| Prod Model: |
DSC-Cat3 Telephone Cable |
| Markets: |
North America,South America,Eastern Europe,Southeast Asia,Africa,Oceania,Mid East,Eastern Asia,Western Europe |
| UTP Cat3 Cable: |
0.51mmcca, Cu |
| Application: |
RF Cable |
| Conductor Material: |
BC/CCS/CCA/TC/CU/CCAG |
| Cover Material: |
PVC |
| Type: |
Cat 3 |
| Certification: |
UL |
| Model: |
UTP Cat3 Cable |
| Brand: |
Cat3 Telephone Cable |
Product Description
25 Pair Utp Cat3 communication cable
UTP Cat3,Cat3 UTP,Lan Cable,Network Cable,Data Cable
Specifications
- UTP Outdoor Lan Cable Cat3
- 10Pairs BC 24AWG 0.50mm
- PE Black Jacket Outdoor Cable
- Waterproof, Direct burial
305m/Box,2Boxes/Carton | |
Conductor Size |
0.35/0.38/0.4/0.45/0.485/0.5/0.51mm |
Jacket Thinckness |
0.92-0.95mm |
Insulation Thinckness |
0.55mm |
UTP/FTP/STP/SFTP Available |
Color Code Pair 1 : Blue- White / Blue Pair 2 : Orange- White / Orange Pair 3 : Green- White / Green Pair 4 : Brown- White / Brow |
DC resistance(Max.) |
9.5Ω/100m |
DC Resistance Imbalance(Average) |
2.50% |
Working Capacitance(Max.) |
5.4nF/100m |
Insulation Resistance |
10000MΩ.km |
Transmission Velocity |
65% |
Operating temperation |
75 |
Conductor |
Insulation |
Drain |
hielded |
Outer Jacket |
Inner Jacket
|
AWG |
Specification
(mm) |
Material |
Thickness
(NOM.mm) |
Material |
Thickness
(NOM.mm) |
OD (NOM.mm) |
Material |
Thickness
(NOM.mm) |
OD (NOM.mm) |
26 |
1/0.404 |
HD-PE |
0.25 |
1/0.404TC |
AL/Mylar |
PE |
0.60 |
5.3 |
PVC |
0.6 |
6.5 |
7/0.16 |
HD-PE |
0.25 |
7/0.16TC |
AL/Mylar |
PE |
0.60 |
5.5 |
PVC |
0.6 |
6.7
|
24 |
1/0.511 |
HD-PE |
0.25 |
1/0.511TC |
AL/Mylar |
PE |
0.60 |
5.5 |
PVC
|
0.6 |
6.8 |
7/0.203 |
HD-PE |
0.25 |
7/0.203TC |
AL/Mylar |
PE |
0.60 |
5.5 |
PVC |
0.6 |
6.8
|
Cat5e Lan Network Cable Construction: UTP Cat5e Cable
Item |
Conductor |
Number Of Pairs |
Shielding |
Drain Wire |
O.D. |
Cat5e UTP Cable |
0.51mm
BC/CCA |
4 |
Non |
Non |
5.1mm Jacket
ROHS,UV,LSZH,UL,Reach |
Cat5e FTP Cable |
0.51mm
BC/CCA |
4 |
Aluminum Foil |
Yes |
5.8mm
ROHS,UV,LSZH,UL,Reach |
Cat5e SFTP Cable |
0.51mm
BC/CCA |
4 |
Aluminum Foil + Alloy Braiding |
Yes |
6.2mmJacket
ROHS,UV,LSZH,UL,Reach |
Cat5e UTP
Outdoor Cable |
0.51mm
BC/CCA |
4 |
Non |
Non |
6.2mm Jacket
ROHS,UV,LSZH,UL,Reach |
Cat5e FTP
Messenger Cable |
0.51mm
BC/CCA |
4 | Aluminum Foil | Yes | 6.0mm JacketROHS,UV,LSZH,UL,Reach |
Cat5e UTP Cable Technical Performance(100m), UTP Cat5e Cable
Frequency MHz | RL ≥dB | Attenuation ≤dB/100m | NEXT ≥dB/100m | PHASE DELAY≤ ns | ELFEXT ≥dB/100m | PS NEXT ≥dB/100m | PS ELFEXT ≥dB/100m |
| 1 | 20.0 | 2.0 | 65.3 | 570 | 63.8 | 62.3 | 60.8 |
| 4 | 23.0 | 4.1 | 56.3 | 552 | 51.7 | 53.3 | 48.8 |
| 8 | 24.5 | 5.8 | 51.8 | 546.73 | 45.7 | 48.8 | 42.7 |
| 10 | 25.0 | 6.5 | 50.3 | 545.38 | 43.8 | 47.3 | 40.8 |
| 16 | 25.0 | 8.2 | 47.3 | 543 | 39.7 | 44.2 | 36.7 |
| 20 | 25.0 | 9.3 | 48.5 | 542.05 | 37.7 | 42.8 | 34.7 |
| 25 | 24.3 | 10.4 | 44.3 | 541.2 | 35.8 | 41.3 | 32.8 |
| 31.25 | 23.6 | 11.6 | 42.9 | 540.44 | 33.9 | 39.9 | 30.9 |
| 62.5 | 21.5 | 17.0 | 38.4 | 538.55 | 27.8 | 35.4 | 24.8 |
| 100 | 20.1 | 22.0 | 35.3 | 537.6 | 23.8 | 32.3 | 20.8 |
Applications: Cat5e UTP Cable, UTP Cat5e Cable
1.Computer Network Cabling Project.
2.Broadband Network Communication.
3.Digital ISDN Network and ATM 155Mbps Network
4.Ethernet Network
5.Audio and Data Transmission
Packing: 2000m/wooden drum or 3000m/wooden drum, Customer's requirement also be welcom
