3000W DC12/24V PV Inverter

Name: 3000W DC12/24V PV Inverter
Brand: all-electronics-online.com
SKU: 722009275
Availability: InStock
Rating: 4.8 (138 reviews)

Price:	Negotiable/Piece
Trade Terms:	FOB,CFR,CIF
Min Order:	10/Piece
Pay Type:	L/C,T/T,Western Union

Contact Supplier

Showroom Product Company Profile

Prod Model:	PI-3000W
Markets:	North America,South America,Eastern Europe,Southeast Asia,Africa,Oceania,Mid East,Eastern Asia,Western Europe
Warranty:	12months
Battery Type:	AGM/Vlra/Gel/Deep Cycle
Wave Form:	Pure Sine Wave
Frequency:	Low Frequency
Charge Current:	20-25A
Display:	LCD/LED Selectable
Transfer Time:	<10ms
Application:	Office/ Home Use
Surge Rate:	3:1
DC Voltage:	12/24V
Type:	DC/AC Inverters
Phase:	Single
Power Source:	Electric Power
Output Power:	501 - 1000W

Product Description

PV Solar Inverter 1000W 1500W 2000W 3000W

Description:

Pure sine wave Inverter
High efficiency up to 90%
Low self-consumption less than 5W
Wide usage solar/AC/CAR

Applications:

Pure sine wave output can be used with different domestic appliance
TV, refrigerator, fan, air conditioner induction cooker, micro-wave oven etc.

MODEL NAME (PI)		1000W	1500W	2000W	3000W
DC INPUT	DC input voltage rating	12V/24V DC
	DC input voltage range	11 -15V DC for 12v ; 22-30V for24v
	Low battery alarm	10.5V DC±0.5V DC for 12V ; 21VDC±0.5V for 24V
	Low battery shutdown	10.0V DC±0.5V DC for 12v ; 20VDC±0.5V for 24v
	No load current draw	<1 A (Input:13.2V DC)
	High battery voltage shutdown	>15V DC for 12v; >30V DC FOR 24V
	Fuse (internal)	30A*4	30A*6	25A*12	25A*16
	Input reverse protection	Yes
OUTPUT	Output voltage range	93VAC~138VAC; 185Vac~264Vac
	Output frequency	60Hz /50Hz
	Output wave form	Pure Sine Wave
	Max output power	1000W	15000W	2000W	3000W
	Overload protection power	100%-130%
	Surge capacity (Peak power)	2:1
	Pure Sine Wave Output	THD<3%
GENERAL DATA	Digital display	Indicates DC battery voltage±0.2V
		output power ±10%@output≥1000W
	Efficiency(except power loss on the wire)	>85% (Full load)
	Over load protection	Yes
	Short circuit protection	Yes
	Over temperature shutdown	<65 degree
	Operating temperature range	-5-40 degree
	Storage temperature range	-20-50 degree
	Operating relative humidity	10%-90%
	Storage relative humidity	5%-95%
MECHANICAL	Dimension(mm)	27022078	37022082.7	34326092	381.526092
	Net weight(kg)	2.5	3.5	5.2	6.15
	Outlet	IEC/NEMA/SCHUKO/UNVERSAL
	Connector	DC cable
	Cool mode	By fan

Shenzhen Must Energy Technology Co., Ltd. Established in Shenzhen in 1998, Which is leading manufacturer of power protection produtcs & service solutions including UPS, power inverters, Solar inverters, charge controllers, Batteries, AVR for more than ten years, with a strong R&D team, internal automation equipment design and manufacturing capability, as well as continuous quality improvement, Santakups Electronic Company has become the leading supplier for long backup time power solution in the new world of information technology.

We' Ve kept our defect rate well under 0.5 percent. Logo printing service is available on request.
