| Prod Model: |
FNGM-JD3532K |
| Type: |
Inductive Proximity Switch |
| Output Signal Type: |
NPN/PNP 3 Wire, Two Wire |
Product Description
Power voltage | DC12-24V |
Consumption current | <200mA |
Response time | ≤15ms |
Output | NPN/PNP |
Indicator light | Transmit: RED (power LED); Receiver :Green(output LED) |
Light Source | infrared light |
Connect | with plug connector,with cable, transmit with 3 pins , and receiver with 4 pins |
Cable length | 2M,3M,5M (can make ) |
The body material | Aluminum alloy and , The cover is reinforced nylon |
Resist ambient light | incandescent:light area illumination 3000Lx; Sunlight:light area illumination 10000Lx |
Resist ambient Temperature | when working -5 to 50 degree (but no freeze); when keep in stock,-25 to 55 degree |
Ambient | humidity:when working:35-85%RH; When keep in stock:35-95%RH |
Dimension | 26x29mm / 35x18mm |
Mode number | Anix No. | Fiber optic space(mm) | Protection height(mm) | The body length(mm) | Sensing distance | Type |
| FNGM-JD3506K | 6 | 35 | 100 | 160 | 0-3/6M | NPN/PNP |
FNGM-JD3508K | 8 | 35 | 140 | 200 | 0-3/6M | NPN/PNP |
| FNGM-JD3510K | 10 | 35 | 180 | 240 | 0-3/6M | NPN/PNP |
| FNGM-JD3512K | 12 | 35 | 220 | 280 | 0-3/6M | NPN/PNP |
| FNGM-JD3514K | 14 | 35 | 260 | 320 | 0-3/6M | NPN/PNP |
| FNGM-JD3516K | 16 | 35 | 300 | 360 | 0-3/6M | NPN/PNP |
| FNGM-JD3518K | 18 | 35 | 340 | 400 | 0-3/6M | NPN/PNP |
| FNGM-JD3520K | 20 | 35 | 380 | 440 | 0-3/6M | NPN/PNP |
| FNGM-JD3522K | 22 | 35 | 420 | 480 | 0-3/6M | NPN/PNP |
| FNGM-JD3524K | 24 | 35 | 460 | 520 | 0-3/6M | NPN/PNP |
| FNGM-JD3526K | 32 | 35 | 500 | 560 | 0-3/6M | NPN/PNP |
| FNGM-JD3528K | 48 | 35 | 540 | 600 | 0-3/6M | NPN/PNP |
| FNGM-JD3530K | 64 | 35 | 580 | 640 | 0-3/6M | NPN/PNP |
