2017 Hot Sell Waterproof Matrix Membrane Switch

Name: 2017 Hot Sell Waterproof Matrix Membrane Switch
Brand: all-electronics-online.com
SKU: 832808155
Availability: InStock
Rating: 5 (83 reviews)

Price:	US $ 0.3-0.5/Piece
Min Order:	1000/Piece
Pay Type:	L/C,T/T,D/P,Western Union,Paypal

Contact Supplier

Showroom Product Company Profile

Prod Model:	XJJ-021
Material:	PET
Application:	Camera
Type:	for Any Car Seat.
Contact Type:	Pressure Senor
Number Of Switch:	>10 Million Activations
Detection Method:	Precision,Easy Seat Integration,Reliability
Brand:	Xjj/OEM
Certification:	Ts-16949

Product Description

Specifications

membrane switch
1 material : PET /PC
2 adhesive: 3M467 & 3M468
3 High life time :>1million times
4 Pass:ISO9001:2008RoHS.

Rapid Prototyping
Short Lead-Times
Cost Savings
Any Size and Any Shape

1.Customize Membrane Switches,

2.Attaining certificates of ISO9001:2008,ISO14001:2004.

3.High quality printing.

Technical parameters
Basic Parameter for the Membrane Switch /Membrane keypad /membrane keyboard
Membrane switch is Compositive switch made of insulating material layers and conductive layers. It be comes the first choice for the electric control switch for its unique Superiority. Good appearance, small volum, long life-span and Bend resistance make the membrane switch popularly accepted. Also, it has strong resistances against the water, fire, oil and scratch. Hereby, the basic parameters of it is presented as follows:
Technical Datas
1 Electrical Performance
(1) Operating Voltage: ≤50VD
(2) Operating Current: ≤100mA
(3) Contact Resistance: 0.5~10Ω
(4) Insulation Resistance: ≥100MΩ(100VDC)
(5) Base Material Withstand: 2kDVC
(6) Contact bounce: ≤6ms
(7) Loop Resistance: 50Ω,150Ω,350Ω or as per clients' requirement
2 Mechanical Properties
(1) Life expectancy: >1 million times
(2) Switch stroke: 0.1-0.4mm(Flat type)
0.4-1.0mm(Tactile type)
(3) Actuation force: 15~750g
(4) Flex Tail Pitch(Standard): 2.54 /2.50 /1.27/ 1.25mm
3 Environment Specification
(1) Operation Temperature: -20°C~+70°C
(2) Storage temperature: -40°C~+85°C
(3) Humidity: 40 C, 90%-95%, 240 hours
4 Printing Indicator
(1) Size Deviation: ±0.15mm
(2) Side Boundary: ≤0.1mm

One-stop shopping! Standard and custom-made membrane keypads
XINJIEJIA offers a wide range of standard keypads designed for XINJIEJIA enclosures.When requested, custom-made versions can be supplied at low cost and fast. In addition XINJIEJIA offers the machining of enclosures and mounting of membrane keypads. Keypad face membranes can be designed to your specifications.
Features :
We use exclusively high-quality materials in our membrane keypads, ensuring longevity even in harsh industrial environments.

In the face of today's high-tech era, in all enterprises like introduction of new and interesting possibilities to play the leading role, and even into the huge human and financial resources to the enterprise product design and packaging. Suitable for high-tech and future trends, as much as possible so that all products to light, thin, short, small fine design.

Cutting-edge industries such as information --- computer, designed by the original Superman heavy, hand-held mini, more communication on the phone, but also towards light, thin, short, small direction of the devlopment of its design eples, in paticular civilian elctrical In this regard, the development isto catch up.

ShenzhenXinjiejia Electron sign membrane switch factory is a professional production of membrane switch manufacturers and their production of thin film switches in full compliance with light, thin, short, small features and high-tech nature.

The Shenzhen Xinjiejia Electron sign membrane switch factory, the general level of quality service for customers, selling its products all over the world, the company has consistently adhered to the first-quality, reasonably priced by manufacturers of deep love.

Shenzhen-a good sign membrane switch factory is very concerned about the requirements of each customer satisfaction and to ensure quick delivery. Please do not hesitate today to contact us information and samples.

Xinjiejia Electron kit is a professional high-tech printing company, the company's products include Ming Ban, circuit boards, membrane switch, touch-screen electronic cold light board, PCB board, silicone, flexible lines, injection and other special printing line, and so on, you are welcome Contact us and work with us.
