| Prod Model: |
EH9335 |
| Markets: |
North America,South America,Eastern Europe,Southeast Asia,Africa,Oceania,Mid East,Eastern Asia,Western Europe |
| Color: |
Black |
| High Frequency: |
Yes |
| Pure Sine Wave: |
Yes |
| Three Phase +N+G: |
Yes |
| Capacity: |
10kVA, 20kVA, 30kVA, 40kVA |
| With Battery Inside Or Without: |
Yes |
| Power Factor: |
0.8 |
| Communication: |
RS232, RS485, As400, Snmp, Epo |
| Product Size: |
470*1150*710 |
| Technology: |
IGBT |
| Phase: |
Single Phase |
| Type: |
On-line |
| Protection: |
AC Fluctuation, Noise Interference, Thdi, Tvss |
| Brand: |
Must/OEM |
Product Description
220V pure sine wave 10kVA to 40kVA High Frequency Online Ups with IGBT Tech
Igbt based 3 phase 20kva online ups full dsp tech
Ups power: 20-40kva three phase in and out online high frequency design
Ups system design: Same as 3C3, EX
Ups power: 20-40kva three phase in and out online high frequency design
Ups system design: Same as 3C3, EX
Feature:1. 3 phase online ups (high frequency online ups) provides high reliability power solution with an advanced,
full-digitalized, dsp-based Ti high-performance micro-processor controll tech
3 phase ups equipmed individual phasic micro-processor controller,
real time monitor ups and ac power status, manage battery charge, discharge in an ABM method,
Advanced Battery Management
2. High power ups consists of a SCR Silicon Rectifier module (PFC integrated) of higher input P.F. 0.99
better ultilize Ac input power
3. Ture online ups of high stability power solution with an individual phasic, advanced,transformer-less,
dsp-based IGBT (Fairchild brand) Inverter
Pure sine wave online ups output high stability sine wave power for protect critical loads, eg. modern
data-center computer room.
Zero transfer time(0ms from Ac-mode to battery-mode) guarrantees uninterruptible power supply /
uninterrupted power supply for connected loads
Online ups power supply of higher efficiency on normal mode: 0.94, ECO mode: 0.98
4. Battery backup power supply provides uninterrupted power supply from internal battery (standard
backup models) and external battery bank (long backup design)
Nominal battery dc voltage:336vdc, 360vdc, or 384vdc.
5. High frequency ups(3 phase online) realize convenient,easy communication, network monitor and
power management with
thorough communication interface: standard RS232,RS485, optional DB-9 dry contact, AS400
expansion card, SNMP network monitor, power management tool, protocol.
6. High frequency Online ups(3 phase), Online ups with isolation transformer provide secure power
solution from internal configured (or external fixed) Galvanic Isolation Output Transformer
isolate output sine wave power from complicated ac input network in case of heavier
noise interference, harmonic distortion;
isolating output neutral from ground line in case of unexpected electric shocks.
7. Online ups power with Emergent power supply(EPS) function: standard EPO "Emergent Power Off"
designation
8. Parallel redundant ups( 3 phase online) provides final solution of flexible on-demand power
expansion, hot-redundancy N+X parallel redundancy configuration
Max parallel redundant design ability: 8 units ( max 2 unit in redundancy , max 7 units in parallel)
9. 3 phase online ups provide dual ac input design option: regular and reserve mains input supply
10. 3 phase online ups with more optional design of
higher IP protection class keeps UPS interior clean, and prevent othe object into,
temperature sensor for protect battery service time
power feedback module: solves high BUS voltage from high re-generated energy on uploaded ups.
Battery Charge Board expansion: Dual charger board solve fast compensation of battery discharge
Internal Galvanic Isolation Transformer or standard configured internal batteries
N+X parallel redundancy
Specification:
20kva-16kw
30kva-24kw
40kva-32kw
3 phase online ups, high power ups, high frequency ups
electrical view
Pls contact Vena Tang:
Tel: +86 755 2910 1183
Shenzhen Must Power Limited established in 2010, with the headquarter in Hongkong, which is a professional hi-tech enterprise specialized in UPS, Power Inverter, Solar Power, VRLA Battery development, manufacturing, sales and after-service.
Our comprehensive product lines include:
Off-line UPS, line interactive UPS, On-line UPS, Solar inverter, Power inverters, Stabilizers and Solar battery.
Most of products from MUST applied with CE, FCC certificates. The main markets are Ukraine, Russia, Vietnam, Thailand, Pakistan, India, etc. Must Power Limited is one of the authorized suppliers for China Citic Bank, Ministry of Information Industry of China, Ministry of Power Industry of China, Ministry of Transportations of China.
With an excellent R & D team formed by over 30 engineers and a skilled, dedicated workforce, together 10, 000 square meter in-house manufacturing facilities in Guangdong China, Shenzhen Must Power Limited has innovated, developed and improved the products to meet the demands of customers and keep pace with changing demands of the industries. With 'close to customer' notion, we have aligned most of its resources to support our Original Equipment Manufacturer (OEM) customers, and work with our customers as power partners. Our mission is to be the best supplier of power solutions, and to accomplish this, we will continue to tailor products for market needs while maintaining high quality, integrated customer service and prompt delivery.
