2.0mm Fiber Optic FC PC Fast Connector

Name: 2.0mm Fiber Optic FC PC Fast Connector
Brand: all-electronics-online.com
SKU: 815381705
Availability: InStock
Rating: 4.7 (92 reviews)

Price:	US $ 0.5-1/Piece
Min Order:	1/Piece
Pay Type:	L/C,T/T,Western Union,Paypal,Money Gram

Contact Supplier

Showroom Product Company Profile

Prod Model:	PN876
Housing:	Metal
Color:	Black
Polish:	PC
Cable Diameter:	2.0mm
Tensile:	1000N
Type:	Single-mode Fiber
Connection Structure:	FC
Material Shape:	Round Wire
Allowed Lateral Pressure:	>1000（N/100mm）
Allowed Tensile Strength:	>10000N
Core:	Single Core
Certification:	VDE, CE, RoHS, ISO9001, CCC, UL
Sheath Material:	Metal
Connector Type:	FC Fast Connector
Application:	Art, Sensor, Communication, Probe, Medicine

Product Description

2.0mm Fiber Optic FC PC Fast Connector

Technical Information:
FC PC Fiber optic SC fast connector, angle 80˚ (other on customer's option)(for φ 0.9 tight buffer optical fiber). Optical fast connectors takes use of the latest generation of Terminal technology.After terminating, both optical and mechanical performance reach the standard for patchcord, meet the demand for making patchcord on site by mechanical splicing, have greatly changed the idea in conventional optical splicing, providing the great support to FTTx implementation.

Features/Benefits:
Easy assembly process;
Available in LC, SC, and ST connector styles;
Available in multimode or singlemode versions;
Factory polishing eliminates loss concerns;
No expensive tools required;
Termination can be repeated 2-3 times;
Packaging comes with a cable/buffer stripping template;
Visible Installation quality; independent from any far end light source and special;
Fiber preparation kit available.

Application:
CATV;
Optical access network;
Repair/replacement requirements.

Specifications:

DESCRIPTION
Fiber Type	Singlemode and Multimode
Insertion Loss (Max)*	0.5dB
Insertion Loss (Typical)*	0.3dB
Return Loss (Typical)*	50db/55dB
Polishing Type	UPC and APC

Standard Compliance:
TIA-568-C.3 performance requirements;
Telcordia GR-326 end face geometry;
Telcordia GR-326 service life tests;
IEC61754-20 and TIA-604-10 intermateability.

Item	Technical Parameters
Applicable for	2mm/3mm Indoor cable
Optical fiber diameter	9/125um ( G.652D & G.657 A1)
Tight buffer diameter (um)	900um
Fiber mode	SM, MM
Operation time	About 120s ( no fiber cut )
Insert loss	<= 0.3dB(1310nm & 1550nm)
Return loss	<= -40dB
Fastening strength of naked fiber	>5 N
Fastening strength of naked fiber holder	>10 N
Tensile strength	>50 N

Ordering information:

DESCRIPTION	PART NO.
Multimode PC 62.5/125 Simplex 900um	FC62MM9BGFIC
Multimode PC 62.5/125 Simplex 3mm	FC62MM3BGFIC
Multimode PC 50/125 Simplex 900um	FC50MM9BGFIC
Multimode PC 50/125 Simplex 3mm	FC50MM3BGFIC
Multimode PC 50/125 OM3 Simplex 900um	FCOM3MM9BGFIC
Single mode APC 9/125 Simplex 900um	FCA09SM9GNFIC

Packing Details:
Compliance with the international ISO9001, CE, FCC, RoHS standards. FOCC strict implementation of standardized management and control of the design, development, production, installation and service.
