| Prod Model: |
LP0037-6600-L |
| Markets: |
North America,South America,Eastern Europe,Southeast Asia,Africa,Oceania,Mid East,Eastern Asia,Western Europe |
| Warranty: |
One Year |
| Delivery Date: |
15days |
| Type: |
Lithium-Ion Battery Pack |
| Connection Mode: |
Series and Parallel |
Product Description
18650 Battery Pack 3.7V 6.6ah Li-ion Battery Pack
Cell: 18650 (High quality Panasonic/Sanyo/Samsung/LG/Chinese A grade or as per special requirement )
Capacity: 6600mAh
Voltage: 3.7V
Battery Pack: 1S3P 3.7V 6.6AH
Pack: PVC Shrink tube
Prewired: 22 AWG wire with connector(as per customer's requirement)
Dimensions: (LxWXH) 69mm x56mm x 20mm
Weight: 180g (About)
Technique:
Charging Voltage: 4.2V CC/CV
Maximal continuous discharging current:2A
Over charge detection voltage: 4.28V ± 0.025V
Over charge release voltage: 4.08 ± 0.025V
Over discharge detection voltage: 2.4V ± 0.05V
Over discharge release voltage: 3.0V ± 0.05V
Over charge protection
Over discharge protection
Over Current protection
Short Protection:
Exterior Short Circuit and can be automatic recovery
Low Interior resistance
Temperature:
Charging temperature: 0 - 45 C degrees
Discharging temperature: -20 - 60 C degrees
Storage temperature: -20 - 45 C degrees
Remark:
The cell can be replaced by other available models such as 14430 14500 18490 18500 and so on, we can make all kinds of customized battery packs.
If you have different requirement on technique, shape and so on for the battery pack, we can made-to-order as per your request.
| 26650/4S2P-12V/6400mAh LiFePO4 Battery Pack |
| Model: |
| Item | Specification | Remark |
| Nominal capacity | 6400mAh | 0.2C discharge Cell: 26650 |
| Nominal voltage | 12V | 3.2V / 1Cell |
| Charging voltage | 14.4V±0.05V | 3.6V / 1Cell |
| Charging method | CC/CV | (Constant-current and -Voltage with Limited current |
| Standard charging time | 2000mA/3.5hour , 3500mA/2hour | Battery capacity÷charging current×1.5 |
| charging current | 3300mA ( 0.5C ) | 0 ~ +40 °C |
| Maximum charging current | 6400mA ( 1C ) | 0 ~ +40 °C |
| Continuous discharge current | 6400mA ( 1C ) | -20 ~ +60 °C |
| Maximum discharge current | 6400mA ( 1C ) | -20 ~ +60 °C |
| Discharge cutoff voltage | 9.2V | 2.3V / 1Cell |
| Short circuit protection | Exterior short circuit | Automatic recovery |
| Internal resistance | ≤ 200mΩ | AC Impedance 1kHz |
| Cycle life | ≥10 00 | |
| Operating temperature | Standard Charge | 0 ~ +40 °C | |
| Standard Discharge | -20 ~ +60 °C | |
| Outline dimension | L106*W54*H72mm | Length x wide x height |
| Pre-wired | | Red = Positive,Black = Negative |
| Protection Circuit Module:PCM-L04S20-292 |
| Balance voltage | | |
| Balance current | | |
| Maximal continuous charging current | 10A | |
| Maximal continuous Discharging current | 10A | |
| Over-charge detection voltage | 3.90±0.025V | single cell |
| Over-charge release voltage | 3.80±0.05V | single cell |
| Over-charge detection delay time | 0.5S_1.5S | single cell |
| Over-discharge detection voltage | 2.30V±0.08V | single cell |
| Over-discharge release Voltage | 2.70±0.1V | single cell |
| Over-discharge detection delay time | 50mS_150mS | single cell |
| Over-current detection | 30±10A | can adjust |
| Over-current delay time | 5ms_15ms | |
