210W-350W Single Output Switching Power Supply (NES series)

Name: 210W-350W Single Output Switching Power Supply (NES series)
Brand: all-electronics-online.com
SKU: 708909942
Availability: InStock
Rating: 4.6 (58 reviews)

Price:	US $ 21.5/Piece
Trade Terms:	FOB
Min Order:	1000/Piece
Pay Type:	T/T,Paypal

Contact Supplier

Showroom Product Company Profile

Prod Model:	WSPNES-210/350
Markets:	North America,South America,Eastern Europe,Southeast Asia,Africa,Oceania,Mid East,Eastern Asia,Western Europe
Dimming Function:	Built-in 3 in 1 Dimming Function(1-10VDC,PWM Signa
Usage:	Light
Output Type:	Single
Driving Method:	LED Constant Current
Circuit Structure:	PWM Controlled
Brand:	OEM

Product Description

NES Series: 210W-350W Single output switching power supply
Features:
*AC input selectable by switch
*Withstand 300VAC surge input for 5seconds
*Protections:Short circuit/Overload/Over voltage /Over temperature
*NES-200: Cooling by free air converction
*NES-350: Forced air cooling by built-in DC fan
*NES-350:Built-in fan ON
*Built-in constant current limiting circuit
*Most economical low wattage solution *Low cost,high reliability
*LED indicator for power on
*100% full load burn-in test
*2 years warranty

Series No.

Model No.

Specification

AC input range

DC adjustable range

Overload protection

Over voltage protection

Setup,rise,hold up time

Withstand Voltage

Working temperature

Safety standards

Output

Voltage tolerance

Ripple&noise

Efficiency

Size(mm)

NES-200

NES-200-3.3

90~132VAC/180~264VDC selectable by switch

±10% rated output range

105%~150% constant current limiting,auto-recovery

115%~145% rated output voltage

100ms,50ms,20ms, full load, 230VAC

I/P-O/P:3KVAC,I/P-FG:1.5KVAC, O/P-FG:0.5KVAC

-20~+50ºC

UL60950-1

3.3V,0~40A

±2%

150mV

75.0%

215x115x50

NES-200-5

5V,0~40A

±2%

150mV

79.0%

NES-200-7.5

7.5V,0~27A

±2%

150mV

82.0%

NES-200-12

12V,0~17A

±1%

150mV

85.0%

NES-200-15

15V,0~14A

±1%

150mV

85.0%

NES-200-24

24V,0~8.8A

±1%

150mV

87.0%

NES-200-27

27V,0~7.8A

±1%

240mV

88.0%

NES-200-36

36V, 0~5.9A

±1%

200mV

89.0%

NES-200-48

48V,0~4.4A

±1%

240mV

89.0%

NES-350

NES-350-3.3

90~132VAC/180~264VDC selectable by switch

±10% rated output range

105%~135% constant current limiting,auto-recovery

115%~145% rated output voltage

100ms,50ms,20ms, full load, 230VAC

I/P-O/P:3KVAC,I/P-FG:2KVAC, O/P-FG:0.5KVAC

-20~+60ºC

UL60950-1

3.3V,0~60A

±3%-4.5%

150mV

74.0%

215x115x50

NES-350-5

5V,0~60A

±3%

150mV

78.0%

NES-350-7.5

7.5V,0~46A

±2%

150mV

80.0%

NES-350-12

12V,0~29A

±1.5%

150mV

83.0%

NES-350-15

15V,0~23.2A

±1%

150mV

84.0%

NES-350-24

24V,0~14.6A

±1%

150mV

87.0%

NES-350-27

27V,0~13A

±1%

240mV

88.0%

NES-350-36

36V, 0~9.7A

±1%

200mV

87.5%

NES-350-48

48V,0~7.3A

±1%

240mV

87.5%
