2200UF Four Pins Snap-in Terminal Aluminum Electrolytic Capacitor 105c

2200UF Four Pins Snap-in Terminal Aluminum Electrolytic Capacitor 105c
Price: US $ 5.6/Piece
Min Order: 1000/Piece
Pay Type: T/T
Prod Model: TMCE18
Number Of Pins: Four
Type: Aluminum Electrolytic Capacitor
Application: General Purpose
Package Type: Through Hole
Capacitance: 0.1 to 15,000UF
Tuning: Electrolytic Capacitor

Product Description

Four Pins Snap-in Terminal Aluminum Electrolytic Capacitor 105C


Features:
105ºC,2000 hours
Suitable for using in switching power supplies,LCD TV, LED,special control power supply and smart meter.

Specifications:
ItemCharacteristics
Rated Voltage Range10~450V.DC
Operating Temperature
Range
-40ºC~105ºC
Capacitance Tolerance±20%(M)  (25ºC,100 or 120Hz)
Leakage CurrentI≤ 3 (mA)
Whichever is greater after 5 minutes at 25ºC.
Dissipation Factor
UR(V)200250~450
tgδ0.150.20
     (25ºC,100 or 120Hz)


Low Temperature
Characteristics
Impedance ratio at 100Hz or 120Hz shall not exceed the values given in the below table.
UR(V)10~3550~100200~250400~450
Z-40ºC/Z2510677
Load  LifeAfter application of rated voltage with ripple current for 5000hours at 105ºC,the following specification shall be satisfied.
Capacitance ChangeWithin ±20% of the initial value
 Dissipation FactorNot more than 200% of the specified value
Leakage CurrentNot more than the specified value
OthersMeet Q/RME 149-2013, GB/T 5993-2003

Ripple Current Multiplier
Frequency Coefficient
Frequency(Hz)50/60100/1201K≥10K
10~100WV0.901.001.101.15
200~250WV0.801.001.301.50
400~450WV0.801.001.251.40

Size: see the datasheet in our webesite at www.topmay-capacitor.com

TMCE09-LOW ESR E-CAPU/P(USD)QtyL/TPayment
16V *     470 uF      8*12mm    0.01641000015 work  daysTT advanced
16 V *    3300 uF    13*25mm 0.07821000015 work  daysTT advanced
50 V *    10 uF        5*11mm 0.00721000015 work  daysTT advanced
50 V *    220 uF     10*15mm0.02681000015 work  daysTT advanced
35 V *    470 uF     10*16mm 0.0351000015 work  daysTT advanced
35 V *    2200 uF   16*25mm 0.17491000015 work  daysTT advanced
100V *    680UF     18*32mm   0.28111000015 work  daysTT advanced
50V  *    1500UF    16*26MM  0.15671000015 work  daysTT advanced




Established in 1998, and mainly engaged in manufacturing, researching & developing, and dealing in various capacitor, Shenzhen Topmay Electronic Co., Ltd. is an industrial enterprise with independent corporate entity and has its headquarters located at the flourishing center of Shenzhen, a city has been recognized as the frontier of China economy. After years' persistent hard work by all the companions, Topmay has now developed to be a famous electronic company that promotes very quickly with the most advanced technology.

Topmay has large factories by joint venture. Located in NanTong city. Years' continuous development now provides us with standard workshop of 12, 000 square meters, 6 production lines and 862 employees.

Presently, Topmay products mainly include the following products:

The whole series capacitors Film capacitor, Ceramic capacitor, Tantalum capacitor, Aluminum Electrolytic Capacitor, and etc.

Topmay holds an idea that the products quality is the life of a company. In order to serve our customers better, and to enhance the products grade, Topmay has invested a lot to the application of kinds of international system and quality certifications, and have achieved the following: ISO9001: 2000, ISO14001, Greatwall, CE, SA, UL, TUV, VDE, and etc. Topmay insist on a tenet that people should be oriented, efficiency is the priority, quality should be emphasized, and credit is the uppermost. And we try our best to exploit and to innovate, and keep improving our production technology. So now we gradually grow up to be an outstanding one in our industry. Topmay products are of numerous varieties, compete species, super quality, competitive price and stable function, and all of their indexes have reached the international advanced level.

Topmay takes marketing as the key procedure of the company's entire development. One after another, we attend many global electronics fairs that take place in Munich, Hong Kong, Shanghai, Guangzhou, and Shenzhen. Meanwhile, we get going kinds of driving publication on the well-known B2B websites, such as EbigChina, Made-in-China. com, Globalsources and etc. All these have surely afforded us a good result, a profound influence, and a continuously expanded clients group. At present, Topmay's business primarily concentrates abroad, more than 65%'s export. Because of the super-quality products, the eminent business reputation, the omnibearing technique service and competitive prices, we have established a stable relationship of good cooperation with overseas customers. Now our products have been sold to many distant places, such as USA, Canada, Brazil, Germany, England, France, Spain, Turkey, Russia, Poland, Arabia, Bulgaria, Korean, Malaysia, India, HK, Taiwan, and etc. Namely, a large scope of overseas market has been successfully occupied.
