24kv Dry Type Indoor Single Pole PT with Embeded Fuse

Name: 24kv Dry Type Indoor Single Pole PT with Embeded Fuse
Brand: all-electronics-online.com
SKU: 799922675
Availability: InStock
Rating: 4.5 (127 reviews)

Price:	US $ 452-478/Piece
Min Order:	1/Piece
Pay Type:	L/C,T/T,Western Union

Contact Supplier

Showroom Product Company Profile

Prod Model:	JDZX10-24R-1
Indoor:	PT
With Fuse:	Sing Pole
China:	Factory
Voltage Transformer:	Vt
24kv:	Dry Type
Expoxy Resin Type:	with Embeded Fuse
Application:	Switchgear
Type:	Voltage Transformer
Phase:	Single

Product Description

JDZXR-12C    Voltage Transformer
12Kv   Indoor   Single-Phanse   Epoxy Resin Type

Description
JDZXR-12C voltage transformer, epoxy resin casting and full enclosed construction, is used indoor switch cabinet to measure the current, electric energy and protective relaying in single phase or three phase AC circuit with the frequency 50Hz or 60Hz and highest voltage for equipment 12kV.
The iron core adopts advanced cold-rolled silicon steel sheet. High voltage outgoing line of primary winding was fetched out from top of the product; outgoing line of secondary winding was fetched out from transverse side of the product.

Technical Data
< >Installation Site   indoorRated Frequency: 50/60HzLoad power factor cosΦ=0.8 (lagging)Technical standard accords with GB1207-2006 / IEC 60044-2:2003Technical parameter
1. Rated primary voltage: 6/or 11/ etc.
2. Technical standard accords with IEC 60044-2:2003 Part2 Instrument transformers-Part2: inductive voltage transformers ( or new version IEC61869-1&3)

Type	Rated primary voltage (kV)	Rated secondary voltage (kV)	Accuracy classes combination	Rated output (VA)	Thermal limiting current (VA)	Rated insulation level(kV)
JDZXR-12C	6/ 11/	0.1/ 0.11/	0.2	15	400	12/28/75
			0.5	30
			1	80
		0.1//0.1/3 0.11//0.11/3	0.2/6P(3P)	15/50	300
		0.1//0.1/3 0.11//0.11/3	0.5/6P(3P)	30/50	300

Remarks: Upon request we are glad to offer transformers according to other standards or with non-standard technical specs.
