0.1UF 50V 4*7mm Aluminum Electrolytic Capacitors
| Price: |
US $ 0.01-0.1/Piece |
| Trade Terms: |
FOB,EXW |
| Min Order: |
1000/Piece |
| Pay Type: |
T/T |
| Prod Model: |
TMCE02 |
| Markets: |
North America,South America,Eastern Europe,Southeast Asia,Africa,Oceania,Mid East,Eastern Asia,Western Europe |
| Rated Voltage: |
25V |
| Type: |
Aluminum Electrolytic Capacitor |
| Application: |
General Purpose |
| Package Type: |
Through Hole |
| Capacitance: |
0.1-470UF |
| Tuning: |
Electrolytic Capacitor |
Product Description
Minuaturer Size 7mm Aluminum Electrolytic Capacitor 105C
Features:
1) Wide temperature range -40°C~+85° C
2) Voltage range from 4V - 100V
3) Stable and reliable performances
4) load life of 1000hours at 85c
5)7mmL standard type
6)Applications: VTR,vedio camera,Car radio, microcassette tape recorder,etc
| Items | Characteristics |
| Capacitance Tolerance | ±20% (120Hz, 20ºC) |
|
| Operating temperature Range | -55~+85ºC | -40~+105ºC | -25~+105ºC |
|
| Rated Voltage Range | 4~100V | 4~100V | 450V |
|
| Leakage Current | WV <= 100V, I <= 0.01CV or 3uA(After 2 minutes application of DC working voltage, at 20ºC) |
| WV > 100V, I <= 0.03CV+20 (uA) (After 5 minutes application of DC working voltage, at 20ºC) |
| Dissipation Factor(tan δ) | Measurement Frequency: 120Hz. Temperature: 20ºC |
| Rated Voltage (V) | 6.3 | 10 | 16 | 25 | 35 | 50 | 63 | 100 | 160~250 | 350 | 400~450 |
| tan δ (MAX) | 0.20 | 0.17 | 0.16 | 0.14 | 0.12 | 0.10 | 0.08 | 0.08 | 0.15 | 0.20 | 0.25 |
| When nominal capacitance exceeds 1000uF, add 0.02 to the value above for each 1000uF increase. (20ºC,120Hz) |
| Low Temperature Stability | Measurement Frequency: 120Hz. |
| Rated Voltage (V) | 6.3 | 10 | 16 | 25 | 35 | 50 | 63~100 | 160~250 | 350,400 | 450 |
| Impedance Ratio (MAX) | Z (-25ºC) / Z (20ºC) | 4 | 3 | 2 | 2 | 2 | 2 | 2 | 3 | 6 | 15 |
| Z (-40ºC) / Z (20ºC) | __ | __ | __ | __ | __ | 3 | 3 | 4 | 10 | __ |
| Z (-55ºC) / Z (20ºC) | 8 | 6 | 4 | 3 | 3 | 3 | __ | __ | __ | __ |
| Load Life | 3000 hours, with application of working voltage at 105ºC. |
| Capacitance Change | Within ± 20% of Initial Value |
| tan δ | 200% or less of Initial Specified Value |
| Leakage Current | Initial Specified Value or less |
| Shelf Life | 1000hours, no voltage applied, at 105ºC. After Test:UR to be applied for 30 minutes, 24 to 48 hours before measurement. |
| Capacitance Change | Within ± 20% of Initial Value |
| tan δ | 150% or less of Initial Specified Value |
| Leakage Current | Initial Specified Value or less |
| Standards | JIS C 5141 and JIS C 5102 |
Packing:
Bulk, ammo, tape and reel
| application of DC working voltage, at 20ºC) |
| Dissipation Factor(tan δ) | Measurement Frequency: 120Hz. Temperature: 20ºC |
| Rated Voltage (V) | 6.3 | 10 | 16 | 25 | 35 | 50 | 63 | 100 | 160~250 | 350 | 400~450 |
| tan δ (MAX) | 0.20 | 0.17 | 0.16 | 0.14 | 0.12 | 0.10 | 0.08 | 0.08 | 0.15 | 0.20 | 0.25 |
| When nominal capacitance exceeds 1000uF, add 0.02 to the value above for each 1000uF increase. (20ºC,120Hz) |
| Low Temperature Stability | Measurement Frequency: 120Hz. |
| Rated Voltage (V) | 6.3 | 10 | 16 | 25 | 35 | 50 | 63~100 | 160~250 | 350,400 | 450 |
| Impedance Ratio (MAX) | Z (-25ºC) / Z (20ºC) | 4 | 3 | 2 | 2 | 2 | 2 | 2 | 3 | 6 | 15 |
| Z (-40ºC) / Z (20ºC) | __ | __ | __ | __ | __ | 3 | 3 | 4 | 10 | __ |
| Z (-55ºC) / Z (20ºC) | 8 | 6 | 4 | 3 | 3 | 3 | __ | __ | __ | __ |
