230VDC 120W Outside Brushes DC Motor for Coffee Machine

Name: 230VDC 120W Outside Brushes DC Motor for Coffee Machine
Brand: all-electronics-online.com
SKU: 777127625
Availability: InStock
Rating: 4.7 (41 reviews)

Price:	US $ 28.3-50/Piece
Trade Terms:	FOB,CIF,EXW
Min Order:	1/Piece
Pay Type:	L/C,T/T,Western Union,Paypal

Contact Supplier

Showroom Product Company Profile

Prod Model:	63ZYT125-23043
Markets:	North America,South America,Eastern Europe,Southeast Asia,Africa,Oceania,Mid East,Eastern Asia,Western Europe
Model:	63zyt125-23043
Voltage:	230VDC
Current:	0.7A
Rated Speed:	3800rpm
Rated Torque:	0.25n.M
Power:	120W
Application:	Power Tools
Operating Speed:	Adjust Speed
Excitation Mode:	Excited
Structure And Working Principle:	Brush
Type:	Zyt
Certification:	SGS
Brand:	Sunrise Motor

Product Description

PMDC MOTOR 63ZYT125-23043 for coffee machine
Outside brushes motor with foot mounting

Motor specifications:
Voltage : 230vdc
Rated speed: 3800rpm
No-load speed: 4300rpm
Rated torque : 0.25N.m
Rated current: 0.7A
Peak torque : 0.72N.m
Peak current: 2.1A
Power: 120w

Model	Voltage (V DC)	No Load		Rated Load			Length (mm)
Model	Voltage (V DC)	Current (A)	Speed (r/min)	Torque (N.m)	Current (A)	Speed (r/min)	Length (mm)
63ZYT125-23043	230	0.2	4300	0.25	0.7	3800	125

More Motors

Changzhou Sunrise Electric Motor Company was founded in 2004 and is located about 200 km west of Shanghai. SUNRISE ELECTRIC MOTOR manufacture and export PMDC motors, BLDC motors, Hybrid Stepping motors with high torque output (0.2N. M - 28N. M), and customized motors which are per customers' drawings, specification and technical requirements. Also, we source and customize products associated with electric motor applications such as, motor controllers and drivers, motor sensing boards (PCB), etc.

The motors introduced can be used for commercial and residential applications such as industrial automation, office equipment, appliances for household, etc.

The motors listed have been exported overseas through our sales representatives in North America and Europe.
