20kv European Protective Separable Connector

Prod Model:	hc-050
Markets:	Eastern Europe,Southeast Asia,Africa,Oceania,Mid East,Eastern Asia,Western Europe
Type:	Screened
Material:	Silicon Rubber
Current:	630/1250A
Cross Section:	25-500 Sqmm
Application:	Power
Gender:	Protective Connector

Product Description

20kV European Protective Separable Connector

 Range of Application

l  Apply to insulation socket protection of ring main unit inlet-outlet wire for the voltage under 12/20kV,also can be applied to various of cable distribution box and enclosure substation device.

Product Description

l  Products adopts importing silicone rubber material to produce, which with excellent insulation performance, heat resistance, cold resistance, dielectric properties, resistance to ozone and atmospheric aging resistance, and can be operated under any working condition.

l  Each batch of raw material takes the mechanical properties and electrical properties index testing, which ensures product quality from source.

l  All finished products 100% takes the factory performance test (power frequency withstand voltage, partial discharge)

l  Import DESMA solid injection production system, with dustless and air-conditioned manufacturing shop,  and constant temperature and humidity all year round, which ensures the product not affected by external environment and the quality stability of product.

l  Product structure design complies with the C type bushing size requirement of EN50180,EN50181 standard, and meet the performance requirement of IEC60502,GB12706.4 standard, which is safe and reliable with long period operation.

Technical Feature

l  Simple design in product structure, easy and convenient installation, product can be disassembled and installed repeatedly and not affected by altitude.

l  Excellent inside and outside screened design and screened resistance lower than 5kΩ,which ensures the safety of product operation and operator, as well as achieve the performance of all insulation, whole sealing, protection, maintenance-free, water resistant and so on.

Technical Parameter

rated voltage	12/20kV
the highest operating voltage	24kV
power frequency withstand voltage	54kV,5min,no flashover, no breakdown
partial discharge	20kV,≤5pc
impulse voltage test	125kV,±10 times
screened resistance test	before and after aging, screened resistance not bigger than 5000Ω
screened leakage current	under 24KV, leakage current no bigger than 0.5mA

Specification

Voltage Level	Specification	Product Description
8.7/15	HCS-O-20	unscreened type Protective Separable Connectors
	HCPS-O-20	screened type Protective Separable Connectors

Quality Control System

Hifuture devote itself to establish a first grade enterprise and a famous brand. During the operation, production, and management, Hifuture has been implementing the enterprise tenet of "customer first, quality first and people first", and making great effort to build an efficient, progmatic,innovative corporate culture.

Our commitment:

By providing customers with the excellent, environmental, safe and reliable city and country power distribution network and service to putting an end to non-performing products. Abide by laws and regulations and other requirements.

Improving product quality by constantly improve the equipment, technique lifting, technique improving, production improving and quality management.

And improving product environmental performance through carrying out energy-saving, consumption reduction, emission reduction and pollution prevention. Reducing the potential health and safe problems during the production to prevent and decrease the accident.

All staff participation, clear statement of safe responsibility of quality, environment, and occupational health and safety. Providing effective training and necessary resource to enhance the employee quality and the awareness of environment and occupational health and safety.

Improving staff's qualities and abilities to make sure each employee perform their duty properly and improve their job performance constantly.

Continuous improvement of system operation suitability, adequacy, effectiveness by external and internal audit, management review, take prevented actions. Analyze the experience of quality, environment, health and safety area with the relevant parties. Advance the idea of quality, environment, health and safety.
