| Prod Model: |
2IK6GN-C |
| Markets: |
North America,South America,Eastern Europe,Southeast Asia,Africa,Oceania,Mid East,Eastern Asia,Western Europe |
| Dia: |
60mm, 70mm, 80mm, 90mm, 104mm |
| Power: |
6W, 25W, 40W, 60W, 90W, 100, 120W, 200W |
| Voltage: |
220V/110V |
| Protection Class: |
IP20 |
| Number Of Stator: |
Single-Phase |
| Function: |
Transmission |
| Certification: |
CCC, CE, UL. RoHS |
| Brand: |
Zd-Motor |
Product Description
220V 50Hz 6w AC Indution Gear Motor
Specification:
Power: 25W, 40W, 60W, 90W, 100, 120W
Dimension: 80, 90mm
Voltage: 110V, 220V
Frequency: 50Hz, 60Hz
Accessory: Terminal box, theremal protector, pedestal of the motor, fan
Certification: CE, UL, RoHS and ISO9001
Please contact us if you have any question or need any of our products.
80mm 12v/24v 40watt Electric DC Gear Motor
Motor Performance Parameters
Model Type |
Voltage
V |
Power
W |
Load Parameters |
Capacitor
uF |
Motor Weight
Kg |
Speed
r/min |
Torque
mN.m |
Current
A |
2IK6GN-A |
110 |
6 |
1200 |
48 |
0.24 |
3.5 |
0.75 |
2IK6GN-C |
220 |
6 |
1200 |
48 |
0.13 |
2 |
0.75 |
2IK6GN-S |
380 |
6 |
1450 |
48 |
0.076 |
0.8 |
0.75 |
Gearhead Type |
Gearhead Model |
Gear Ratio |
Long Life Low Noise |
2GN*K |
3,3.6,5,6,7.5,9,12.5,15,18,25,30,36,50,60,75,90,100,120,150,180,200 |
2GN10XK(Decimal gearhead) |
Note : It's just the typical technical data for you reference, The specification such as voltage, speed, torque, shaft can customized.
Typical Application:
machine tools,textile machinery, medical appliance, conveying machines, printing mechanism, food machinery, vending machinery, packing machinery, and gumming machinery.
Our company is specialized in mini AC/DC gear motors. At present, our main products are: gear motors, three phase motors, speed control motors, brake motors, damping motors, torque motors, and DC gear motors. They are widely used in machine tools,textile machinery, medical appliance, conveying machines, printing mechanism,food machinery, vending machines, packing machinery, and gumming machines. Our tenet is: quality as foundation, reputation first, seeking for outstanding position.With excellent equipment, advanced procedure, scientific management, andmodern test method, we can provide all customers both at home and abroad with our top quality products, favorable prices and sincere service. We hope that we canestablish long-term business relationships together with you for mutual business
Ningbo zhongda leader transmission equipment Co., Ltd. is specialized in mini AC gear motors. At present, our main products are: Gear motors, three phase motors, speed control motors, brake motors, damping motors, torque motors, and DC gear motors. They are widely used in machine tools, textile machinery, medical appliance, conveying machines, printing mechanism, food machinery, vending machines, packing machinery, and gumming machines.
Our tenet is: Quality as foundation, reputation first, seeking for outstanding position. With excellent equipment, advanced procedure, scientific management, and modern test method, we can provide all customers both at home and abroad with our top quality products, favorable prices and sincere service.
We welcome interested companies to inquire about our products. We are looking forward to establishing long-term business relationships together with you for mutual business success.
History of ZD motor:
March 1996, start to make motor parts;
1998 start to make Y-series AC motor;
2001 start to produce micro AC gear motor;
2005 start to customize products for customer. Meanwhile, start to produce DC gear motor;
2006 start to produce small series AC gear motor;
2007 start to produce planetary gearbox and BLDC motor;
ZD is the first draft-man of national standardin 2008;
ZD is the first draft-man of standard in 2010;
ZD developed China's first high-precision helical planetary gear reducer in 2011;
ZD developed a robot-specific reducer in 2011.
Honors:
Ningbo's well-known trademarks;
Ningbo technology innovation model.
Ningbo patent demonstration enterprise;
Ningbo innovative pilot enterprises;
Ningbo Safety Standardization enterprises;
Chinese micro motor Union;
Chinese gear Union;
Chinese Electric parts Union;
Chinese Micro motor standardized Union;
First draft-man of Chinese standard of micro motor
