| Prod Model: |
QW120-200-S |
| Input Voltage: |
AC100-240V 50/60Hz |
| Voltage: |
12V |
| Current: |
20A |
| Delivery Date: |
20days |
| Desktop Type: |
Yes |
| Warranty: |
12 Months |
| Charger Type: |
Electric Charger |
| Nominal Voltage: |
12V |
| Type: |
Lead Acid Battery |
| Socket Type: |
EU/Au/UK/Us |
Product Description
12V Lead acid battery charger(12V 20A)
Quick Detail:
Brand Name:QUAWIN
Model Number:QW120-200-S
Use:12V Lead-Acid Battery
Type:Electric
Place of Origin:Guangdong China (Mainland)
Battery charger:automatic battery charger 14.7V
Color:Black/Silver
Input voltage:AC 90~264V or 100~240V 50/60Hz with PFC
Output voltage:14.7V
Output current: 20A
Output power: 294W
Output Connector: Alligator Clip,SR175A Output Plug,SB175A Output Plug,SB50A Output Plug,Custom
Packaging & Delivery:
inner package: white box/polybags/at your request outer package:carton
Delivery Detail:sample within 5 work days,25 days for bulk order
Specifications:
Portable fast SLA/AGM/VRLA /GEL charger 12V lead acid battery charger
Features:
• Fully auto CC +CV(H)+CV(L) charging process,with MCU controller.
• Constant big charging current for faster charging,
• automatically charging ending with Cut-Off output.
• Aluminum case with Fan Cooling
• It can charge any 12V SLA/VRLA/GEL/AGM battery with capacity 150-160Ah
Specification:
• Input: AC 90~132V or 180~264V or 100~240V
• Output: DC 14.7V
• Charging current: 20A
• Full Load Efficiency:≥87%
• Shock & Vibration:SAEJ1378 Standard
• Operating Temperature:-20ºC~45ºC (-20ºF~+113ºF)
• Weight: 1500g(only body)
• Dimension:184*103*64.5mm
Safety protections:
• Over Voltage protection
• Short Circuit protection
• Polarity error protection
• Over power protection
LED Indicator:
• GREEN Light ON: fully charged or no connected.
• BLUE Light flash: battery is being charged.
• RED Light ON: Charger under protection (over temperature protection, output short-circuit protection, reverse polarity protection, output over-voltage protection).
Call us to know more details datasheet.
| ITEM | QW120-160-S | QW120-170-S | QW120-180-S | QW120-190-S | QW120-200-S | QW120-210-S |
| Output voltage: | 14.7V | 14.7V | 14.7V | 14.7V | 14.7V | 14.7V |
| Rated output current: | 16A | 17A | 18A | 19A | 20A | 21A |
| Output power: | 235.2W | 249.9W | 264.6W | 279.3W | 294W | 308.7W |
| ITEM | QW120-220-S | QW120-230-S | QW120-240-S | QW120-250-S | QW240-110-S | QW240-120-S |
| Output voltage: | 14.7V | 14.7V | 14.7V | 14.7V | 29.4V | 29.4V |
| Rated output current: | 22A | 23A | 24A | 25A | 11A | 12A |
| Output power: | 323.4W | 338.1W | 352.8W | 367.5W | 323.4W | 352.8W |
| ITEM | QW240-130-S | QW240-140-S | QW240-150-S | QW360-080-S | QW360-090-S | QW360-100-S |
| Output voltage: | 29.4V | 29.4V | 29.4V | 44.1V | 44.1V | 44.1V |
| Rated output current: | 13A | 14A | 15A | 8A | 9A | 10A |
| Output power: | 352.8W | 411.6W | 441W | 308.7W | 396.9W | 441W |
| ITEM | QW480-070-S | QW600-060-S | QW720-040-S | QW720-050-S | QW840-040-S | |
| Output voltage: | 58.8V | 73.5V | 88.2V | 88.2V | 102.9V | |
| Rated output current: | 7A | 6A | 4A | 5A | 4A | |
| Output power: | 411.6W | 441W | 352.8W | 441W | 411.6W | |
