25W Single Output Switching Power Supply (HS-25)

Name: 25W Single Output Switching Power Supply (HS-25)
Brand: all-electronics-online.com
SKU: 13213
Availability: InStock
Rating: 5 (140 reviews)

Price:	US $ 7/Piece
Trade Terms:	FOB,CFR,CIF
Min Order:	1/Piece
Pay Type:	L/C,T/T

Contact Supplier

Showroom Product Company Profile

Prod Model:	HS-25
Markets:	North America,South America,Eastern Europe,Southeast Asia,Africa,Oceania,Mid East,Eastern Asia,Western Europe
Output Type:	Single
Output Power:	1 - 50W
Voltage Regulating Mode:	Width Modulation Type
Connection Mode:	Series Switching Power Supply
Starting Mode:	Self-excited Switching Power Supply
Warranty:	2 Years
Power Supplying System:	Terminal Power Distribution Equipment
Certification:	ISO
Input Voltage:	AC85~264
Brand:	Dhecn

Product Description

Features:
· High efficiency, high reliability
· Universal AC input / Full range
· Protections: Short circuit / Over load / Over voltage
· Fixed switching frequency at 56 KHz
· 100% full load burn-in test
· Cooling by free air convection
· 2 years warranty
· Dimension: 99*97*36mm (L*W*H)

Specification:

1) INPUT
· Voltage Range: 85-264VAC 120-370VDC; 47-63Hz
· AC Current: 0.6A/115VAC 0.35A/230VAC
· Inrush Current: Cold start 15A/115V 30A/230V
· Leakage Current: <0.75mA/240VAC

2) PROTECTION
· Over Load: 110%-160%; Fold back current limiting, recovers automatically after fault condition is removed.
· Over Voltage: 115%-135%; Hiccup mode, recovers automatically after fault condition is removed.

3) ENVIRONMENT
· Working Temp. & Humidity: -10º C~+60º C; 20%~90% RH.
· Storage Temp. & Humidity: -20º C~+85º C; 10%~95% RH.
· Vibration: 10~500Hz, 2G 10min. /1 cycle, period for 60min, each along X, Y, Z axes.

4) SAFETY STANDARDS
· Withstand Voltage; I/P-O/P: 3KVAC; I/P-FG: 1.5KVAC; O/P-FG: 0.5KVAC
· Isolation Resistance: I/P-O/P, I/P-FG, O/P-FG: 100MΩ /500VDC
· Safety Standards: Design refer to UL1012, EN60950, TUV.
· EMC Standards: Design refer to EN55022, EN55024, EN61000-3-2, -3 EN61000-4-2, 3, 4, 5; ENV50204

5) OUTPUT
· Model: HS-25-5 HS-25-12 HS-25-15 HS-25-24
· Voltage Tolerance: ± 2% ± 1% ± 1% ± 1%
· Rated Current: 5A 2.1A 1.7A 1.1A
· Current Range: 0-5A 0-2.1A 0-1.7A 0-1.1A
· Rated Power: 25W 25.2W 25.5W 26.4W
· Ripple & Noise: 50mVp-p 100mVp-p 100mVp-p 100mVp-p
· DC Voltage Adj. Range: +10, -5% ± 10% ± 10% ± 10%
· Setup, Rise, Hold time: 800ms, 50ms, 10ms/115VAC; 300ms, 50ms, 80ms/230VAC at full load.

Established in 1988, We specialize in manufacturing switching power supply, current transformer, voltage transformer, fuse and isolation switch. Donghua provides you a variety of high quality switching power supply, Transformer, fuse, isolation switch And professional product solution.

To supply our customers perfect products, we set up R&D department with over 20 experienced engineers and also follow a full set of computerized managementssystem. What' S more, as an ISO9001 certified company, we adopt a strict inspection process and a scientific management system with modern imported manufacturing and testing facilities, succeeded in achieving some safety sertification such as CCC, CE, CB, UL and all products are RoHS Compliance.

Advantage managent and abundant labor in China, let us provide our customers more high reliable quality and more cheaper products, by now, DHECN-SMPS is becoming more and more famous among customers worldwide due to its reliable quality, competitive price, punctual delivery and correct service.

Donghua warmly welcome all old and new customers to visit our company or contact us by Tel, Fax, E-mail. Believing we will be your long-term business cooperator either as a reliable supplier or as a close ODM/OEM partner in China.
