| Prod Model: |
WTG02 |
| Markets: |
North America,South America,Eastern Europe,Southeast Asia,Africa,Oceania,Mid East,Eastern Asia,Western Europe |
| Style: |
Headset Microphone |
| Application: |
Meeting |
| Signal Transmission: |
Wireless |
| Directivity: |
Uni-direction |
| Sound Channel: |
Mono |
| Connector(',s): |
TRS 3.5 mm |
| Wireless Technology: |
2.4GHz |
Product Description
Brief Introduction:
The system is based on our 2.4GHz wireless technology, which is a free and legal RF range all over the world. It has been widely used by tourist guide of Louvre Museum, Angkor Wat; Also can be used as Simultaneous Translation system; It was also widely used in Audio-visual education system.
It supports independent microphone input and an external audio source such as CD, MP3;
It supports one-to-one and one-to-many modes, and the numbers for receiver can be enlarged according to your needs.
It supports the mute function when there is no signal for the receiver
SOYO-WTG2010-mini, developed by SOYO TECHNOLOGY CO. Ltd on the basis of SOYO-WM24G02, a digital wireless transceiver, is a Hi-fi wireless digital tour guide system with very good resistance to various RF interferences. It is characterized by a lot of advantages, such as small in size, highly integrated, high quality sound (with HDCD sound effect, and the highest sampling ratio in the field of all our modules so far), broad input voltage range (2.5_5Volts), audio output up to 60 mw, input interface compatible microphones and stereo audio input, etc.
The module adopts an international band-- 2.4 G ISM, which is free for the global market.
This product supports fixed ID working mode, both peer-to-peer or to groups, as well as automatic sweep frequency function. It is quite easy and convenient to use. Once ID is paired, the receiver or receivers, placed at random, will receive signals from the RF transmitter automatically. If there is any interference in the current channel, just change the current channel. It features audio muting function in case
There should be no or weak signals There are 20 channels available, the number of which has been the largest in the industry so far. Simultaneous interpretation, Multi-channel player as well as some other applications can also be available by selecting channels manually.
You can adjust the volume with the adjustment button
Features of the wireless transmitter and receiver:
1. Transmit frequency 2400-2480 MHz; Real digital transmit;
2. 30 selectable channels, no need to worry about signal interference. Current channel, battery level status, volume level status can be shown.
3. It can reach up to about 100 meters in an open area;
4. Shortest latency(<0.5ms) in this industry.
5. Ultra-low power consumption, more than 12 hr continuous work time for transmitter, more than 20 hr continuous work time for receiver
6. Powered by 2 AA battery, Recharge is support if your AA battery is rechargeable;
7. Small in size, easy to install, flexible in design and support customization;
8. Audio mute when no signal or weak signal existing;
9. CE / CCC approved.
Specification of the wireless transmitter and receiver:
Carrier Frequency: 2400-2483MHz
Frequency Response: 30Hz-18KHz
Sampling Rate: 16K@16bit*2
Number of Channels: 30
Transmit Power: ≤18dBm
S/N Ratio: ≥75dB
Latency: <0.5ms
Max Operating Range:100 meters
Power Supply: 2* AA battery
Recharge: Support
Where's a tour guide system shall be used?
1. Tour guide systems are used in Tourist Attractions for each tourist hear Commentary clearly.
2. Tour guide systems are used in factories for showing visitors round, for training where machinery noise makes it hard for trainees to hear their instructors.
3. In public meetings as an interpretation system. The interpreter can simply sit at the back of the room and whisper the translation into the microphone.
Tour guide systems operate on different frequencies which means that several different languages can be catered for at the same time.
Soyo Technology development Co. Ltd is a national High-Tech enterprises with certification of software enterprises and products. SOYO owns independent intellectual property rights and the core technology on 2.4G/5.8g digital wireless audio and video transmission technologies. SOYO is well known in Asia-Pacific region as a professional digital wireless audio and video transmission solutions provider, and is committed to creating the best, most complete wireless audio, video and data transmission products and solutions
SOYO Technology was established in 2005, main founder graduated from the Tsinghua University and the University of Science and Technology of China(USTC), has always focused on the development and innovation of 2.4G/5.8G digital wireless audio and video transmission technology. Our products have been sold to over 50 countries and regions, cover four main application areas: Education, Tourism, Professional Audio, Consumer Electronics Field.
In the tourism & Museum industry, SOYO technology offers complete solutions from product to service, include digital wireless tour guide system, digital wireless VIP guide system, Audio guide/Video guide system, 3D video show technology and the related service of the Multilingual audio and video production etc. SOYO believe that we can give the the museum, Science and technology museum, Planning museum, Tourist Attractions the best service and totally solution on the tourism interpretation, wireless tour guide and show, exhibition digitalization and intellectualization. In the professional wireless tourism guide and exhibit explain technology field, SOYO technology has become the largest scale, the most powerful technology, most complete solutions & most perfect after-sales service network.
SOYO have successfully applied the digital wireless tourism guide system and professional exhibit explain loudspeaker system in below famous museum in China:
History museum of Party School of the CPC Central Committee, the British consulate in Shanghai, Museum of Shandong Province, Wuhan Ordnance Officer School History Museum, the Mongolian National Museum, Dalian Sun Asia Sea World, Deng Shichang Memorial museum, Huangpu Ancient village Cultural History Museum, Yanbian Museum, Peking University Library etc., also finished the construction of corporate pavilions of some famous domestic and foreign companies like China's Nuclear Power Group, Porsche (China branch), S. F Express (headquarters), Ricoh China, Mitsubishi Electric Co., Ltd in China, which is the remarkable achievements SOYO made amoung the museum of Chinese tourism industry equipment manufacturers. Soyo also engaged in cooperating with the famous exhibition /museum design company so they can provide professional tour guide and explain solution to the end user to expain what their good design on museum in wireless.
SOYO technology developing rapidly in recent years, has become a national double soft enterprise, national high-tech enterprise, AAA quality credit enterprise in China, achieve the honor of 2011 China venture capital value list new 30 strong entrepreneurship, the third China (shenzhen) innovation contest awards, the first China Tianjin Technology Entrepreneurship Competition Success Endeavour Award. Besides those, SOYO has passed the global wireless certification such as FCC in North American, CE in European Union, TELEC in Japan, Chinese 3C and China radio models approval etc., also gained all the certifications for the global sales of wireless products. We are worthy of being leader in the field of wireless audio and video transmission technology. In May 2013, SOYO officially listed in national financial reform of science and technology demonstration area Qianhai stock trading center, stock code is: 660173.
SOYO would like to share the beauty of Science, Technology and Innovation and create the bright future of the intelligence times with you.
