2.4mm Male to Female RF Coaxial Adapter

2.4mm Male to Female RF Coaxial Adapter
Price: US $ 30-35.2/Piece
Trade Terms: FOB
Min Order: 5/Piece
Pay Type: T/T,D/P
Prod Model: 2.4mm Male to Female
Markets: North America,South America,Eastern Europe,Southeast Asia,Africa,Oceania,Mid East,Eastern Asia,Western Europe
Mating Cycles: >1000 Cycles
Plating Of Pin: Au,Silver

Product Description

2.4 Precision coaxial connector for microwave applications. The maximum frequency is
50GHz.
`Design in accordance with: IEEE287™ -2007
Standard materials and finish
` Center conductor: Beryllium copper, gold plated
` Insulator: PEI
` Outer conductor: Stainless steel, Passivated
Electrical Characteristics
` Characteristic Impedance: 50Ω
` Frequency range: DC-50GHz
` VSWR: 1.15: 1 max
`Insulation resistance: 5000MΩ Min
`Test voltage: 1000V
Mechanical
`Coupling torque: 1.69N*m max
` Mating cycles: 1000cycles min
Environmental
`Temperature range: -55° C~+155° C
Key Specifications (Click on Data Sheet Above for Additional Details) .
Connector Series 12.4mm
Connector Gender 1Female
Connector Polarity 1Standard
Connector Impedance 150 Ohm
Connector Series 22.4mm
Connector Gender 2Female
Connector Polarity 2Standard
Connector Impedance 250 Ohm
Minimum FrequencyDC
Maximum Frequency50 GHz
Adapter Body StyleRight Angle
Connector Mount Method 1None
Connector Body Material 1Passivated Stainless Steel
Connector Mount Method 2None
Connector Body Material 2Passivated Stainless Steel

EZCON Telecom Technology (Changzhou) Co., Ltd. Was formally founded on January 19, 2013, in Changzhou City, Jiangsu Province, Peoples Republic of China. EZCON is a product and solution provider, the company provide high quality, high performance and low cost cable assembly/connector products. EZCON engages in R&D, for telecom and electronics products with focus on RF cable assemblies/connectors, high speed interconnect cable assemblies/connectors and high end test/calibration products. The company has the capacity of product design, engineering service, low cost production/sourcing, assembly, and testing. EZCON combines the advantages of low cost production in China with a high level of engineering expertise, service, and quality. EZCON Telecom Technology Co. Is a US-China joint venture. EZCON CEO, Dr. Zemin Liu is a recognized RF connector industry expert. Dr. Liu developed and designed the industry's most advanced EZCON series connector. He has over 20 years work experience working in the United States, Sweden, and China for world-renowned companies (Commscope, Tyco, Atlas Copco, Amphenol etc). The company management team consists of top technical experts and business development professionals in the telecom industries. EZCON Telecom Technology Co. LTDA.

Leading supplier for high quality test products (frequency range DC-100 GHz) and RF cable assemblies including test cables, adaptors, and calibration kits etc for R&D and production test applications as well as RF connectors and cable assemblies for wireless base stations. Our customers includes world-class telecom equipment suppliers as well as operators such as Commscope, Amphenol, AT&T, Huawei, Synergy Telecom (India) etc.
