| Prod Model: |
1054 |
| Copper Thickness: |
0.5oz-12 Oz |
| Min. Line Width/Spacing: |
0.075mm |
| Structure: |
3 Layer FPC |
| Type: |
Flexible Circuit Board |
| Flame Retardant Properties: |
V0 |
| Dielectric: |
Fr4&Polymide |
| Material: |
Polyimide |
Product Description
Ucreate is specialized in low to medium volume high quality PCB population with UL&ISO&RoHs certificate approved. Our Specialities: 1. No MOQ2. Quick Lead time3. High standard pcb depends on IPC Class II or IPC Class III if required4. 100% E-tested guarantee before shipping5. RoHS, UL, ISO, SGS certificate approvedOur Capabilities:| Items | Speci. | Remark |
| Max panel size | 32" x 20.5"(800mm x 520mm) | |
| Min trace width/ space (inner layer) | 4mil/4mil(0.1mm/0.1mm) | |
| Min PAD (inner layer) | 5 mil(0.13mm) | hole ring width |
| Min thickness(inner layer) | 4 mil(0.1mm) | without copper |
| Inner copper thickness | 1~4 oz | |
| Outer copper thickness | 0.5~6 oz | |
| Finished board thickness | 0.4-3.2 mm | |
Board thickness tolerance control | ±0.10 mm | ±0.10 mm | 1~4 L |
| ±10% | ±10% | 6~8 L |
| ±10% | ±10% | ≥10 L |
| Inner layer treatment | brown oxidation | |
| Layer count Capability | 1-30 LAYER | |
| alignment between ML | ±2mil | |
| Min drilling | 0.15 mm | |
| Min finished hole | 0.1 mm | |
| Hole precision | ±2 mil(±50 um) | |
| tolerance for Slot | ±3 mil(±75 um) | |
| tolerance for PTH | ±3 mil(±75um) | |
| tolerance for NPTH | ±2mil(±50um) | |
| Max Aspect Ratio for PTH | 8:1 | |
| Hole wall copper thickness | 15-50um | |
| Alignment of outer layers | 4mil/4mil | |
| Min trace width/space for outer layer | 4mil/4mil | |
| Tolerance of Etching | +/-10% | |
| Thickness of solder mask | on trace | 0.4-1.2mil(10-30um) | |
| at trace corner | ≥0.2mil(5um) | |
| On base material | ≤+1.2mil
Finished thickness | |
| Hardness of solder mask | 6H | |
| Alignment of solder mask film | ±2mil(+/-50um) | |
| Min width of solder mask bridge | 4mil(100um) | |
| Max hole with solder plug | 0.5mm | |
| Surface finish | HAL (Lead or Lead free), immersion Gold, Immersion Nickel, Electric Gold finger, Electric Gold, OSP, Immersion Silver. | |
| Max Nickel thickness for Gold finger | 280u"(7um) | |
| Max gold thickness for Gold finger | 30u"(0.75um) | |
| Nickel thickness in Immersion Gold | 120u"/240u"(3um/6um) | |
| Gold thickness in Immersion Gold | 2u"/6u"(0.05um/0.15um) | |
| Impedance control and its tolerance | 50±10%,75±10%,100±10% 110±10% | |
| Trace Anti-stripped strength | ≥61B/in(≥107g/mm) | |
bow and twist
| 0.75% |
Function of flexible circuit board
1.Lead Line
2.Printed Circuit
3.Connector
4.Integration of Function
Application of flexible circuit board
Aerospace, military, mobile, laptop,Auto Electronics, computer peripherals,
digital cameras,GPS,MP4,Instrumentation equipment,Appliances,Power supply,etc.
By unremitting work and effort tothe marketing, products exports to American,
Canada, Europe counties,Africa and other Asia-pacific countries.
Advantage:
1. FPCB from factory directly.
2. FPCB which have the comprehensive quality control system.
3. FPCB with good price.
4. FPCB with quick turn delivery time .
5. FPCB with certification (ISO/UL/RoHS/SGS).
6. FPCB with many years experience in exporting service.
