3000W Battery Power Inverter 48V DC AC 120V
| Price: |
US $ 225/Piece |
| Min Order: |
100/Piece |
| Pay Type: |
L/C,T/T,D/P,Western Union,Paypal |
Product Description
3000w Battery Power Inverter 48v DC AC 120V
Product Description
| Model | P3000-121 | P3000-241 | P3000-481 | P3000-122 | P3000-242 | P3000-482 |
| Output | AC voltage | 100/110/120VAC | 220/230/240VAC |
| Rated power | 3000W |
| Surge power | 9000W |
| USB | 5V 500mA(optional) |
| Waveform | Pure sine wave(THD<3Hz) |
| Frequency | 50/60Hz±3Hz |
| AC regulation | ±5% |
| Standard sockets | A,B,C,D,E,F,G,H,I(optional) |
| LED indicator | Green for power on,red for failure/protection status indication |
| Input | No load current draw | ≤1A |
| DC voltage | 12V | 24V | 48V | 12V | 24V | 48V |
| Voltage range | 10.5-15.0VDC | 21.0-30.0VDC | 42-60VDC | 10.5-15.0VDC | 21.0-30.0VDC | 42-60VDC |
| Efficiency | >87.0% | >90.0% | >90.0% | >87.0% | >90.0% | >90.0% |
| Fuse | 40A*5 | 20A*5 | 10A*5 | 40A*5 | 20A*5 | 10A*5 |
| DC cable | BVR4*2 | BVR4*2 | BVR4*2 | BVR4*2 | BVR4*2 | BVR4*2 |
| Protection | Bat.low voltage alarm | 11±0.5VDC | 22±1VDC | 44±2VDC | 11±0.5VDC | 22±1VDC | 44±2VDC |
| Bat.low voltage shutdown | 10.5±0.5VDC | 21.0±1VDC | 42±2VDC | 10.5±0.5VDC | 21.0±1VDC | 42±2VDC |
| Overload | Shut down |
| Over voltage | 14.8±0.5VDC | 29.6±1VDC | 58.4±2VDC | 14.8±0.5VDC | 29.6±1VDC | 58.4±2VDC |
| Over temperature | Shut-off output voltage,recover automatically after temperature goes down |
| Short circuit | Shut-off output voltage,repower on to recover |
| Bat.reverse polarity | By fuse open |
| Soft start | Yes 5-10s |
| Earth leakage | Yes |
| Environment | Reset voltage atfer LVS | 11.8-12.8VDC | 23.6-25.6VDC | 47.2-51.2VDC | 11.8-12.8VDC | 23.6-25.6VDC | 47.2-51.2VDC |
| Working temp | 0-40ºC |
| Others | Remote control | Switch with 5m wire(otional) |
| Dimension | 48.8*23*10.8cm |
| Packing | 8.96kg,2pcs/CTN/56*32*40cm/18.9kg |
| Cooling fan | Controlled by load/temperature(optional) |
| Application | Home and office appliances |
