3.0mm ST APC SM mm Optical Terminator

Name: 3.0mm ST APC SM mm Optical Terminator
Brand: all-electronics-online.com
SKU: 691528531
Availability: InStock
Rating: 4.6 (150 reviews)

Price:	US $ 1-1.5/Piece
Min Order:	1/Piece
Pay Type:	L/C,T/T,D/P,Western Union,Paypal

Contact Supplier

Showroom Product Company Profile

Prod Model:	00452
Color:	Green
Material:	Plastic
Fiber Type:	Singlemode
Fiber Polishing:	APC
Cable:	3.0mm
Material Shape:	Round Wire
Allowed Lateral Pressure:	1000N
Core:	Single Core
Transmission Medium:	Single-Mode
Structure:	ST
Number Of Cores:	Single-Core
Ferrule Endface:	APC
Light Source TYPE:	Fiber

Product Description

3.0mm ST APC SM MM Optical Terminator

Optical Terminators are functional devices using Metal-lon Doped fibers. These products prevent the reflection of light that are present at open end systems. Fiber optic terminator can terminate unused fiber connector ports in fiber optic systems . Fiber opticterminators are passive components that absorb light coming from unterminated connector plugs. By minimizing the reflected power, the terminator can reduce signal degradation in digital and analog systems.

Features / Benefits

Latched push-pull operation;
Automatic metal shutter on connector and adapter for dust and laser protection;
Safe for use in high power laser applications;
One-piece design for easy termination;
Color coding of connector and adapter;
Mechanical coding of connector and adapter.

Specifications

Compliance	IEC 61754-15, TIA 604-16
Technology	Full ceramic ferrule and sleeve
Tuning	in 60^° steps
Mechanical resistance	100N tensile load
Thermal resistance	-40ºC to +85ºC, stock temperature range
Flammability	UL 94-V0
Durability	Min. 1000 mating cycles
Color of housing	Single-mode, blue
	SM (APC 8^°), green
	Multimode, beige

Application

Telecommunication Networks
Instrumentation
CATV Networks
Active Device Termination
EDFA

Technical Information

Standards requirements	TIA/EIA-604 FOCIS-10 compatible; exceeds TIA/EIA-568-B.3 requirements
Fiber compatibility	62.5/125μm OM1, 50/125μm OM2,10Gig 50/125μm laser optimized OM3/OM4 and 9/125μm OS1
Fiber cable type	900μm tight-buffered fiber recommended 250μm coated fiber, by using F250BT-C 250 micron fiber build-up tube kit or FO6CB or FO12CB fan-out kit
Insertion loss	0.1dB average (Multimode and Single-mode)
Return loss	>20dB (Multimode), >40dB (Single-mode)

Payment & Shipping Term

Minimum Order Quantity	1 Piece MOQ On Request
Packaging Details	10 or 20 PCS / Plastic Tray, 1 PC / Gift Box
Delivery Time	Delivery In 7 - 15 Business Days
Payment Terms	L/C, D/A, D/P, T/T, Western Union, MoneyGram
Supply Ability	5000 Pieces Per Monthly

Ordering Information - Fiber Optical Connector

Fiber Type	5-50/125; 6-62.5/125; 9-9/125; O-OM3
Connector Type	F-FC S-SC T-ST L-LC M-MU E-E2000
Polish Type	P-PC U-UPC A-APC
Operating Wavelength	1-850nm; 2-1310nm; 3-1550nm; 4-1310/1550nm; 5- 1310/1490nm
