20W/30W Ipg Fiber Laser Marking System for Yeti Cup
| Price: |
US $ 4500/Piece |
| Min Order: |
1/Piece |
| Pay Type: |
L/C,T/T,D/P,Western Union,Paypal |
| Prod Model: |
PEDB-200A |
| Average Output Power: |
20W (Cw or Pulse) |
| Wavelength: |
1064nm |
| Pulse Repetition Frequency: |
20-100kHz |
| Marking Depth: |
≤1.2mm |
| Output Beam Quality: |
<1.5m² |
| Min. Focusing Spot: |
0.005mm |
| Min. Character Height: |
0.15mm |
| Max. Marking Speed: |
12000mm/S |
| Re-Precision: |
±0.001mm |
| Cooling: |
Air Cooling |
Product Description
PEDB-200A Mini Full Closed Fiber Laser Marking Machine
---Brief Introduction
The full-closed type 20w fiber laser marking machine adopts the portable design and is easy to move and work in different place. It has no consumables, so the depreciation cost of the product is greatly reduced. It has the advantages of high efficiency, long service life and maintenance free, which the traditional laser doesn't have. It is suitable to mark on hardware tools, kitchen knives, plastic products, integrated circuit, bottles, glasses frame, cleaner taps and so on.
---Technical Parameters| Average output power | 20W (CW or pulse) |
| Wavelength | 1064nm |
| Power Modulation Range | 10-100% |
| Pulse Repetition Frequency | 20-100KHz |
| Output Beam Quality | <1.5M² |
| Marking Depth | ≤1.2mm |
| Min. Focusing Spot | 0.005mm |
| Min. Character Height | 0.15mm |
| Max. Marking Speed | 12000mm/s |
| Format Supported | Graphics, text, bar code, two-dimensional code, date, frequency, batch number, serial number, file link. |
| Operating System | It can work with win7,win8 and XP.
It support PLT, PCX, DXF, BMP and so on.
It can use directly SHX and TTF font. |
| Re-precision | ±0.001mm |
| Overall Power | ≤160W |
| Power Supply | 220V±10%/50Hz/4A |
| Cooling | Air Cooling |
| Control Interface | USB |
| Laser Module Life | >100000h |
| Galvanometer | High performance scanning galvanometer |
| Working Environment | No dust and no source of vibration |
---Product Application
1. Replace ink and paint: labels of cellphone battery, panels, cellphone keys, small accessories, etc..
2. Ceramic and EP materials: electronic components package, IC, etc..
3. Plastic products: numerical order and LOGO of electrical enclosures and electronic products.
4. Metal surface: stainless steel, copper, aluminum, oxidation, phosphatization and electrocladding. It's commonly used in hardware, daily necessities, electrical enclosures, cell phone cases, etc..
---Product Advantages
1. High definition: Resolution is up to 1 micron and is at least 10 times higher than traditional machines.
2. Less power consumption: It's 1 / 25 ~1 / 10 of traditional laser markers.
3. High speed: 3~5 times faster than traditional laser markers.
4. High stability: higher than any other similar ones.
5. Long service life: 10 times longer than traditional ones.