| Load Life | 3000 hours, with application of working voltage at 105ºC. |
| Capacitance Change | Within ± 20% of Initial Value |
| tan δ | 200% or less of Initial Specified Value |
| Leakage Current | Initial Specified Value or less |
| Shelf Life | 1000hours, no voltage applied, at 105ºC. After Test:UR to be applied for 30 minutes, 24 to 48 hours before measurement. |
| Capacitance Change | Within ± 20% of Initial Value |
| tan δ | 150% or less of Initial Specified Value |
| Leakage Current | Initial Specified Value or less |
| Standards | JIS C 5141 and JIS C 5102 |
Packing:
Bulk, ammo, tape and reel
Established in 1998, and mainly engaged in manufacturing, researching & developing, and dealing in various capacitor, Shenzhen Topmay Electronic Co., Ltd. is an industrial enterprise with independent corporate entity and has its headquarters located at the flourishing center of Shenzhen, a city has been recognized as the frontier of China economy. After years' persistent hard work by all the companions, Topmay has now developed to be a famous electronic company that promotes very quickly with the most advanced technology.
Topmay has large factories by joint venture. Located in NanTong city. Years' continuous development now provides us with standard workshop of 12, 000 square meters, 6 production lines and 862 employees.
Presently, Topmay products mainly include the following products:
The whole series capacitors Film capacitor, Ceramic capacitor, Tantalum capacitor, Aluminum Electrolytic Capacitor, and etc.
Topmay holds an idea that the products quality is the life of a company. In order to serve our customers better, and to enhance the products grade, Topmay has invested a lot to the application of kinds of international system and quality certifications, and have achieved the following: ISO9001: 2000, ISO14001, Greatwall, CE, SA, UL, TUV, VDE, and etc. Topmay insist on a tenet that people should be oriented, efficiency is the priority, quality should be emphasized, and credit is the uppermost. And we try our best to exploit and to innovate, and keep improving our production technology. So now we gradually grow up to be an outstanding one in our industry. Topmay products are of numerous varieties, compete species, super quality, competitive price and stable function, and all of their indexes have reached the international advanced level.
Topmay takes marketing as the key procedure of the company's entire development. One after another, we attend many global electronics fairs that take place in Munich, Hong Kong, Shanghai, Guangzhou, and Shenzhen. Meanwhile, we get going kinds of driving publication on the well-known B2B websites, such as EbigChina, Made-in-China. com, Globalsources and etc. All these have surely afforded us a good result, a profound influence, and a continuously expanded clients group. At present, Topmay's business primarily concentrates abroad, more than 65%'s export. Because of the super-quality products, the eminent business reputation, the omnibearing technique service and competitive prices, we have established a stable relationship of good cooperation with overseas customers. Now our products have been sold to many distant places, such as USA, Canada, Brazil, Germany, England, France, Spain, Turkey, Russia, Poland, Arabia, Bulgaria, Korean, Malaysia, India, HK, Taiwan, and etc. Namely, a large scope of overseas market has been successfully occupied.
