| Prod Model: |
PLC-12-LCA-12 |
| Package Style: |
Mini Module |
| Configuration Type: |
1X2 |
| Fiber Diameter: |
900μm |
| Pigtail Length: |
1.5m |
| Insertion Loss: |
≤4.2dB |
| Return Loss: |
≥50dB |
| Loss Uniformity: |
≤0.4dB |
| Directivity: |
≥55dB |
| Polarization Dependent Loss: |
≤0.2dB |
| Temperature Dependent Loss: |
≤0.5dB |
| Transmission Medium: |
Single-Mode |
| Structure: |
LC |
| Number Of Cores: |
Single-Core |
| Ferrule Endface: |
APC |
| Connector Type: |
LC/APC |
| Shape: |
Round |
Product Description
1x2 PLC Fiber Splitter, Mini Module, 900μm, LC/APC
Singlemode G.657A1 fiber, 900μm input/output, 1260-1650nm, mainly used in fiber splice closure, optical distribution box and no need to splice in PON system.
Planar lightwave circuit (PLC) splitter is a type of optical power management device that is fabricated using silica optical waveguide technology to distribute optical signals from Central Office (CO) to multiple premise locations.
Mini module PLC splitter has stronger fiber protection than bare fiber splitter, which is a miniaturization result of cassette splitter. It's mainly used for various connection and distribution boxes or network cabinets.
Product Details
| Package Style | Mini Module | Configuration Type | 1x2 |
| Fiber Type | Singlemode G.657A1 | Connector Type | LC/APC |
| Fiber Diameter | 900μm | Pigtail Length | 1.5m |
| Insertion Loss | ≤4.2dB | Return Loss | ≥50dB |
| Loss Uniformity | ≤0.4dB | Directivity | ≥55dB |
| Polarization Dependent Loss | ≤0.2dB | Temperature Dependent Loss | ≤0.5dB |
| Wavelength Dependent Loss | ≤0.3dB | Operating Bandwidth | 1260~1650nm |
| Operating Temperature | -40~85°C | Storage Temperature | -40~85°C |
Quality Control
All products must go through five checks before manufacturing process
1.Material incoming inspection before production
2.Full check after every individual process finished
3.Full check after production half-done
4.Full check before packing
5.Spots check after production packed before shipping
Advantage
1.15 years experience in manufacturing fiber optic products..
2.Availability of R & D with more than 10 engineers.
3.Available of design and making mold with special molding house.
4.High quality, attractive price and fast delivery(2-7days)
5.OEM, ODM customer designs are also welcomed
6.More than 200 workers
7.Excellent survice
