2040 Nomex Resin Coating Paper

Name: 2040 Nomex Resin Coating Paper
Brand: all-electronics-online.com
SKU: 670417712
Availability: InStock
Rating: 4.8 (60 reviews)

Price:	Negotiable/Piece
Trade Terms:	FOB,CFR,CIF
Min Order:	300/Piece
Pay Type:	T/T,Paypal

Contact Supplier

Showroom Product Company Profile

Markets:	North America,South America,Eastern Europe,Southeast Asia,Africa,Oceania,Mid East,Eastern Asia,Western Europe

Product Description

Characteristics and application:
Temperature classification is F. Uniform resin, good drying and bonding properties. Used as the turns insulation for motors.

No	Item		Unit	Normal value
1	Thickness and tolerance	Thickness	mm	0.15± 0.02	0.18± 0.02	0.22± 0.02
		Thickness		Individual tolerance: ± 0.03
		Width		According to the order of the customer. Tolerance: ± 1mm
		Length		The diameter of the disk is not less than 100mm. The joint per roll shall not be more than one. The length is not less than 5m.
2	Nomex paper		mm	0.13		0.18
3	Bending at edge		mm	≤ 1	≤ 1	≤ 1
4	Weight per square meters		g/m 2	150- 160	153- 177	261- 240
5	Resin content		%	24± 3	30± 4	23± 4
6	Soluble resin content		%	≥ 85	≥ 85	≥ 85
7	Breakdown voltage		kV	≥ 3	≥ 3	≥ 5
8	Bonding strength		MPa	≥ 3	≥ 3	≥ 3

Beijing Red Sun Composite Material Co., Ltd. is one professional producer for SMC and BMC molding products, insulating rigid laminates, rods and tubes, flexible composites, high thermal resistant products, gasket, fiber glass products, engineering plastics, etc. We also provide the further fabrication for these products and kinds of composite materials. You can get most of what you want from us.

Advanced production line, excellent technology and experienced work team assure we can provide you the products comply with the international standards and different requirements. We assure that you will get the high efficiency feedback and best service from us for those products that we deal with and certainly with the competitive price.

We have won customers from USA, Canada, Germany, Japan, and so on to be our partners, and more and more customers are joining us.

Red Sun Composite always takes the "Mutual Benefit", "Quality First" and "Better Ethics" as principle. Red Sun Composite will be your partner to success.
