you. GPS tracking solutions available at Eelink when purchased in bulk can be useful in knowing the exact position of all the cars which are used for the different business purposes. You can always order for gps tracking solutions in bulk to save money.
| Base Specification |
| GPS positioning accuracy | 5-15m (Depend GPS signal) |
| GSM positioning accuracy | 100-1000 m
(Depending on density of base stations) |
| GPS Frequency | 1575MHz |
| GSM Frequency | 850/900/1800/1900MHz |
| Hot/warm/cold start time | <3s,<15s,<60s |
| Battery capacity | 550mAh |
| Dimensions (mm) | 56.5(L)X47(W)X 24.6(H) |
| Operating temperature | -20~70ºC |
| Operating humidity | 20%~80%RH |
| Net Weight | 69 g |
Shenzhen Eelink Communication Co. Ltd was founded in June 2004 aiming at technology Innovative. After 10 years development, we accumulate more and more experienced experts and senior engineers specializing in Internet Platform/APP/GPS trackers. Now we have a professional technology team engaged in software, hardware and industrial design, totally more than 50 engineers. This professional team guarantee technology advancement for Eelink products. Meanwhile we have advanced management system, complete QC and QA systems as well as strict testing methods to guarantee high quality.
Shenzhen Eelink Communication Co. Ltd can provide: GPRS+GPS tracker, WCDMA+GPS tracker, GPRS+Beidou tracker, Plug-in and play OBD vehicle tracker, Plug-in and play OBD diagnostics vehicle tracker, intelligent terminal for real time temperature and humidity checking. Our products are widely used in positioning and tracking vehicle, personal, pet and assets. This will realize the management for vehicle, person and cargo meanwhile the complete care for the elder and child. Eelink can truly understand your specific needs and complete different clients' Requirements in terms of new designs, high quality and large production, you will also enjoy the service of internet platform and smart phone APP for your GPS tracker.
We hold the faith to meet every customer' S needs to gain 100% customer satisfaction on quality products and after-sale service.
