| Prod Model: |
EH5110 Series R1kVA-6kVA RACK UPS |
| Markets: |
North America,South America,Eastern Europe,Southeast Asia,Africa,Oceania,Mid East,Eastern Asia,Western Europe |
| Power: |
1kVA-10kVA |
| Transforter Time: |
Zero |
| Model: |
Bypass Output |
| Technology: |
True Double - Conversion Online UPS |
| Wide Input Voltage Range: |
110-300VAC |
| Protection-1: |
Over Load, Over Temperture . Short Circuit |
| Brand Name: |
Must |
| Size: |
2u or 3u |
| Weight: |
8-41kgs |
| Certificate: |
CE |
| Phase: |
Single Phase |
| Type: |
On-line |
| Protection: |
Overvoltage |
| Brand: |
Must |
Product Description
Home UPS rack UPS
Sine wave output, Zero conversion time
Input zero frontline detection function, Bypass output
TVSS function, Input power correct
DC starting, Bypass protection
Automatic startup function, Long-term type power design
Strong ability to recharge long-term acting machine
Shelf-check function, Powerful anti-jamming
Can match generator
Support inductive load too
Winpower2000 monitoring software free downloads
Provide intelligent slot, Provide standard battery pack
| Model | HR1K | HR1KS | HR2K | HR2KS | HR3K | HR3KS | HR6K | HR6KS |
| CAPACITY | 1000VA/700W | 2000VA/1400W | 3000VA/2100W | 6000VA/4200W |
| INPUT |
| Phase | Single Phase with Ground |
| Frequency Range | 50Hz:46~54Hz |
| Power Factor | >=0.97 | >=0.98 |
| Voltage Range | Base on load percentage (100%-80% / 80%-70% / 70%-60% / 60%-0%) |
| Line Low Transfer | 160VAC/140VAC/120VAC/110VAC± 5VAC | 176 ±3% VAC |
| Line Low Comeback | 175VAC ± 5VAC | 185 ± 3% VAC |
| Line High Transfer | 300VAC± 5VAC | 276 ± 3% VAC |
| Line High Comeback | 285VAC± 5VAC | 266 ± 3% VAC |
| OUTPUT |
| Phase | Single |
| Voltage | 220VAC/230VAC/240VAC |
| Voltage Regulation | ± 2% | ± 1% |
| Frequency( Synchronized Range) | 46~54Hz |
| Frequency( Battery Mode) | 50 ± 0.2 Hz | 50Hz ± 0.5Hz |
| Current Crest Ratio | 3:1 |
| Harmonic Distortion | <= 4% THD ( Linear Load) / <= 7% THD ( Non-Linear Load) | <= 2% THD (Linear Load)/<= 6%THD(Non-Linear Load) |
|
| Output Waveform | Pure Sinewave |
| EFFICIENCY |
| To AC Mode | 85% | 85% | 85% | > 88% |
| To Battery Mode | 83% | 83% | 83% | > 88% |
| BATTERY |
| Battery Type | 12V/7Ah | Depending on the capacity of external batteries | 12V/7Ah | Depending on the capacity of external batteries | 12V/7Ah | Depending on the capacity of external batteries | 12V/7AH | Depending on the capacity of external batteries |
| Numbers of Batteries | 3 | 8 | 8 | 20 |
| Backup Time(Full Load) | >5 minutes | >9 minutes | >5 minutes | 8 minutes |
|
| Recharge Time | 5 hours to 90% | 5 hours to 90% | 5 hours to 90% | 7 hours to 90% |
| Charging Current (Max.) | 1.0A | 7A | 1.0A | 8A+/-1A | 1.0A | 8A+/-1A | 2.0A | 4.2A |
| Charging Voltage | 41.1Vdc ± 0.6V | 110Vdc ± 0.4V | 274Vdc ± 1%V |
| External Battery type | N/A | 12V/7AH*3 | N/A | 12V/7AH*8 | N/A | 12V/7AH*8 | N/A | 12V/7AH*20 |
| TRANSFER TIME |
| AC to DC | Zero |
| Inverter to Bypass | 2.5ms (Typical ) | Zero |
| INDICATOR |
| Status | Load Level / Battery Level / Battery Mode / AC Mode / Bypass Mode / Fault |
| AUDIBLE ALARM |
| Battery Mode | Sounding every 4 seconds |
| Low Battery | Sounding every second |
| Overload | Sounding twice every second |
| Fault | Continuously Sounding |
| DIMENSION |
| UPS CaseD x W H(mm) | 450x482.6x88 | 450x482.6x88 | 600x482.6x130 |
| Battery Case D x W x H | N/A | 450*482.6*88 | 450*482.6*88 | 600*482.6*130 |
| WEIGHT |
| UPS Case (kgs) | 14(w / battery) | 7 | 34.5(w / Battery) | 15 | 35.5(W / Battery) | 16 | 84(W / Battery) | 35 |
| Battery Rack (kgs) | N/A | 22.5 | 27.8 | 27.8 | 64.2 |
| ENVIRONMENT |
| Operating Environment | 0~40 °C, 20~90% relative humidity (non-condensing) |
| Noise Level | <45dB @ 1 Meter | 50dB @ 1 Meter | <55dB @ 1 meter |
| INTERFACE |
| Smart RS-232 | Windows 98/NT/2000/XP/2003, Linux, Sun Solaris, IBM Aix, Compaq True64, SGI IRIX, FreeBSD, HP-UX, and MAC |
| SNMP (option) | Power management from SNMP manager and web browser |
