220V 950W Plastic Extruder Ceramic Band Heater
| Price: |
US $ 15/Piece |
| Min Order: |
1/Piece |
| Pay Type: |
T/T,Western Union,Paypal |
| Prod Model: |
480V 1500W Ceramic Band Heater |
| Working Life: |
2-5 Years |
| About Health: |
Eco-Friendly |
| Voltage: |
220V |
| Power(W): |
950W |
Product Description
220V 950W Plastic Extruder Ceramic Band Heater
Ceramic Band Heaters are constructed by winding a nickel-chrome resistance ribbon around mica/ceramic insulation and encapsulated in a stainless steel sheath. It is then formed to the desired diameter for installation over a dies, barrels and nozzles.
They are available in an extensive variety of sizes and shapes with options for holes, notches and cut-outs. A number of threaded terminals, wire lead options and terminal boxes offer great flexibility for field wiring.
Features:
The sheath of the heater is rust resistance.
High class Nickel Chrome ribbon is used.
Maximum power: 3w/cm2(s.steel),4.5w/cm2(brass),6.5w/cm2(ceramic insulation)
Operating temperature up maximum of 500 degree centigrade
Axial, Radial & Tangential terminals are available
Thermocouple holes can be provided as per client's requirements
All Displayed Only for Retail Price, Bulk Purchase Welcome to Contact us for Detail
•Heating barrels of plastic injection molding machines and extruders
•Die and die holder heating of plastic extruders and blow molding machines
•Autoclaves
•Burn-out ovens
•Heated kettles
•Fluidized beds
•Heat treating pipes
•Any application requiring heat applied to a cylindrical surface
| Product Name | Ceramic Band Heater |
| Voltage | 220V |
| Power | 950W |
| Band Size | 50×40mm(Inside Dia.*H) |
| Main Materials | Ceramic |
| Withstand Temperature | 950°C-1000°C |
| Weight | 75g/pc |
| Package | 2pcs Ceramic Band Heater |
Note:
If you need 110V or 380V, please remark in the order. If without any remark, the shipment will be arranged as 220V.
Custom:
The band heater can be customized according to your request. But please offer your request, including:
Voltage/Power/Band Sizes(D/H)
Besides, There are some sizes for your choices, please click the size for your needed.| Size (Inside Dia.*H) | Voltage | Power | Size (Inside Dia.*H) | Voltage | Power |
| 25×25mm | 220V | 60W | 50×45mm | 220V | 220W |
| 25×30mm | 220V | 70W | 50×50mm | 220V | 240W |
| 30×25mm | 220V | 70W | 50×60mm | 220V | 290W |
| 30×30mm | 220V | 90W | 50×65mm | 220V | 310W |
| 30×35mm | 220V | 100W | 55×35mm | 220V | 190W |
| 30×40mm | 220V | 120W | 55×40mm | 220V | 210W |
| 30×45mm | 220V | 130W | 55×45mm | 220V | 240W |
| 30×50mm | 220V | 150W | 55×50mm | 220V | 260W |
| 35×25mm | 220V | 90W | 55×60mm | 220V | 310W |
| 35×30mm | 220V | 100W | 60×25mm | 220V | 150W |
| 35×35mm | 220V | 120W | 60×30mm | 220V | 170W |
| 35×40mm | 220V | 140W | 60×35mm | 220V | 200W |
| 35×50mm | 220V | 170W | 60×40mm | 220V | 230W |
| 35×60mm | 220V | 200W | 60×45mm | 220V | 260W |
| 40×30mm | 220V | 120W | 60×50mm | 220V | 290W |
| 40×35mm | 220V | 110W | 60×55mm | 220V | 310W |
| 40×40mm | 220V | 150W | 60×60mm | 220V | 340W |
| 40×45mm | 220V | 140W | 60×65mm | 220V | 370W |
| 40×50mm | 220V | 190W | 65×50mm | 220V | 310W |
| 40×55mm | 220V | 210W | 65×55mm | 220V | 340W |
| 45×30mm | 220V | 130W | 65×60mm | 220V | 370W |
| 45×35mm | 220V | 150W | 70×40mm | 220V | 270W |
| 45×40mm | 220V | 170W | 70×50mm | 220V | 330W |
| 45×45mm | 220V | 200W | 70×60mm | 220V | 400W |
| 45×50mm | 220V | 220W | 80×50mm | 220V | 380W |
| 50×30mm | 220V | 150W | 85×40mm | 220V | 320W |
| 50×35mm | 220V | 170W | 90×90mm | 220V | 770W |
| 50×40mm | 220V | 190W | 100×100mm | 220V | 950W |
