2kv Flat Electrical Submersible Pump Esp Power Cable

Prod Model:	ESP Cable
Markets:	North America,South America,Eastern Europe,Southeast Asia,Africa,Oceania,Mid East,Eastern Asia,Western Europe
Rated Voltage:	1.8/3kv or 3.6/6kv
Cross Section:	10mm2, 13mm2, 16mm2, 20mm2, 33mm2, 42mm2
Insulation:	Epr, PP
Sheath:	Epr, Lead
Certificate:	UL
Conductor:	Solid Copper
Voltage:	Low and Medium Voltage Cable
Current:	AC Cable
Certification:	ISO
Model:	Qypdb10, Qypdf10, Qypdf12, Qyeq10-120
Sheath Material:	Lead Sheathed
Insulation Material:	Epr or XLPE
Application:	Fixed-Laid in Oil Well of The Land or Platform on
Brand:	Rne Da

Product Description

2KV Flat Electrical Submersible Pump ESP Power Cable



1 Implemented Standard: Enterprise standard

2 Product Introduction:

The product manufactured by us has the characteristics of advanced technology, reliable quality.The main manufacturing equipment is included
the ROYLE90 plastic extrude, the rubber continuous vulcanizing process, the interlocked armoring machine made by CEECO, Canada, the
continuous sintering process imported from GRILLER, Austria, the Nokia cross-linked cable process, the advanced continuous annealing
process and tinned process, etc. Now, the cable and coil end lead wire for submersible
oil pump or pump unit can be produced, with different types and specifications, the crosssection of conductor is 42mm2 and below. The well
temperature is from 50ºC to 180ºC, the max. continuous working temperature of conductor is 204ºC. The insulation material that can be used is
as below: PP, EPR, polyimideF46, fluoroscopic, XLPE, etc. The material of inner jacket includes NBR, compound of the neoprene and PVC, EPR,
 fluoroplastics, lea, etc. The outer sheath material is as the galvanized steel tape, stainless steel tape, etc. All kinds of cables for submersible
oil pump can be developed according to the customer's requirements.

3 Test voltage of the finished product before leaving the factory


Rated voltage (KV)	Test voltage(KV)
1.8/3	DC 30/5min or AC 10KV/1min,no-breakdown
3.6/6	DC 35/5min or AC 13KV/1min,no-breakdown



4 Type and Name


Cable type	Description	Max working  temperatureºC	Product range  (cross section)  mm2
QYPN	PP insulated and NBR sheathed, galvanized steel tape interlocked armoring,  cable for submersible oil pump	96	10,13,16,20,33,42
QYPNY	PP insulated and NBR sheathed, galvanized steel tape interlocked armoring,  round cable for submersible oil pump	96	10,13,16,20,33,42
QYEN	EPR insulated and NBR sheathed, galvanized steel tape interlocked armoring,  cable for submersible oil pump	140	10,13,16,20,33,42
QYENY	EPR insulated and NBR sheathed, galvanized steel tape interlocked armoring,  round cable for submersible oil pump	140	10,13,16,20,33,42
QYEE	EPR insulated and sheathed, galvanized steel tape interlocked armoring, cable  for submersible oil pump	175	10,13,16,20,33,42
QYEEY	EPR insulated and sheathed, galvanized steel tape interlocked armoring,  round cable for submersible oil pump	175	10,13,16,20,33,42
QYEQ	EPR insulated and lead sheathed, galvanized steel tape interlocked armoring, cable for submersible oil pump	204	10,13,16,20,33,42
QYYEQ	Polyimide-F46 composite film and EPR insulated, lead sheathed, galvanized steel tape interlocked armoring, cable for submersible oil pump	232	10,13,16,20,33,42
QYYEEY	Polyimide-F46 composite film and EPR insulated, EPR sheathed, galvanized steel tape interlocked armoring, round cable for submersible oil pump	204	10,13,16,20,33,42
QYJEQ	Polyimide F46 composite film and EPR insulated, lead sheathed, galvanized steel  tape interlocked armoring, lead wire for submersible oil pump	200	10,13,16,20,33


Company Information


Hebei huatong wires&cables Group Co.,ltd.It was established in 1993, we are JV with Furukawa (Japanese company) for rubber serious cables
and JV with Riken(Japanese company) for elevator cables. Besides these, our submersible oil pump cable and shipboard cable are very
influential in domestic, and, the traditional cables are also produced such as PVC powercables, XLPE power cables, ABC cables, wires, control
cables, screened cables,communication cables, conductors.We areOEM for many USA, Europen, Australia cable company,70% of our products
are exported, most customers are from developed countries. We got ISO,UL,TUV,KEMA,CE and many other certifications.

FAQ
(1).When can I get the price?
We usually quote within 6 hours after we get your inquiry. If you are very urgent to get the price, please call us or tell us in your e-mail so that we
will regard your inquiry priority.
(2).How can I get a sample to check your quality?
After price confirmation, you can require for samples to check our quality. Sample is free, but the freight charge should be paid.
(3).How long can I expect to get the sample?
After you pay the freight charge and send us confirmed files, the samples will be ready for delivery in 3-7days. The samples will be sent to you
via express and arrive in 3~5 days. You can use your own express account orprepay us if you do not have an account.
(4).What about the lead time for mass production?
Honestly, it depends on the order quantity and the season you place the order.The best record we keep is delivering 10 kilometers cable within
a week. Generally speaking, we suggest that you start inquiry two months before the date you would like to get the products at your country.
