2 Core Duct FTTH Drop Optic Cable with G657A Fiber

Name: 2 Core Duct FTTH Drop Optic Cable with G657A Fiber
Brand: all-electronics-online.com
SKU: 698317502
Availability: InStock
Rating: 4.7 (63 reviews)

Price:	US $ 445KM
Trade Terms:	FOB,CFR,CIF
Min Order:	5KM
Pay Type:	L/C,T/T,Western Union,Paypal,Money Gram

Contact Supplier

Showroom Product Company Profile

Prod Model:	GYPHA
Markets:	North America,South America,Eastern Europe,Southeast Asia,Africa,Oceania,Mid East,Eastern Asia,Western Europe
Product Name:	Duct FTTH Drop Optic Cable
Inner Sheath Color:	Black
Inner Sheath Material:	Lszh
Strengthen Member:	Steel/FRP
Outer Sheath Material:	PE
Cable Diameter:	6.8±0.2mm
Cable Weight:	Approx. 33.0 Kg/Km
Operation Temperature:	-20~+60c
Crush Resistance:	2200n/100mm
Fiber Type:	G.657A
Application:	Communication
Type:	Single-mode Fiber
Certification:	CCC
Connection Structure:	Sc, FC, LC, etc.
Sheath Material:	Lzsh PE

Product Description

GYPHA 2 core duct ftth drop optic cable with G657A fiber for the last 1 kilometers

Drop Cable Characteristic
1. Special Low-bend-sensitivity fiber provides high bandwidth and excellent communication transmission property.
2. Two parallel FRP strength members ensure good performance of crush resistance to protect the fiber.
3. Simple structure , light weight and high practicability.
4. Novel flute design , easily strip and splice , simplify the installation and maintenance.
5. Low smoke , zero halogen and flame retardant sheath , environment-friendly material

Drop Cable Application
1. Access network , fiber to the home.
2. Support the Internet , CATV , telephone and more network service in the future.

Drop Cable Parameter

Item	Technology parameter
Cable type	GYPHA-2B6
Cable specification	6.8
Fiber color	Blue, orange
Fiber type	9/125 (G657A2)
Inner sheath color	Black
Inner sheath material	LSZH
Inner cable dimension mm	3.0(±0.1)*2.0(±0.1)
Strength member	Steel wire
Outer sheath color	Black
Outer sheath material	PE
Cable diameter mm	6.8±0.2
Cable weight Kg/km	Approx. 33.0
Min. bending radius mm	10D (D: Cable diameter)
Attenuation dB/km	<=0.4 at 1310nm,<= 0.3 at 1550nm
Short term tensile N	200
Crush resistance N/100mm	2200
Operation temperature ºC	-20~+60

Hangzhou Softel Optic Co., Ltd. (Brand: SOFTEL) was established in 2006, which Located in the HangZhou Hi-Tech Development Zone. Taking advantage of the modern broadcast and optic fiber communication technology, we are specializing in R&D of CATV system equipment, and leading manufacturer of HFC broadband Optic Transmission equipment with strong R&D capability in this field.

We have more than 100 staff in which 10% of senior technicians. It has more than 1, 000 square meters standards production assembling line, we have strict QC procedure, each unit of our products will go through 3 layer QC procedure, material checking before production, stability and performance testing after production, packing checking before delivery.

Currently, we supplying to numerous agents, integrated dealers and equipment producers all over the world, most of our products move to South America, Russia and north European countries.

Through keen international business competition in good faith, all of our staffs feel big accomplishment & work under heavy responsibility. In addition, we are much proud of providing our invaluable customers with our high quality, high reliability, high efficiency, competitive products.
