16mm Micro Planetary Gear Motor
| Price: |
US $ 1/Piece |
| Trade Terms: |
FOB,CFR,CIF |
| Min Order: |
1/Piece |
| Pay Type: |
L/C,T/T,D/P |
| Prod Model: |
YG16 |
| Markets: |
North America,South America,Eastern Europe,Southeast Asia,Africa,Oceania,Mid East,Eastern Asia,Western Europe |
| Model Number: |
N20 |
| Motor Type: |
Brushless DC Motor |
| Torque: |
5(Nm) |
| Speed(Rpm): |
0~5000(Rpm) |
| Voltage(V): |
3\6\12\24(V) |
| Output Power: |
40(W) |
| Place Of Origin: |
Hangzhou |
| Usage: |
Electric Curtain |
| Structure And Working Principle: |
Brushless |
| Operating Speed: |
Low Speed |
| Application: |
Power Tools |
| Excitation Mode: |
Excited |
| Brand: |
Lectstyle |
Product Description
Basic Info.
Model NO.:D163 Fuel:Planet Gear MotorSize:16mm Export Markets:GlobalAdditional Info.
Trademark:I. CH Packing:Carton or PalletOrigin:China HS Code:85011099Production Capacity:100, 000 PCS/YearProduct Description
I. CH motion supply China DC Planetary Gear Motor.I. CH planetary gearbox make use of high precision cutting gears that the most important parts of the planetary gearbox, Our micro DC Planetary Gear Motor are characterized by high precision, high reduction gear ratio, low noise, long service life, large bearing capacity and excellent interruption resistance and quality can replace imports with high-end models in Europe, America, Japan product.
DC Planetary Gear Motor widely applied in office automation, intelligence furniture, production automation, medical equipment, financial machinery and game machine sector, such as automatic window opener, glass curtain wall, auto curtain, bank ATM, automatic cash register, note vending machine, stage lime light and other automatic devices.| GEARBOX MOTOR SPECIFICATION |
| Type | Ratio | 1: 4 | 1: 5 | 1: 15 | 1: 23 | 1: 36 | 1: 57 | 1: 69 | 1: 100 | 1: 129 | 1: 167 | 1: 222 | 1: 267 | 1: 320 | 1: 385 | 1: 415 | 1: 536 | 1: 834 | 1: 1296 |
| D163 | Rated torque | kg. cm | 0.02 | 0.02 | 0.06 | 0.11 | 0.16 | 0.24 | 0.32 | 0.42 | 0.6 | 0.7 | 0.83 | 1 | 1.2 | 1.455 | 1.56 | 2.02 | 2.8 | 3 |
| Rated speed | rpm | 1532 | 1226 | 409 | 267 | 170 | 108 | 89 | 61 | 48 | 37 | 28 | 23 | 19 | 16 | 15 | 11 | 7 | 5 |
| Gearbox | Instantaneous torque | Kg. cm | 1.5 | 2 | 3 | 3.75 | 4.5 |
| Allowable torque | Kg. cm | 1 | 1.5 | 2 | 2.5 | 3 |
| Length | mm | 14 | 17.9 | 21.8 | 25.7 | 29.6 |
| Backlash | O | 0.7 | 0.8 | 1 | 1 | 1.5 |
| Weight | g | 18 | 23 | 28 | 31 | 36 |
| MOTOR DATA |
| Frames volt (V) | No load speed (rpm) | Noroad current (mA) | Rated torsion (g. cm) | Raterd speed (rpm) | Raterd current (mA) | Output power (w) | Weight (g) |
| 1B7K5-12 | 7500 | 20 | 9 | 6130 | 89 | 0.568 | 22 |
| Note: Product voltage, output shaft size, electrical performance, you can request custom-made! |
