200402 Toggle Switch

Name: 200402 Toggle Switch
Brand: all-electronics-online.com
SKU: 621136024
Availability: InStock
Rating: 4.6 (106 reviews)

Price:	US $ 1-10/Piece
Trade Terms:	FOB,CFR,CIF
Min Order:	100/Piece
Pay Type:	L/C,T/T,Western Union,Paypal

Contact Supplier

Showroom Product Company Profile

Prod Model:	200402
Markets:	North America,South America,Eastern Europe,Southeast Asia,Africa,Oceania,Mid East,Eastern Asia,Western Europe
Rated Current 30A:	Rated Voltage 125/250V
Interface Mode 4p:	Protection Class IP20
Standard:	Standard
Lamp:	Without Lamp
Color:	Black
Certification:	CE
Condition:	New
Usage:	Industrial

Product Description

Parameter
Product Name toggle switch
Product Model 200402
Using standard EN61058-1
Rated Current 30A
Rated voltage 125/250V
Interface mode 4P
Insulation Resistance ≥5MΩ
Electrical strength AC 2000V 50HZ
Protection class IP20
The main material H161
Color Standard color: black; or according to customer requirements
Adaptation Model switching Life 20000

Application
special switches intended for devices or appliances

Features
This product is very durable, long-lasting life, superior stability, belonging to the patented design

Testing and Quality Control
Our product have pass lots type of test, whatever in TEMPERATURE-RISE TEST, CTI/PTI TEST, GLOW WIRE TEST, UST TEST and the other test, our product performance are over the standards and other brands' product

Certification CE Rohs

Packaging & Delivery

Packaging Details:	1pc in a white/Colour box, 12pcs in a carton
Delivery Detail:	Epoxypanels: 15-20 days, Laminated glass panels 30-60 days once order confirmed
Production Capacity:	300000 Strings/Month

Payment terms:

1. TT, Western Union or Paypal: 30% in advance,70% before delivery or 100% paid in advance.
2. L/C is available for container orders.

Shenchuang Electrical is an electrical company of invention, production and integration. We concentrate on manufacturing solar panel fairy lights, solar panel lamps and electric starter lock switch, high-current switching, American NEMA socket, plug series, German socket, , plug series, South Africa socket, plug series etc...

Shenchuang Electrical has been dedicating itself to the research and development since its inception. It has strong technical strength and complete tesing equipment. Many products have passed international safety certification organizations such as the famous U. S. "UL", Canada "cUL", German "VDE" "TUV", Australia"SAA" and the ISO90001 quality system certification. It is also widely used in the generator industry, machine tool equipments, Electric vehicle charging piles, factory production lines, construction sites, airport and docks etc. With reasonable price, superior quality and excellent services won the praise and trust of new and old customers. The products have exported to Europe, America and Southeast Asia and other regions. We also support production to Honda, YAMAHA, Generac, Cunmmins, TTI, CPI, BS, ETQ

And other multinational companies. Shenchuang Electrical has become a leader of Chinese generators supporting industry!

Our company adhere to the guidelines of "quality for survival, technology for development. ". We believe that we can achieve new heights with sincerity, ethics technology, creation, mangement.
