3.5mm Male Test Cable Assembly

Name: 3.5mm Male Test Cable Assembly
Brand: all-electronics-online.com
SKU: 750241635
Availability: InStock
Rating: 4.3 (47 reviews)

Price:	US $ 140.3-145.3/Piece
Trade Terms:	FOB
Min Order:	10/Piece
Pay Type:	L/C,T/T,D/P

Contact Supplier

Showroom Product Company Profile

Prod Model:	3.5mm
Markets:	North America,South America,Eastern Europe,Southeast Asia,Africa,Oceania,Mid East,Eastern Asia,Western Europe
Mating Cycles:	>1000 Cycles
Plating Of Pin:	Au, Silver

Product Description

TEST CABLE

Product data
Part Number	Description		Insertion loss (dB) 25ºC
Part Number	Connectors	Cable Length	up to 0.9GHz	0.9to 1.8GHz	1.8to 3GHz
	N, Male, Straight / N, Male, Straight	1000mm	< 0.46	< 0.65	< 0.88
	3.5mm, Male, Straight / 3.5mm, male, Straight	1000mm	< 0.46	< 0.65	< 0.88

Electrical Data
Impedance			50	Ω
Operating frequency			3	GHz
Insulation resistance			≥5000	MΩ
Dielectric withstand voltage AC r.m.s			≤1500	V
Capacitance			94	pF/m
Velocity of propagation			70%
Shielding effectiveness			>-80	dB
Return loss			≤-32dB(upto1.8GHz) ≤-30dB(1.8to3GHz)
			up to 0.9GHz	0.9 to 1.8GHz	1.8 to 3GHz
Insertion loss vs.shaking (dB)			< 0.03	< 0.03	< 0.03
Insertion loss vs.bending (dB)			< 0.03	< 0.03	< 0.03

Mechanical Data
Min. bending radius dynamic			50	mm
Recommended mating torque			0.7~1.1	Nm

Environmental Data
Operating termperature			-55ºC to +85ºC
2002/95/EC (ROHS)			compliant

Material Data
Piece Parts			Material		Surface Plating
center contact			Beryllium copper		Au
body			Brass		CuZnSn(N)
body			Brass		Au(3.5mm)
coupling nut			Brass		CuZnSn(N)
coupling nut			Brass		Au(3.5mm)
insulator			TPX RT18		-

EZCON Telecom Technology (Changzhou) Co., Ltd. Was formally founded on January 19, 2013, in Changzhou City, Jiangsu Province, Peoples Republic of China. EZCON is a product and solution provider, the company provide high quality, high performance and low cost cable assembly/connector products. EZCON engages in R&D, for telecom and electronics products with focus on RF cable assemblies/connectors, high speed interconnect cable assemblies/connectors and high end test/calibration products. The company has the capacity of product design, engineering service, low cost production/sourcing, assembly, and testing. EZCON combines the advantages of low cost production in China with a high level of engineering expertise, service, and quality. EZCON Telecom Technology Co. Is a US-China joint venture. EZCON CEO, Dr. Zemin Liu is a recognized RF connector industry expert. Dr. Liu developed and designed the industry's most advanced EZCON series connector. He has over 20 years work experience working in the United States, Sweden, and China for world-renowned companies (Commscope, Tyco, Atlas Copco, Amphenol etc). The company management team consists of top technical experts and business development professionals in the telecom industries. EZCON Telecom Technology Co. LTDA.

Leading supplier for high quality test products (frequency range DC-100 GHz) and RF cable assemblies including test cables, adaptors, and calibration kits etc for R&D and production test applications as well as RF connectors and cable assemblies for wireless base stations. Our customers includes world-class telecom equipment suppliers as well as operators such as Commscope, Amphenol, AT&T, Huawei, Synergy Telecom (India) etc.
