0~30V DC Voltage Transformer Stabilizer 220V Factory Power Supply
| Price: |
US $ 245-265/Piece |
| Trade Terms: |
FOB,CIF,EXW |
| Min Order: |
1/Piece |
| Pay Type: |
L/C,T/T,Paypal,Money Gram |
| Prod Model: |
MZDC SERIES |
| Markets: |
North America,South America,Eastern Europe,Southeast Asia,Africa,Oceania,Mid East,Eastern Asia,Western Europe |
| Current Type: |
DC |
| Phase: |
Single Phase |
| Usage: |
JIW |
| Frequency: |
High Frequency |
| Size: |
Small/Large |
| Application Range: |
Hotel/School/ |
| Brand: |
Meze |
Product Description
0~30V DC Voltage Transformer Stabilizer 220v Factory Power Supply
| Model MZT | 3010 | 3015 | 3020 | 3030 | 3040 | 3050 | 3060 | 3080 | 3100 | 3120 | 3140 | 3160 | 3200 | 3250 | 3300 |
| Nominal capacity | 10KVA | 15KVA | 20KVA | 30KVA | 40KVA | 50KVA | 60KVA | 80KVA | 100KVA | 120KVA | 140KVA | 160KVA | 200KVA | 250KVA | 300KVA |
| Working way and principle | On-line static bypass switch power supply,Double conversion technolog,The output power is completely isolated |
| Ac input | Number of phase | three-phase+N+G |
| Voltage | 380V±20% |
| Frequency | 50ZH±15% |
| Single-phase maximum current(A) | 25 | 33 | 40 | 55 | 71 | 86 | 102 | 133 | 164 | 195 | 226 | 257 | 286 | 366 | 517 |
| The power factor | 0.95 |
| Soft start | 0-100% 5sec |
| Bypass the input | Voltage | 380v±15% |
| Frequency | 50HZ±5% |
| Conversion time | nverter/The bypass(overload)Oms |
| Dc system | Dc voltage | 384V(Battery 12 v32 section) | 384V/396V(Section 12 v32 / section 33) |
| Float charging voltage | 432V | 446V |
| As the voltage | 336V | 347V |
| The maximum discharge current(A) | 25 | 42 | 56 | 85 | 113 | 141 | 169 | 225 | 282 | 338 | 400 | 457 | 571 | 714 | 857 |
| Charging current | 10-25A |
| The ac | Number of phase | three-phase+N+G |
| Voltage | 380±1% |
| Frequency | 50HZ±5%(mains)50HZ±0.05%(Battery power) |
| The load power factor | 0.8 Lag |
| Output waveform | Sine wave |
| Total harmonic distortion | Linear load<3% The nonlinear load<5% |
| Dynamic load voltage transients | ±5%(Change from 0-100% fall) |
| Transient recovery time | <20ms ±5% |
| Unbalanced voltage | ±1%(Balance the load) |
| Overload capacity | 125%10min ,150%1min ,>150%220ms |
| System indicators | The work efficiency | >91%,95% ECOEconomic model |
| Computer communication interface | RS 232/RS422 |
| Operating temperature | 0-40ºC |
| Relative humidity | 0~90% No condensation |
| Running high | <1500,Each additional 100 meters, capacity by 1%, up to 4000 meters |
| Noise | 50db | 55db | 63db | 65db | 68db |
| Structure | Overall dimensions(D*W*H) | 700*520*1100 | 780*580*1190 | 1000*660*1460 | 1150*900*1500 | 1600*750*1600 |
| Weight (kg) | 190 | 230 | 320 | 365 | 440 | 520 | 605 | 850 | 1040 | 1110 | 1250 | 1380 | 1500 | 1600 | 2100 |
MZDC SERIES is Dc regulated power supply circuit for linear series adjustment type
structure, with the advantages of high stability, low ripple voltage. Using voltage
suspension type technology, Output voltage can be transferred to the rating from zero
volts, Output current can range from zero amps preset to the rating.
Adopt SCR or relay preliminary stability change on both ends of the voltage rectifier
bridge
Dual power supply, with functions of master-slave track series and parallel. when
cascade used, , The output voltage is equal to the double power source voltage, Increase
the load voltage, When using parallel output current is the sum of two lines of output
current Increase the load current
Small volume, light weight, convenient adjustment, high precision, low ripple voltage,
output voltage and current are starting from zero, with functions of master-slave track.
The input voltage: 220V±15% 50±1Hz
The output voltage: Can be adjusted according to the demand o f 0 ~ maximum rating
Output current: Can be adjusted according to the demand of 0 ~ maximum rating
Effect of the power: 5x10 +10mv
Current effect: 5x10 +15mv
Ripple voltage: Vp-p 10mv
1. Welcome your enquiryContact me :leon liang Mob:+86 18824648626
Meze company was founded in 1999, so far, has developed into a comprehensive power supply enterprise, products include: UPS uninterruptible power supply, microcomputer non-contact electronic AC regulated power supply, EPS emergency power supply, etc. Main range: The financial, government, research institutes, transportation, aerospace, electronics, medical, services, etc. To meet the global electronic and communication industry for power equipment is increasingly vigorous market demand, Due to the need of development, shenzhen Meze power technology Co., Ltd was established in 2008 (Specialize in UPS power frequency, regulated power supply, and transformer) In the same year registered Meze electronics Co., Ltd. (Terminal blocks, all accessories of PCB), In 2011, registered shenzhen Meze mechanical and electrical Co., Ltd. ( SMT placement machine and accessories ).
Existing number of employees: 180-180 employees, Using area: 3000 square meters, Company has the high technology and rich experience, Products from well-known international brands of Europe, is committed to providing customers with the full range of high quality high performance high stable power supply protection. Using the international advanced intelligent digital UPS power supply technology, and the most advanced precision purification. Provide the most advanced, cutting-edge, the most reliable, the top power solutions.
